Camden CX-MA0613D-BK L & Z Bracket for Double Door Magnetic Lock

Overview

The CX-MA0613D-BK is a heavy-duty L & Z mounting bracket built for 600 lb double-door magnetic lock installations. This bracket solves the mechanical fastening and alignment problem in dual-leaf door frames — it positions the strike plate and armature accurately so the magnetic lock can seat properly and maintain full holding force across both doors. Use this when you're installing a fail-secure magnetic lock system and need robust frame-mounted hardware that doesn't shift under door weight or vibration.

Compatibility

The CX-MA0613D-BK is engineered for 24VDC magnetic lock systems rated at 600 lb holding force. It accommodates standard double-door frame geometries where the strike must be mounted across dual leaves. If you are deploying Camden magnetic locks in a double-door access control environment — security entries, server room access, or institutional secured spaces — this bracket provides the mechanical foundation. Verify frame type (metal or wood) and door thickness against your site conditions; the bracket is designed for typical commercial door frames.

Installation Notes

All-black finish provides a clean institutional appearance. Heavy-duty all-metal construction means it tolerates repeated door cycling without sagging or warping. Mount using appropriate fasteners for your frame material (wood screws for timber frames, bolts for steel). The L & Z profile orients the strike plate vertically and horizontally to align with both door leaves — ensure both strike and armature are flush and parallel before final tightening. Environmental operating range 32°F to 131°F (0°C to 55°C); avoid extreme temperature swings that could stress the mechanical joint.
