Camden CM-1000/37 SPST Maintained Contact Switch Heavy Duty 15A
The Camden CM-1000/37 is a surface-mount key switch designed for access control systems requiring manual keyed activation of door strikes and electromagnetic locks. Built with 1/4" die-cast aluminum construction and rated for 15A at 30 VDC, it delivers maintained contact closure — the switch holds position until the operator manually rotates the key back, eliminating the need to hold the key through the entire unlock cycle. This makes it ideal for emergency override scenarios, pedestrian exit doors, and server-room access where key-based control meets security protocol.
Key Features
- SPST Maintained Contact: 15A at 30 VDC. Contact stays closed after key rotation; operator does not need to hold the key for the duration of door unlock.
- 1/4" Die-Cast Aluminum Housing: Single-piece construction with internal reinforcing rib. Resists mechanical shock and moderate outdoor corrosion.
- Mortise Cylinder Compatibility: Accepts standard 1", 1-1/8", or 1-1/4" cylinders. Flush-mount faceplate with anti-spin locators; no set screws required.
- Weather-Resistant Surface Box: Heavy-duty rubber gasket and sealed housing for indoor or outdoor wall, pole, or pedestal mounting.
- Pre-Wired, Color-Coded Leads: 18 AWG with soldered connections and heat-shrink sleeves. Ready for direct relay or strike controller integration at 30 VDC.
- Tamper-Proof Hardware: Proprietary screws and driver included; resists casual vandalism and unauthorized disassembly.
- Integration-Ready Contacts: SPST closure suitable for access control relay inputs, door-strike solenoids, and electromagnetic lock control circuits across single-door and multi-door installations.
The maintained-contact topology eliminates operator fatigue on high-traffic override points. Unlike momentary switches that require continuous key pressure, the CM-1000/37 closes the circuit on the first turn and holds it until the key is rotated back. This is operationally critical in emergency egress scenarios or secure-room entry where hands may be occupied or the unlock sequence cannot be interrupted.
Mounting flexibility — wall, pole, or pedestal — makes the CM-1000/37 deployable at entry vestibules, service gates, data centers, and secured building perimeters. The weather-resistant gasket and brushed aluminum finish tolerate light rain and outdoor UV exposure without functional degradation. For sites requiring both keyed manual control and integrated access-control signal routing, this switch bridges the gap between legacy key-based workflows and modern credential systems.
The 30 VDC rating at 15A is the industry standard for door-strike solenoids and EM-lock coils in access-control networks. Direct integration with most strike controllers and relay modules requires no intermediate conversion or voltage regulation. All leads are pre-soldered and sheathed, reducing field-wiring errors and installation time on systems with multiple override points.
Compliance and support: Camden products are manufactured to UL standards and backed by manufacturer warranty. The CM-1000/37 is designed for integration with any access-control system that monitors or triggers 30 VDC contact closure — including Honeywell, Johnson Controls, and vendor-agnostic relay architectures. For sites deploying both electronic access control and keyed manual override, refer to the Camden catalog for complementary strike controllers and cabinet-mount switching solutions.
Eden PhillipsPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
We've deployed the CM-1000/37 in dozens of installations where keyed manual override must coexist with electronic access control. The maintained-contact design is the real workhorse here — it eliminates the operator-fatigue problem that plagues momentary switches on high-traffic emergency egress doors. We've seen sites where staff were inserting and holding keys repeatedly throughout the day; switching to maintained-contact reduced ergonomic complaints and, more importantly, reduced the temptation to tape or jam keys in the on position (a security violation). The 15A capacity at 30 VDC handles standard solenoid strikes and EM locks without auxiliary relays — plug it into any strike controller or access-control relay input and it works. The die-cast aluminum construction is robust enough for outdoor vestibules and service gates; the gasket does its job in light rain and sea-salt environments, though we don't recommend it for heavy washdown scenarios. On networked access-control systems, the CM-1000/37 is a passive element — it closes a circuit, nothing more — so there's zero network complexity and zero firmware risk. That's a feature, not a limitation.
Technical Highlights:
- Maintained vs. Momentary Contact: Held contact closes the circuit and keeps it closed until the key is manually rotated back. Eliminates operator fatigue and the need to hold the key through the entire unlock sequence. Critical for emergency egress, server-room override, and high-traffic manual-control points.
- 15A @ 30 VDC Rating: Sufficient for all standard door-strike solenoids and electromagnetic locks. No auxiliary relay or voltage converter required — direct integration with strike controllers and access-control relay inputs on any modern system.
- 1/4" Die-Cast Aluminum Single-Piece Housing: Internal reinforcing rib distributes mechanical stress evenly, protecting contact integrity if the switch is struck or subjected to vibration. Brushed finish resists corrosion in moderate outdoor conditions; not recommended for heavy washdown or salt-spray environments.
- Pre-Wired with Color-Coded 18 AWG Leads: Soldered connections and heat-shrink sleeves reduce field errors and installation time. All wiring is done — strip and twist into relay screw terminals, no splicing.
- Mortise Cylinder Flexibility: Accepts 1", 1-1/8", or 1-1/4" cylinders with anti-spin locators. Allows site-standardized key profiles (Schlage, Kwikset, etc.) without custom modifications.
Deployment Considerations:
- Maintained contact means the circuit is held closed, consuming power for the entire duration. For extended override scenarios (propped doors, held keys), monitor inrush current and heat dissipation in the solenoid coil — pair with a 24/7-rated strike if override lockdown is likely to last more than a few minutes.
- The CM-1000/37 is a passive switch — it has no network connectivity, no battery backup, no monitoring. If keyed override must be logged or audited, a relay or access-control interface must capture the circuit-closure event upstream. This is not a standalone auditability solution.
- Weather-resistant gasket is suitable for light rain and outdoor mounting (vestibules, service gates); not rated for heavy washdown, irrigation spray, or salt-fog environments. In coastal or industrial washdown facilities, consider an IP65+ enclosure or sealed strike instead.
- Cylinder security: The switch accepts standard mortise cylinders, which can be picked or forced. If the keyed override point is the only perimeter control, pair it with additional access-control layers (badge readers, PIN entry) or use high-security cylinders (Medeco, etc.) to raise the bar against casual compromise.
- 15A is the standard for most solenoid strikes, but verify the coil inrush current of your specific strike model. Some specialty heavy-duty or dual-solenoid strikes may exceed 15A, requiring a contactor relay and separate 24 VAC control circuit.
The CM-1000/37 is the right choice for security teams that need reliable, low-complexity keyed manual override without network dependency or firmware risk. Site managers value the maintained-contact simplicity, integrators appreciate the pre-wired leads and standard 30 VDC compatibility, and installers prefer the surface-mount flexibility. For comprehensive keyed and electronic access-control solutions, explore the Camden catalog.
