ACTi A314 vs i-PRO S15600-V2LN: Specification Comparison
Both the ACTi A314 and i-PRO WV-S15600-V2LN are 6MP fixed outdoor IR bullet cameras aimed at perimeter and site surveillance. They occupy the same resolution class and share a core feature set — H.265 compression, ONVIF compliance, IR night vision, and rated vandal resistance — making them a legitimate cross-shop for integrators specifying outdoor fixed bullets. Key differentiators include lens type, WDR ceiling, IP ingress rating, AI analytics depth, sensor size, audio capability, and warranty terms.
In This Guide
How do the imaging specs compare?
The ACTi A314 uses a 1/2.4" sensor with a fixed 2.8 mm lens, delivering a fixed field of view with no optical zoom adjustment. Its minimum illumination is 0.003 lux in color mode and 0 lux with IR active, and its IR LEDs reach 65 m at 850 nm. Its WDR is rated at 150 dB (Extreme WDR). The i-PRO WV-S15600-V2LN uses a larger 1/1.8" CMOS sensor and a motorized 2.0x varifocal lens covering a horizontal FOV of 53° (tele) to 104° (wide), with motorized focus and an extra digital zoom of 2.0x–6.0x at 720p. Its minimum illumination is specified at 0.03 lux (B&W, 50 IRE, F1.5, 1/30s), and its IR LEDs reach 70 m (30 IRE) / 50 m (50 IRE). WDR is rated at up to 132 dB (Super Dynamic, level 30 or above, 15 fps).
On sensor size and lens flexibility, the i-PRO holds a clear advantage: the 1/1.8" sensor is physically larger than the A314's 1/2.4", generally yielding better light capture, and the motorized varifocal lens allows on-site FOV adjustment without changing optics. The A314 counters with a 150 dB WDR rating versus 132 dB for the i-PRO, and a lower specified minimum illumination (0.003 lux color vs. 0.03 lux B&W for the i-PRO) — though note these figures use different measurement conditions and are not directly equivalent. Both cameras operate at up to 30 fps at full 6MP resolution. The i-PRO also publishes DORI distances: at wide-end, detect at 52 m and identify at 5.2 m; at tele, detect at 133.5 m and identify at 13.3 m — no equivalent DORI data is provided in the A314 spec.
What about installation and environment?
The ACTi A314 carries an IP68 ingress rating (dust-tight and continuous submersion protection) and IK10 impact resistance. The i-PRO WV-S15600-V2LN is rated IP66 and NEMA 4X (dust-tight and strong-jet water resistant, but not rated for submersion) and also IK10. For sites subject to flooding, washdown, or temporary submersion, the A314's IP68 is a meaningful step above IP66. Both cameras share an operating temperature range of -40°C to +60°C. The i-PRO adds a wind resistance rating of up to 40 m/s (~89 mph) and an active anti-condensation system (Temish element, heater, and moisture absorption gel); the A314 spec does not document equivalent wind or condensation-control features.
Power input differs: the A314 spec lists both DC 12V and PoE Class 3 (IEEE 802.3af), though the product header also references PoE++ (802.3bt) — the body of the spec consistently cites 802.3af/Class 3, so buyers should verify with ACTi. The i-PRO is powered by DC 12V (1.0A) or PoE 802.3af and is specified as PoE Class 0. Physically, the A314 is significantly smaller (71×71×170 mm) versus the i-PRO (ø133×133×383 mm, approx. 2.4 kg), making the A314 more suitable for discreet installations or limited mounting clearance. The i-PRO supports wall and ceiling mount configurations with defined pan/tilt/yaw ranges; the A314 spec lists pole mount as the primary mount type. The i-PRO also includes a composite video monitor output for on-site optical alignment.
Which fits your VMS and analytics better?
Both cameras support ONVIF Profiles S, G, T, and M, providing broad VMS compatibility. The ACTi A314 offers Deep Learning Processing Unit (DLPU)-based analytics and Video Motion Detection (VMD); no audio input or output is documented in its spec. The i-PRO WV-S15600-V2LN includes AI Video Motion Detection, Scene Change Detection, Audio Detection, and AI Sound Classification covering gunshot, yell, vehicle horn, and glass break events. It also provides two-way audio via 3.5 mm stereo input and output jacks, up to 8 VMD areas, 8 privacy zones, and 8 VIQS zones — all absent from the A314 spec.
On-board storage is supported on the i-PRO via SDXC/SDHC/SD card (H.265/H.264 and JPEG recording modes including pre/post alarm and schedule recording); the A314 spec does not document local SD storage. The i-PRO is secured to FIPS 140-2 Level 3 with NXP SE050F hardware security element, HTTPS, and 802.1X; the A314 lists UL Taiwan IoT Cybersecurity Certification and ONVIF compliance but does not cite FIPS or hardware security element equivalents. The i-PRO supports up to 14 simultaneous users and nine GUI languages; comparable figures are not provided for the A314. The i-PRO runs on the Ambarella CV22 SoC, which is documented; no SoC is specified for the A314.
Which should you choose: the A314 or the S15600-V2LN?
