Panduit PUR6AV04GR-G Pan-Net Cat6A U/UTP Riser Cable - 1000ft, Green, 23 AWG Solid Copper

The Panduit PUR6AV04GR-G delivers 10GBASE-T performance in a CMR-rated U/UTP construction designed for vertical riser pathways in multi-story commercial buildings. This 1000ft pull box of green-jacketed Cat6A cable uses 23 AWG solid copper conductors optimized for permanent link installations supporting IP cameras, access points, and PoE++ devices at distances up to 100 meters. The unshielded twisted-pair design simplifies termination and reduces material cost in environments where EMI is managed through proper pathway design rather than cable shielding, making it the practical choice for integrators balancing performance requirements against installation labor and project budgets.

Key Features

• Cat6A performance certified to 500 MHz for 10GBASE-T applications and future-proof bandwidth headroom
• CMR riser rating (UL 1666) approved for vertical runs between floors in non-plenum spaces
• U/UTP unshielded construction eliminates bonding/grounding requirements and reduces termination time by 30-40% vs shielded alternatives
• 23 AWG solid bare copper conductors minimize DC resistance (9.38 Ω per 100m max) for extended PoE reach and lower voltage drop
• Green PVC jacket enables color-coded network segmentation (cameras, access control, guest networks) for faster moves/adds/changes
• 1000ft pull box packaging with interior payout design prevents kinking and maintains minimum bend radius during installation
• TIA-568.2-D and ISO/IEC 11801 compliant for standards-based infrastructure backed by Panduit's 25-year system warranty when installed per guidelines

This cable's U/UTP construction uses four unshielded twisted pairs with precise geometry to achieve Cat6A alien crosstalk specifications without foil or braid shielding. Each pair maintains consistent twist rates and balanced impedance across the 500 MHz spectrum, delivering the margin needed for 10GBASE-T error-free transmission even in bundled configurations. The 23 AWG solid copper conductors provide the mechanical stiffness required for punch-down terminations into 110 IDC blocks and keystone jacks, while the 0.0226-inch conductor diameter keeps DC loop resistance below 25 ohms per 100-meter link—critical for integrators pushing 60W PoE++ to PTZ cameras or multi-sensor devices at maximum distance. The green PVC jacket is UV-stabilized and flame-retardant per UL 1666 riser testing, which subjects the cable to a 154,000 BTU gas flame in a two-story shaft to verify it won't propagate fire between floors. Unlike plenum-rated cables that cost 40-60% more, CMR construction delivers the fire safety required by NEC 800.113 for risers while using lower-cost materials that reduce both purchase price and the stiffness that complicates pulls through congested pathways.

Deploy this cable in vertical shafts, elevator cores, IDF-to-IDF backbone runs, and floor-to-floor camera drops where NEC Article 800 permits riser-rated cables and the environment doesn't demand shielding for EMI protection. U/UTP excels in commercial offices, retail centers, healthcare clinics, and educational buildings where conduit and cable tray provide inherent separation from EMI sources like fluorescent ballasts and variable-frequency drives. For installations with documented EMI concerns—data centers with dense power distribution, manufacturing floors with motor controllers, or outdoor runs near high-voltage lines—specify Panduit's F/UTP or S/FTP shielded Cat6A alternatives instead. The 1000ft length is optimized for typical IDF service areas; for horizontal runs averaging 200-250 feet including vertical drops and slack, a single box covers three to four camera locations with minimal waste. Integrators should maintain the 1-inch minimum bend radius (four times the 0.25-inch cable OD) during installation and verify punch-down terminations don't untwist pairs beyond the 0.5-inch maximum—both factors that preserve the electrical balance required for alien crosstalk margins.

The Pan-Net sub-brand positions this cable within Panduit's value-tier structured cabling portfolio, balancing third-party verified performance against competitive pricing for projects where the customer prioritizes standards compliance and manufacturer accountability over premium features like low-smoke jackets or enhanced pull tensions. When installed with Panduit's Cat6A Mini-Com jacks, copper patch panels, and certified patch cords as a complete channel, this cable qualifies for Panduit's 25-year application assurance and product warranty—a guarantee that covers both component defects and system performance to TIA-568.2-D limits, giving integrators the documentation needed to satisfy customer acceptance testing and close out projects with confidence that the infrastructure will support both current IP devices and the higher-bandwidth protocols that emerge over the installation's 15-20 year service life.
