Cipherlab A97AM1CLN31UP 9700 WEH Laser 30key 3600mAh Pistol USB

CipherLab A97AM1CLN31UP Rugged Handheld Mobile Computer Scanner

Overview

The CipherLab A97AM1CLN31UP is a Windows-based handheld mobile computer built for warehouse, logistics, and field operations requiring real-time barcode scanning and data capture. The 2D laser scan engine handles both near and far range 1D and 2D barcodes—reducing the need for device repositioning during fast-moving shipment processing. The 3.5-inch sunlight-readable touchscreen (VGA/QVGA TFT) with resistive panel means operators can work outdoor loading docks or brightly lit receiving areas without screen washout. IP65 rating and SGS-certified 1.8m drop protection to concrete (MIL-STD-810G) make this unit suitable for high-impact environments where ruggedness is not optional. The A97AM1CLN31UP ships with a 3600mAh battery, delivering 13 hours of continuous operation—enough for a full warehouse shift without mid-day charging.

Connectivity and Data Handling

Cisco CCXv4 certified IEEE 802.11 a/b/g/n WLAN ensures reliable handoff across warehouse Wi-Fi networks without loss of transaction data. Bluetooth Class II V2.1 with Enhanced Data Rate provides backup short-range connectivity to paired peripherals (scales, label printers, dock equipment). The TI OMAP 3730 1GHz processor and 512MB DDR SDRAM run Windows CE 6.0 R3 or Windows Embedded Handheld 6.5.3—operating systems built for mobile enterprise applications. 4GB NAND FLASH storage accommodates application binaries and local transaction logs; the microSD slot (up to 32GB SDHC) adds capacity for high-volume capture operations without network dependency.

Durability and Physical Design

The 447-gram (3600mAh) form factor balances scanning reach with sustained grip comfort across an 8-hour shift. Rubberized pistol grip and reinforced trigger reduce fatigue during high-frequency scanning. The 30-key alphanumeric keypad with LED backlight supports inventory lookup, order confirmation, and manual SKU entry in low-light receiving bays. IP65 protection handles dust, light rain, and warehouse washdown spray without component failure. Drop certification to 1.8m and tumble testing (500 drops from 1m, 1000 from 0.5m) demonstrates real-world durability rather than lab minimums.

Compatibility

The A97AM1CLN31UP integrates with enterprise warehouse management systems (WMS), transportation management systems (TMS), and custom mobile applications running on Windows CE/Embedded Handheld platforms. Direct USB and Bluetooth connectivity supports docking stations, label printers, and weight scales. WLAN connectivity enables real-time inventory sync with backend ERP or WMS databases. Verify your WMS vendor has certified mobile support for Windows Embedded Handheld before final deployment.
