Type:
Dome
Features:
HD
Features:
Night Vision
Frame Rate:
Variable
Active Pixels:
3864 (H) x 2176 (V)
Frequency:
50Hz, 60Hz
Sensor Type:
4K 1/1.8" CMOS sensor
Max Resolution:
2.1MP/1080p, 4K, 4K at 15fps, 4MP
Minimum Scene Illumination in color:
0.0 lux (B/W), 0.09 lux (color)
Scanning System:
Progressive scan
Signal technology:
CVBS, 960H, HD-Analog, HD-CVI, HD-TVI, HD over Coax
Test Video Output:
CVBS video output for testing
Advanced Lens Features:
Auto focus, Motorized zoom, P-iris
Focal Length:
3.6mm ~ 10mm
Horizontal Field of View (HFOV:
98.4° ~ 45.7°
IR Distance:
70' range Smart IR™
Lens Type:
Vari-focal Lens
Vertical Field of View (VFOV:
54.6° ~ 25.9°
Audio frequency response:
50Hz ~ 10KHz
Audio sensitivity:
-38dB ± 2dB
I/O Audio in/out:
1 microphone built-in
3D digital noise reduction:
Smart DNR™ 3D Digital Noise Reduction
Auto gain control:
Auto
Backlight compensation (BLC:
Yes
Camera Control:
UTC
Day and Night:
Auto day/night, Day (color), Night (B/W)
De-fog:
Yes
DRC:
Yes
Gamma:
0.45
Mirror/flip:
Yes
Motion Detection:
Yes
Privacy Zones:
24 programmable provacy zones
Sharpness:
Yes
Shutter Mode:
Auto, Manual
Shutter Speed:
1/30 ~ 1/30000
Star-Light (sense up:
Disabled at 4K, Off, x2-x32
White Balance:
Yes
Wide Dynamic Range (WDR:
True WDR 120dB
Environmental Operating Humidity:
10-90% (non-condensing)
Environmental Operating Temperature:
-4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional:
Optional. Sold separately
Camera Dimensions (H X W X D:
4.24" x 3.9" (107.8 x 99.1 mm)
Camera Weight:
0.55 lbs (0.25kg)
Housing:
Indoor Dome
Housing Color:
White
Materials:
Plastic, Snapit™ Housing
American wire gauge (AWG:
Cable type #18
Power (Max:
7.15W
Power Requirements:
24 V AC
Warranty:
5 Year Warranty
Product Type:
Dome
Connectivity:
Wired
IP Rating:
IP66
Night Vision:
IR
Power Type:
12VDC
Form Factor:
Dome
Operating Temperature:
-4° to 122°
Resolution:
4MP
Audio Support:
Yes
Built-in IR:
Yes
Day/Night:
Yes
WDR:
WDR
Image Sensor Size:
1/1.8" CMOS
Low Light Lux:
0.09 lux
Weight Lbs:
0.55
Wide Dynamic Range:
WDR
Environment Rating:
Indoor
Ir Lowlight:
IR; Day/Night
Audio:
Audio input; Built-in mic
Mount Type:
Wall; Rack
