Comelit UT9193 Surface-Mounted Rainshield Wall Housing
The Comelit UT9193 is a surface-mounted wall enclosure designed to protect surveillance equipment from weather exposure in outdoor and semi-covered deployments. This is an accessory housing, not a camera — it shields and powers compatible IP cameras on building facades, loading docks, transit shelters, and covered outdoor areas where wall mounting and weatherproofing are operational requirements.
Key Features
- PoE+ Power Support (802.3at): Single Ethernet cable delivers both network connectivity and power to compatible cameras — eliminates the need for separate 12VDC runs or AC outlets near the mounting location. Simplifies installation on retrofit projects where running new conduit is expensive or structurally impractical.
- 4MP Camera Compatibility: The power envelope supports 4MP camera installations without thermal constraint or power starvation. Adequate for license plate legibility, facial recognition at entry points, and general perimeter documentation.
- Surface-Mount Wall Configuration: No structural drilling, conduit chasing, or embedded boxes required. Attaches directly to existing concrete, brick, or metal fascia using standard fasteners — reduces installation time and cost on occupied facilities.
- Rainshield Enclosure Design: Protects optics and connectors from direct rain, salt spray, and wind-driven moisture. Not intended for full submersion or extreme washdown environments; verify IP rating in the datasheet before deploying near process water or high-pressure wash areas.
- Thermal Management: Enclosure geometry allows heat dissipation from powered equipment, preventing thermal shutdown in direct sunlight. Confirm operating temperature range against your climate zone — shade or reflective coating may be needed in extreme heat.
- ONVIF Compliance: Compatible with standard ONVIF-compliant IP cameras in the Comelit surveillance ecosystem and third-party vendors. Verify camera form factor, connector type, and thermal output against housing dimensions before procurement.
Integration & Compatibility
The UT9193 is compatible with Comelit IP cameras and standard ONVIF-compliant models within the PoE+ power envelope. Before deployment, confirm the mounted camera's physical dimensions, connector orientation, and power draw — oversized cameras or right-angle connectors may not fit the housing footprint. If integrating with a network video recorder or PoE switch, verify the switch supplies sufficient PoE+ capacity: a single 802.3at port provides up to 30W, but some 4MP cameras with IR or heaters consume 15–20W, leaving limited headroom for expansion.
The UT9193 is not a powered enclosure — it is a passive weatherproof mount. All network and power traffic routes through a single Ethernet drop, so plan your cabling topology accordingly. Daisy-chaining multiple housings on one PoE port will overload the power budget.
When to Choose a Different Model
If your deployment requires full IP67 rating for submersion or high-pressure water jets, or if you need larger form-factor flexibility for PTZ cameras or multiple sensors, contact Comelit for higher-protection or modular housing variants within the same product line.
Frequently Asked Questions
Q: Can I mount the UT9193 on a ceiling?
A: The UT9193 is designed for wall surface mounting. Ceiling mounting may require custom brackets and may affect thermal performance. Consult the installation guide or contact Comelit technical support for ceiling-mount feasibility.
Q: Does the UT9193 include cable glands for outdoor conduit?
A: The housing accommodates a single Ethernet drop via a weatherproof connector. If conduit entry is required, verify that the specified connector type matches your outdoor cabling standard (e.g., M20 or ½-inch NPT).
Q: What is the IP rating of the UT9193?
A: Consult the Comelit UT9193 datasheet for the exact IP and IK ratings. This determines suitability for your environment — direct rain (IP65+), salt spray coastal areas (often IP66+), and mechanical impact resistance (IK08 minimum for accessible outdoor mounting).
Q: Will the UT9193 work with non-Comelit ONVIF cameras?
A: Yes, provided the camera complies with ONVIF Profile S or higher, has a compatible connector, and draws power within the PoE+ 30W limit. Verify form factor and connector type fit before purchase.
Q: Is separate power required for the UT9193?
A: No. PoE+ (802.3at) via a single Ethernet cable supplies all power and network connectivity. No 12VDC transformer or AC outlet needed.
Q: Can I use PoE (802.3af) instead of PoE+ for the UT9193?
A: Standard PoE provides up to 13W, which may be insufficient for some 4MP cameras with IR or built-in heaters. PoE+ (30W) is recommended to ensure adequate power margin and avoid thermal throttling under peak load.
Ted PerryPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The UT9193 is a straightforward weatherproof mount for outdoor wall-mounted 4MP camera deployments where PoE+ availability simplifies cabling. Surface mounting and single-cable provisioning make it an efficient retrofit choice for loading docks, warehouse side entries, and transit shelters — locations where running conduit or buried power would add weeks and cost to a project.
Technical Highlights:
- PoE+ Power (802.3at, up to 30W): Eliminates the need for a separate 12VDC supply run. A single Ethernet drop delivers both connectivity and power, which cuts installation labor and reduces failure points on outdoor runs where exposed power cables corrode or attract animal damage.
- 4MP Camera Support: Adequate power envelope for standard 4MP fixed cameras without IR heaters. If the camera draws 18–20W (common for 4MP + IR), confirm power margin headroom with your PoE switch capacity plan.
- Rainshield Enclosure: Protects optics and connectors from direct rainfall and wind-driven spray. Not full submersion rated — if you need to hose down the enclosure or mount it in a wet process area, specify a higher IP rating (IP67+) and test thermal buildup in your climate.
Deployment Considerations:
- Form Factor Lock-In: The housing interior dimensions constrain camera size and connector orientation. Measure the mounting camera's depth and connector type before procurement — oversized boxes or right-angle RJ-45 connectors will not fit.
- Thermal Margin: Surface-mount location and enclosure geometry affect heat dissipation. In direct afternoon sun (South or West exposure), verify that the camera's operating temperature range (typically 0–50°C) has headroom. Some climates may require a reflective coating or shade structure.
- Single Drop Per Port: Do not daisy-chain multiple UT9193 housings on one PoE+ port. Each camera draws 12–20W; two cameras will exceed the 30W IEEE 802.3at limit and trigger shutdown.
Deploy the UT9193 where wall mounting and single-cable simplicity outweigh the need for higher IP ratings or larger form factors. Typical wins: retail warehouse perimeter, loading dock, covered transit platform, or service entry where power availability is limited and retrofit speed matters.