Our take: The i-PRO WV-S15600-V2LN is the stronger choice when installation flexibility, analytics depth, and enterprise integration are priorities. Its 1/1.8" sensor is physically larger than the A314's 1/2.4" sensor, providing a meaningful light-collection advantage; its motorized varifocal lens (53°–104° FOV) eliminates the fixed-angle constraint of the A314's 2.8 mm fixed lens; and its IR reach extends to 70 m versus the A314's 65 m. The i-PRO also adds two-way audio, AI sound classification (gunshot, glass break, vehicle horn, yell), on-board SD recording, FIPS 140-2 Level 3 security, and a 5-year warranty versus the A314's 3-year term. The A314 holds advantages in ingress protection (IP68 vs. IP66), published WDR rating (150 dB vs. 132 dB), specified low-light sensitivity (0.003 lux color vs. 0.03 lux B&W under different test conditions), and a significantly smaller, lighter footprint suited to discreet or constrained mounting. Choose the A314 for submersion-risk or space-constrained deployments; choose the i-PRO where lens adjustability, audio, and deep analytics are required.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | ACTi A314 | i-PRO S15600-V2LN |
|---|---|---|
| Resolution | 6MP | 6MP |
| Image Sensor | 1/2.4" CMOS | 1/1.8" CMOS |
| Lens / Focal Length | 2.8 mm fixed | 4.3–8.6 mm motorized varifocal (2.0x optical zoom) |
| Horizontal FOV | Not specified | 53° (tele) – 104° (wide) |
| Min. Illumination | 0.003 lux (color); 0 lux (IR on) | 0.03 lux (B&W, 50 IRE, F1.5, 1/30s) |
| IR Range | 65 m (850 nm) | 70 m (30 IRE) / 50 m (50 IRE) |
| WDR | 150 dB (Extreme WDR) | 132 dB (Super Dynamic, level ≥30, 15 fps) |
| Max Frame Rate | 30 fps | 30 fps |
| Video Compression | H.265, H.264, MJPEG | H.265, H.264, MJPEG |
| IP Rating | IP68 | IP66, NEMA 4X |
| IK / Impact Rating | IK10 | IK10 |
| Operating Temperature | -40°C to +60°C | -40°C to +60°C (power-on: -30°C to +60°C) |
| Power Input / PoE | DC 12V; PoE Class 3 (802.3af) — header also references 802.3bt; verify with ACTi | DC 12V 1.0A; PoE 802.3af (Class 0) |
| Edge Storage | — | SDXC/SDHC/SD (H.265/H.264/JPEG) |
| Audio | — | 3.5 mm stereo input and output; half/full duplex; G.726/G.711/AAC-LC |
| AI / Edge Analytics | DLPU; VMD | AI VMD; Scene Change Detection; Audio Detection; AI Sound Classification (gunshot, yell, vehicle horn, glass break) |
| ONVIF Profiles | S, G, T, M | S, G, T, M |
| Dimensions (W×H×D) | 71 × 71 × 170 mm | ø133 × 133 × 383 mm |
| Weight | Not specified | Approx. 2.4 kg (5.3 lbs) |
| Warranty | 3 years | 5 years |
Frequently Asked Questions
Which should you choose: the A314 or the S15600-V2LN?
The i-PRO WV-S15600-V2LN is the stronger choice when installation flexibility, analytics depth, and enterprise integration are priorities. Its 1/1.8" sensor is physically larger than the A314's 1/2.4" sensor, providing a meaningful light-collection advantage; its motorized varifocal lens (53°–104° FOV) eliminates the fixed-angle constraint of the A314's 2.8 mm fixed lens; and its IR reach extends to 70 m versus the A314's 65 m. The i-PRO also adds two-way audio, AI sound classification (gunshot, glass break, vehicle horn, yell), on-board SD recording, FIPS 140-2 Level 3 security, and a 5-year warranty versus the A314's 3-year term. The A314 holds advantages in ingress protection (IP68 vs. IP66), published WDR rating (150 dB vs. 132 dB), specified low-light sensitivity (0.003 lux color vs. 0.03 lux B&W under different test conditions), and a significantly smaller, lighter footprint suited to discreet or constrained mounting. Choose the A314 for submersion-risk or space-constrained deployments; choose the i-PRO where lens adjustability, audio, and deep analytics are required.
Is the ACTi A314 or i-PRO S15600-V2LN better for low-light performance?
The A314 specifies 0.003 lux (color) and 0 lux with IR active; the i-PRO specifies 0.03 lux (B&W, 50 IRE, F1.5, 1/30s). These figures use different measurement conditions — color vs. B&W, different IRE levels and apertures — so they are not directly equivalent. The i-PRO's larger 1/1.8" sensor (vs. the A314's 1/2.4") generally supports better optical light capture, and its IR range is 70 m vs. the A314's 65 m. Buyers should request controlled side-by-side testing under their specific site conditions before drawing conclusions solely from published lux figures.
Which camera has better weather and vandal protection — the A314 or the S15600-V2LN?
Both cameras achieve IK10 impact resistance. On ingress protection, the A314 is rated IP68 (dust-tight and rated for continuous submersion), while the i-PRO is rated IP66 and NEMA 4X (dust-tight and protected against powerful water jets, but not submersion). For sites with flooding risk or high-pressure washdown cycles, the A314's IP68 rating is the more stringent standard. The i-PRO adds a documented anti-condensation system (Temish element, heater, and moisture absorption gel) and a wind resistance rating of up to 40 m/s; the A314 spec does not document equivalent features.
Does either camera support on-board storage and two-way audio?
Yes — the i-PRO WV-S15600-V2LN supports both. It accepts SDXC/SDHC/SD cards for H.265/H.264 and JPEG local recording (manual, alarm-triggered, scheduled, and network-failure backup modes) and includes 3.5 mm stereo audio input and output jacks with half- and full-duplex modes. The ACTi A314 spec does not document SD card storage support or audio input/output capability. If on-board recording or two-way audio is a project requirement, only the i-PRO satisfies it based on published specifications.
