Panduit UTP6AX10BL Cat 6A 10ft Patch Cord

Panduit UTP6AX10BL Cat 6A UTP Patch Cord

The Panduit UTP6AX10BL delivers 10GBASE-T performance in a 10-foot unshielded twisted pair patch cord engineered for high-density data center and enterprise network deployments. Built with 24 AWG solid copper conductors and a slim 6.4mm diameter profile, this Cat 6A cable supports full 10 Gb/s throughput across all 500 MHz while maintaining headroom for alien crosstalk mitigation in congested rack environments. The integrated RapidID barcode system enables rapid port mapping and documentation, and the tangle-free modular plug latch design reduces snag incidents during moves, adds, and changes. Certified to exceed ANSI/TIA-568.2-D and ISO 11801 Class EA requirements, this patch cord supports IEEE 802.3bt Type 3 and Type 4 PoE applications up to 90 watts, making it suitable for high-power edge devices including PTZ cameras, access points, and PoE lighting.

Key Features

• 10 Gb/s transmission certified to 500 MHz per ANSI/TIA-568.2-D Category 6A and ISO 11801 Class EA standards
• 24 AWG solid copper conductors in U/UTP construction with internal foil tape for alien crosstalk control
• Slim 6.4mm (0.250") diameter cable body improves airflow and reduces pathway congestion in high-density racks
• Tangle-free latch mechanism on modular plugs prevents snags during cable pulls and simplifies MAC workflows
• Pre-installed RapidID barcodes integrate with Panduit RapidID software for automated port mapping and documentation
• IEEE 802.3af/at/bt Type 3 and Type 4 PoE support delivers up to 90 watts for high-power endpoint devices
• Compatible with both T568A and T568B wiring schemes for flexible deployment in mixed infrastructures
• CM flammability rating per UL 1863 and CSA C22.2 for general plenum and riser installations
• RoHS compliant construction meets environmental and procurement requirements for enterprise and government projects

Solid Conductor Construction for Permanent Link Performance
Unlike stranded-conductor patch cords commonly used for equipment connections, the UTP6AX10BL uses 24 AWG solid copper conductors—the same construction specified for permanent horizontal cabling. This design choice delivers two advantages: first, it maintains consistent insertion loss and return loss characteristics across the entire channel, eliminating the impedance discontinuity that occurs when transitioning from solid horizontal cable to stranded patch cord. Second, solid conductors exhibit lower DC resistance than equivalent-gauge stranded wire, reducing voltage drop on PoE circuits and enabling reliable power delivery to Type 3 (60W) and Type 4 (90W) powered devices at the full 10-foot length. The internal foil tape shields against alien crosstalk from adjacent cables in dense bundles, ensuring this patch cord meets the 10GBASE-T bit error rate threshold even in 48-port switch deployments with full port utilization. The 6.4mm overall diameter—30% slimmer than standard Cat 6A cables—reduces bundle cross-section in vertical managers and horizontal pathways, improving airflow around active equipment and lowering the risk of exceeding conduit fill ratios in retrofits.

RapidID Integration and Tangle-Free Latch for Operational Efficiency
Each UTP6AX10BL ships with a factory-applied barcode label compatible with Panduit's RapidID port mapping software, allowing technicians to scan patch cord endpoints during installation and automatically populate port schedules, DCIM records, and as-built documentation without manual data entry. This capability is particularly valuable in server virtualization projects and backbone aggregation deployments where accurate layer-1 records are critical for troubleshooting and change management. The modular plug's tangle-free latch uses a low-profile boot design that prevents the release tab from catching on adjacent cables when pulling cords through congested pathways or removing them from fully populated patch panels. This feature reduces the time required for adds, moves, and changes in production environments, and minimizes the risk of accidental disconnects when servicing neighboring ports. The plug termination meets IEC 60603-7 and ANSI/TIA-1096-A (formerly FCC Part 68) mechanical and electrical specifications, ensuring reliable mating with RJ45 jacks from any standards-compliant manufacturer.

Compliance and Application Fit
The UTP6AX10BL meets or exceeds all Category 6A channel performance requirements in ANSI/TIA-568.2-D across the 1–500 MHz spectrum, including insertion loss, return loss, near-end crosstalk (NEXT), alien near-end crosstalk (ANEXT), power sum alien near-end crosstalk (PSANEXT), and alien attenuation-to-crosstalk ratio (AACR-F). This certification ensures compatibility with 10GBASE-T Ethernet, 40GBASE-T aggregation links, and high-speed computing fabrics that rely on the full Cat 6A performance envelope. The cable's PoE support extends to IEEE 802.3bt Type 4 applications, making it suitable for powering enterprise access points, building automation controllers, LED lighting systems, and security cameras—including motorized PTZ models that can draw up to 90 watts under full load. For integrators working in mixed T568A/T568B environments or transitioning legacy installations, the UTP6AX10BL's wiring scheme compatibility eliminates the need to stock separate A-wired and B-wired inventory. UL and CSA certifications (File E129886) satisfy North American building codes, and RoHS compliance addresses material content restrictions in federal, state, and vertical-market procurement specifications.
