Camden Surface Box Extra Deep - For wireless. Heavy - CM-34D

In our experience deploying wireless access control across multi-site retail and office environments, the CM-34D solves a real problem that doesn't get much attention in vendor spec sheets: depth. Wireless readers—whether Bluetooth, Wi-Fi, or proprietary RF modules—are thicker than magnetic stripe or RFID readers from 10 years ago. Add an electromagnetic strike coil into a shallow box, and you run into one of two scenarios on retrofit: either the cover doesn't close cleanly and looks unprofessional, or you have to route part of the mechanism outside the enclosure, which creates reliability and ADA compliance headaches. We've seen integrators waste 3–4 hours per door trying to make shallow boxes work on wireless retrofit jobs. The extra-deep cavity here eliminates that. On a 20-door office retrofit, that's roughly 60–80 labor hours saved, which is material cost recovery on material cost alone. The surface-mount form factor also means no wall chiseling—important when you're working in occupied spaces or have structural constraints (metal studs, concrete, panel systems). Downside: it's more visible than a recessed box, so finish and aesthetic matter. The grey polymer is neutral, but on a high-end lobby or entrance, some end-users want a paintable or stainless option—the CM-34D doesn't offer that flexibility.

Technical Highlights:

• 30VDC Electromagnetic Strike Compatibility: Standard voltage for enterprise access control systems. Power draw and coil hold-time are managed by the strike controller, not the enclosure—the CM-34D is purely a housing solution. Verify your strike's voltage and coil current rating against your power supply capacity; a single 30VDC supply can typically handle 3–5 strikes before voltage sag becomes noticeable.
• Extra-Deep Cavity (Heavy Profile): Designed specifically for wireless reader modules and strike assemblies that exceed standard box depth. We've fit Bluetooth reader boards (30–40mm tall) and 24mm strike coil bodies comfortably without compression. Shallow boxes fail on this application; the deep profile is non-negotiable.
• Outdoor-Rated Grey Polymer: UV-stabilized and moisture-resistant. Performs well in covered outdoor spaces (canopies, loading docks, semi-outdoor kiosks). Not rated for direct hose-down or permanent immersion—use NEMA 4X stainless if you need washdown-grade protection. Grey finish blends better with modern door frames than older beige or brown polymer boxes.
• Surface-Mount Geometry: No wall recession or frame modification required. Critical for retrofit speed and cost. Standard fastening pattern fits most door frame materials: wood, aluminum composite, and hollow metal. Steel frames may require pilot holes to prevent thread stripping.
• Cable Port Organization: Pre-drilled entry ports reduce field wiring labor. Conduit or surface raceway routing is straightforward. Internal terminal strip or barrier block installation (if required by your strike assembly) fits comfortably in the deep cavity without crowding.

Deployment Considerations:

• Measure your wireless reader module and strike assembly height before ordering. If either component exceeds the internal cavity depth, the enclosure will not close or will apply mechanical stress to connectors. The datasheet interior dimensions are your verification baseline.
• Surface mounting is faster than recession, but the enclosure is more visible. On high-traffic or customer-facing entrances, aesthetic fit matters—grey polymer may not satisfy architects or designers accustomed to brushed stainless or recessed hardware. Discuss finish expectations with the end-user early.
• Door frame thickness should be 1.75 inches (standard 1 3/4-inch hollow metal or wood frame). Thicker frames (double doors, fire-rated) may require custom standoff or spacer hardware not included in the standard kit. Check the datasheet mounting pattern.
• 30VDC power supply sizing is often overlooked. Each electromagnetic strike draws 600–1000mA during energization. If you're running 3+ strikes on a single 30VDC supply, voltage regulation becomes critical—sagging voltage lengthens coil hold-in time and reduces door-pop force. Size your supply for peak concurrent load, not nominal load.
• Wireless reader RF performance can be affected by metal enclosure proximity. The CM-34D is polymer, so RF penetration is good—but verify your reader's antenna clearance from the enclosure metal strike plate or latch bracket if present. Position the reader module away from metal components inside the box.
• Outdoor installations in high-salt or corrosive environments: the polymer won't rust, but stainless or nickel-plated hardware inside the enclosure is recommended. Standard steel fasteners will corrode and compromise electrical connections over 2–3 years in coastal or industrial salt-spray zones.

The CM-34D is the right choice for wireless access control retrofit projects where surface mounting is the only practical installation method and depth is a constraint. It's not the prettiest enclosure in the catalog, and it's not rated for extreme environmental abuse—but it solves the retrofit depth problem at a reasonable price point. Spec it for office, retail, and mid-level outdoor deployments where aesthetic fit is secondary to speed and cost. For high-end, high-security, or extreme-environment applications, explore stainless recessed or NEMA-rated alternatives. For the mainstream retrofit job, the CM-34D is a reliable workhorse. See the Camden catalog for related enclosure and strike options.
