Panduit CP-991-KIT4 12 AWG Ferrule Kit

Overview

The Panduit CP-991-KIT4 is a specialized kit containing 12 AWG wire ferrules designed for terminating stranded conductors. This kit ensures a clean, consolidated wire end, preventing stray strands that can cause shorts or poor connections. It's critical for high-density terminal blocks, screw terminals, and push-in connectors where conductor integrity is paramount, particularly in control panels and industrial automation systems. The CP-991-KIT4 addresses the need for reliable termination when working with smaller gauge stranded wire, ensuring consistent performance and simplifying installation.

Compatibility

This kit is designed for use with 12 AWG stranded copper conductors. It is compatible with Panduit's range of terminal blocks, connectors, and wire management solutions that accept ferruled conductors. While specific compatibility depends on the terminal's maximum wire size and ferrule acceptance, these ferrules are engineered to meet industry standards for secure termination in control systems, power distribution, and automation equipment.

Installation Notes

Proper installation requires a Panduit crimping tool (sold separately) designed for the specified ferrule size. Ensure the stranded wire is fully inserted into the ferrule before crimping. The crimp should be firm, consolidating the strands without damaging the conductor. Torque specifications for the terminal block or connector must be followed to ensure a secure connection. Use of the correct tool is essential for achieving UL and CSA certifications for the termination.
