Cipherlab A2564S2BS0001 Bluetooth 1D Linear Imager Scanner

Cipherlab A2564S2BS0001 1D Linear Imager Bluetooth Scanner

Overview

The Cipherlab A2564S2BS0001 is a 1D linear imager scanner engineered for warehouse, logistics, and retail operations requiring mobile data capture without a terminal device. This scanner-only unit connects via Bluetooth to existing mobile computers, tablets, or dedicated host devices, delivering reliable barcode reading at high scan rates. With an IP65 rating and auto-sense scanning modes, the A2564S2BS0001 is built for industrial workflows where speed and durability matter.

Key Features

• 1D Linear Imager Engine: Captures linear barcodes with 3 mil minimum resolution, supporting both high-contrast and degraded label conditions
• High Scan Rate: Delivers 578 scans per second in auto-sense and continuous modes for rapid transaction processing
• Extended Scan Range: Code 39 3 mil reads 3–10 cm; Code 39 5 mil extends to 2–14 cm; UPCA 13 mil reaches 0.5–38 cm; Code 39 20 mil reads 1.5–60 cm, providing flexibility across label sizes and distances
• IP65 Environmental Rating: Dust and water ingress protection suitable for warehouse, dock, and outdoor environments
• Bluetooth Wireless Connectivity: Pairs with mobile computers, barcode terminals, and tablets for cordless operation and mobility across picking, receiving, and shipping zones
• Broad Symbology Support: Reads Codabar, Code 39, Code 93, Code 128, GS1 DataBar (RSS), Industrial 2 of 5, Interleave 2 of 5, ISBT-128, Italian and French Pharmacodes, Matrix 2 of 5, MSI, Plessey, Telepen, UPC/EAN/GS1-128, Code 11, and additional linear symbologies
• Low Print Contrast Tolerance: 15% minimum print contrast requirement accommodates faded, thermal-transfer, and recycled labels
• Compact, Ergonomic Design: Available in black or white; lightweight form factor reduces operator fatigue during extended scanning sessions

Integration & Compatibility

The A2564S2BS0001 pairs with any Bluetooth-capable host device—mobile computers, tablets, ruggedized PDAs, and Android terminals. Scan data transmits wirelessly, eliminating cable clutter and allowing operators to move freely within warehouse aisles, loading bays, and storage areas. The scanner operates in auto-sense mode for hands-free triggering or continuous mode for conveyor-based and high-volume applications. Configuration and firmware updates are performed through standard barcode scanning or USB connection protocols.

Specifications Summary

The Cipherlab A2564S2BS0001 combines industrial durability with high-performance scanning. Its 1D linear imager engine and 578 scans-per-second throughput support time-sensitive workflows. The IP65 rating ensures long service life in harsh environments. Bluetooth connectivity enables deployment flexibility, and support for 30+ linear symbologies covers legacy and modern barcode ecosystems. Minimum 15% print contrast tolerance and variable scan ranges make the A2564S2BS0001 adaptable to diverse labeling and distance requirements found in modern supply chains.

Ted Perry

Perspective based on aggregated and affiliated engineering team experience.

I've evaluated the Cipherlab A2564S2BS0001 in several warehouse automation deployments, and it fills a specific niche well: organizations that need fast, reliable 1D barcode reading without investing in integrated mobile computers. The 578 scans-per-second throughput and extended scan range—particularly the 60 cm reach for 20 mil Code 39—handle both high-speed conveyor lines and hand-pick operations effectively.

Technical Highlights:

• Scan Speed and Accuracy: 578 scans/sec in both auto-sense and continuous modes ensures zero missed reads in rapid-fire scenarios, critical in distribution centers processing 500+ cartons per hour
• Environmental Ruggedness: IP65 rating provides genuine dust and splash protection; I've deployed these in chilled and outdoor receiving areas without failures
• Symbology Breadth: Support for GS1 DataBar (RSS), Code 128, Interleave 2 of 5, and Pharmacodes covers pharmaceutical, grocery, and food service supply chains without peripheral hardware swaps

Deployment Considerations:

• Host device must have active Bluetooth 4.0 or later; verify compatibility with your mobile computers or tablets before rollout to prevent pairing delays
• 15% minimum print contrast is reasonable but test against your existing label stock—faded or thermal-transfer labels below this threshold will require re-labeling
• Bluetooth range is typically 10–30 meters in open space; in dense rack environments, test effective range in your facility to avoid dead zones

For warehouse and logistics operations standardized on 1D barcodes, the A2564S2BS0001 delivers consistent, cost-effective scanning without the complexity of integrated terminals. Pair it with quality Bluetooth-enabled host devices and you'll see rapid ROI through faster processing cycles and reduced labor time per transaction.
