ACTi A213 vs Geovision BX5700F-8010: Specification Comparison
Both the ACTi A213 and Geovision BX5700F-8010 are 5MP fixed box cameras aimed at integrators needing a modular, lens-interchangeable platform for indoor and outdoor surveillance. This comparison examines how their imaging capabilities, installation requirements, and VMS integration features differ across the specifications provided — giving installers and IT buyers a direct, spec-grounded view before committing to either platform.
In This Guide
How do the imaging specs compare?
The ACTi A213 delivers 5MP resolution at up to 30 fps (2592×1944) or 60 fps at 1080p with WDR disabled, backed by a rated 150dB Extreme WDR. Minimum illumination is specified at 0.018 lux in color and 0.001 lux in B/W, with active IR for low-light operation. The lens is CS-mount interchangeable, with a 2.8mm f/2.8 fixed lens included, and the datasheet lists a 2.8–12mm focal-length range supported by that mount system.
The Geovision BX5700F-8010 is also rated at 5MP with WDR, but the WDR performance level in dB is not specified in the provided data. Minimum illumination is described only as 'Low Lux' — no lux figure is given. The lens is a fixed 2.95mm unit with no interchangeability noted. IR / Day-Night operation is indicated, but IR range and illumination cutoff values are absent from the provided specifications. Buyers requiring precise low-light or WDR numbers for the Geovision model will need to consult its datasheet directly.
What about installation and environment?
The ACTi A213 carries an IP66 weatherproof rating, accepts DC 12V or PoE Class 3 (IEEE 802.3af/at), and is rated for –10°C to 50°C (14°F to 122°F). It supports wall, ceiling, pole, corner, and rack mounting and ships with a 2-meter cable. Weight is 420 g. Certifications include CE Class A and FCC Class A. No IK impact rating is listed in the provided specs.
The Geovision BX5700F-8010 lists PoE as its power source but does not specify the PoE class (802.3af vs 802.3at), IP rating, IK rating, operating temperature range, dimensions, or weight in the provided data. The form factor is described as a modular box. Installers planning outdoor or temperature-extreme deployments should verify environmental ratings directly with Geovision before specifying this unit.
Which fits your VMS and analytics better?
The ACTi A213 is ONVIF-compliant across Profiles S, G, T, and M, providing broad VMS compatibility including event and metadata streams. It carries an on-board Deep Learning Processing Unit (DLPU) supporting face, people, and vehicle detection alongside VMD, reducing server-side processing load. Audio capabilities include a built-in microphone, dedicated mic-in, line-in, and line-out — a relatively complete audio I/O set for a box camera at this resolution tier.
The Geovision BX5700F-8010's provided specifications note ONVIF compatibility in a card bullet but do not confirm which ONVIF profiles are supported. No edge analytics capability is listed in the provided data. Audio support is not mentioned. On-board or edge storage support (SD card slot) is not specified for either model in the provided data, so buyers requiring local redundant recording should verify this with both manufacturers.
Which should you choose: the A213 or the BX5700F-8010?
Our take: The A213 is the stronger choice when precise imaging performance, ONVIF profile depth, and edge analytics are decision criteria. Concretely: the A213 specifies a 150dB Extreme WDR rating versus an unquantified 'WDR' on the BX5700F-8010; minimum illumination is documented at 0.018 lux color / 0.001 lux B/W on the A213 versus only 'Low Lux' for the Geovision unit; and the A213 confirms ONVIF Profiles S, G, T, and M while the BX5700F-8010's profile support is unconfirmed in the provided specs. The A213 also adds a DLPU for on-camera deep learning analytics and a full audio I/O suite — neither of which appears in the Geovision data. The BX5700F-8010 may be suitable for cost-sensitive, integrator-managed deployments where detailed specs are confirmed separately, but the A213 presents a more completely documented specification set for confident project quoting.
Side-by-Side Comparison
Spec-for-spec, from manufacturer data.
| Specification | ACTi A213 | Geovision BX5700F-8010 |
|---|---|---|
| Resolution | 5MP | 5MP |
| Max Frame Rate | 30 fps @ 2592×1944; 60 fps @ 1080p (WDR off) | Not specified |
| Lens / Focal Length | CS-mount interchangeable; 2.8mm fixed included (2.8–12mm range) | 2.95mm fixed |
| Min Illumination | 0.018 lux (Color, 30 IRE); 0.001 lux (B/W) | Low Lux (no value specified) |
| IR / Night Vision | Active IR | Day-Night IR (range not specified) |
| WDR | Extreme WDR 150dB | WDR (dB level not specified) |
| Video Compression | H.265 Adaptive Stream; H.264; MJPEG | H.265 |
| ONVIF | Profiles S, G, T, M | Noted in bullet; profiles not specified |
| Edge Analytics | DLPU (Deep Learning); VMD | — |
| Audio | Built-in mic; mic-in; line-in; line-out | — |
| IP Rating | IP66 | — |
| Operating Temperature | –10°C to 50°C (14°F to 122°F) | Not specified |
| Power Input / PoE Class | DC 12V or PoE Class 3 (IEEE 802.3af/at) | PoE (class not specified) |
| Weight | 420 g (0.926 lb) | Not specified |
| Warranty | 3 Years | Not specified |
Frequently Asked Questions
Which should you choose: the A213 or the BX5700F-8010?
The A213 is the stronger choice when precise imaging performance, ONVIF profile depth, and edge analytics are decision criteria. Concretely: the A213 specifies a 150dB Extreme WDR rating versus an unquantified 'WDR' on the BX5700F-8010; minimum illumination is documented at 0.018 lux color / 0.001 lux B/W on the A213 versus only 'Low Lux' for the Geovision unit; and the A213 confirms ONVIF Profiles S, G, T, and M while the BX5700F-8010's profile support is unconfirmed in the provided specs. The A213 also adds a DLPU for on-camera deep learning analytics and a full audio I/O suite — neither of which appears in the Geovision data. The BX5700F-8010 may be suitable for cost-sensitive, integrator-managed deployments where detailed specs are confirmed separately, but the A213 presents a more completely documented specification set for confident project quoting.
Is the A213 or BX5700F-8010 better for low-light performance?
Based on the provided specifications, the ACTi A213 is better documented for low-light use: it lists a minimum illumination of 0.018 lux (color) and 0.001 lux (B/W) with active IR. The Geovision BX5700F-8010 only states 'Low Lux' and 'Day-Night' with no numeric illumination value in the available data, so a direct comparison cannot be made from specs alone.
Can either camera work with my existing VMS via ONVIF?
The ACTi A213 confirms ONVIF compliance across Profiles S, G, T, and M, covering live stream, recording, event, and metadata integration. The Geovision BX5700F-8010 references ONVIF compatibility in a product bullet but the provided specification data does not confirm which profiles are supported. Verify BX5700F-8010 profile support with Geovision or your VMS vendor before deploying.
Does either camera support changing the lens in the field?
Yes — the ACTi A213 uses a CS-mount interchangeable lens system, with a 2.8mm f/2.8 lens included, accepting lenses across the 2.8–12mm range. The Geovision BX5700F-8010 is listed with a fixed 2.95mm lens; no interchangeable lens capability is noted in the provided specifications.
