Code Blue Z00050-01 Centry Top Plate Dark Gray
Overview
The Z00050-01 is a dark gray top plate assembly for Code Blue Centry help point installations. This accessory houses the camera module, microphone, speaker, and control interface for emergency communication and surveillance in institutional and commercial settings. It mounts flush or surface and integrates a ¼" CMOS sensor with 125° wide-angle optics, capturing 1080p video at up to 30 fps. The plate includes three contact closure inputs and three outputs, enabling integration with door locks, strobes, and external alert systems—essential for coordinated emergency response in schools, hospitals, and corporate facilities. Built to NEMA 3 specifications for indoor use with conformal-coated PCB and piezoelectric buttons designed to resist mechanical wear and environmental stressing.
Compatibility
The Z00050-01 top plate is designed exclusively for Code Blue Centry help point camera systems. It operates on PoE (802.3af) power delivery, drawing standard power from enterprise network switches without dedicated power supplies. Video output supports H.264, MPEG-4, and Motion JPEG compression—compatible with ONVIF-compliant VMS platforms, Milestone Xprotect, Genetec, and other standard network video management systems used in institutional deployments. The three Ethernet ports enable daisy-chaining or independent network connections. The contact closure architecture (3 in / 3 out) interfaces directly with access control panels, fire alarm systems, and relay modules common in integrated security installations.
Installation Notes
Surface mounting: 4.75" W × 10.25" H × 2.875" D. Flush-mount option: 4.5" W × 10" H × 3.125" D. Operating temperature range -40° C to 70° C suits indoor institutional environments; not rated for outdoor or high-humidity spaces. The piezoelectric button design eliminates mechanical switch sticking and jamming—critical in high-traffic emergency communication zones. ADA Braille text and LED station beacon are factory-integrated. Memory: 4 GB RAM. No external configuration required beyond standard PoE network provisioning and VMS integration via ONVIF discovery or static IP assignment.
What's in the Box
- 1x Z00050-01 Centry Top Plate Dark Gray (assembled)
- Mounting hardware (surface and flush-mount templates included per standard Code Blue installation kit)
