Vertiv 27858 Basic 15A 6-Outlet 1U Horizontal Rackmount PDU
The Vertiv 27858 (model BRFN060-10) is a no-frills, reliable rack power distribution unit built for IT cabinets where you need dependable 15A/120V distribution without monitoring overhead or unnecessary cost. Six NEMA 5-15R duplex receptacles, a 10ft cord, and a 1U horizontal form factor cover the vast majority of standard rackmount PDU deployments in data closets, server rooms, and edge locations. Every unit ships 100% factory-tested — a detail that matters when you are commissioning racks remotely or on a compressed timeline.
Overview
Part of the Vertiv PowerIT rPDU line, the 27858 is designed for environments where circuit-level monitoring is not required but build quality and compliance are non-negotiable. The heavy steel powder-coat chassis, UL and c-UL listing, RoHS compliance, and TAA/Buy American Act COTS compliance make it a defensible choice for government, education, and regulated commercial deployments. At 6 lbs and 1.72in x 17in x 4.50in, it drops into a standard 1U slot without consuming rack space you cannot spare.
Key Features
- Six NEMA 5-15R Duplex Receptacles: All six outlets share a single 15A thermal breaker, which trips and resets without tools — faster recovery than fuses when a branch overload occurs during a maintenance window.
- 15A / 120V / 1.4kW Load Capacity: Sized for a single 15A branch circuit. If your per-rack draw runs close to or above 1.4kW, plan for a 20A or higher-rated unit rather than running this one at the edge of its rating continuously.
- 10ft / 14-3 AWG Power Cord with NEMA 5-15P: The 10ft reach gives you flexibility to route from a floor-mounted PDU or wall outlet to a mid-rack mounting position without extension cords. 14 AWG wire is correctly sized for a 15A circuit at this cord length.
- 1U Horizontal Rackmount with Adjustable Brackets: The included adjustable mount brackets accommodate varying rack rail depths — useful in mixed-vendor cabinet environments where rail spacing is not perfectly standardized.
- Single Green Power-On LED Indicator: One LED confirms the unit is energized. Simple, but enough for a visual sweep during rack commissioning or a walkthrough inspection.
- TAA Compliant + Buy American Act COTS Compliant: Domestically manufactured in the USA. Required for most federal, state, and DoD procurement vehicles — check your contract vehicle requirements before substituting a non-TAA unit.
- UL and c-UL Listed (60950), RoHS Compliant: Agency listings confirm the unit meets North American and Canadian safety standards. The 60950 listing covers IT equipment power distribution specifically, not just general-purpose power strips.
- 50/60Hz Operation (100-120V): The 50/60Hz frequency range means this unit will function on both North American 60Hz grid power and 50Hz power in regions where 120V/50Hz distribution exists — useful for globally standardized rack builds.
Integration and Compatibility
The BRFN060-10 connects directly to any standard 15A branch circuit via its NEMA 5-15P plug. It pairs naturally with server cabinets and open-frame racks that accept 19-inch 1U accessories. For sites needing per-outlet switching, metering, or remote monitoring, step up within the Vertiv metered or switched rPDU family — this basic unit offers none of those capabilities by design. Operating temperature range of 10-45°C (50-113°F) covers standard conditioned data center and IDF/MDF closet environments.
Frequently Asked Questions
Q: What is the warranty on the Vertiv 27858?
A: The 27858 carries a 5-year limited warranty from Vertiv, which is longer than most comparable basic PDUs in this category.
Q: Is the 27858 TAA compliant?
A: Yes. The BRFN060-10 is manufactured in the USA and is both TAA Compliant and Buy American Act COTS Compliant, making it eligible for most federal procurement vehicles.
Q: Does the 27858 include surge protection?
A: No. The model name BRFN060-10 indicates Basic Non-Surge. Over-current protection is provided by a 15A thermal breaker only. If surge suppression is required, select a unit from Vertiv's surge-protected PDU line.
Q: How many outlets does the 27858 have and what type are they?
A: Six NEMA 5-15R duplex receptacles, all on a single 15A circuit. Maximum output per receptacle is 15A at 120V.
Q: What rack space does the 27858 occupy?
A: It mounts horizontally in 1U of rack space in a standard 19-inch rack. Chassis dimensions are 1.72in H x 17in W x 4.50in D.
Q: Can I use the 27858 in a 20A circuit?
A: The unit's plug is NEMA 5-15P, which is a 15A plug type. It will not physically connect to a 20A NEMA 5-20R receptacle without an adapter, and is rated and designed for 15A branch circuits only.
The Vertiv 27858 is the unit I specify when the rack budget is tight and the site already has properly designed 15A branch circuits — it does exactly one job (distribute 15A across six NEMA 5-15R outlets) and does it with a build quality that justifies the 5-year warranty. The heavy steel powder-coat chassis and 100% factory testing are not marketing language; they show up on the bench when you compare this against generic strip-style PDUs that flex under load or arrive DOA.
Technical Highlights:
- 15A Thermal Breaker: Trips and manually resets — no fuse to source on a midnight call. All six outlets share the single breaker, so a downstream short kills the whole strip; plan load assignment accordingly.
- 14/3 AWG, 10ft Cord: Correct gauge for 15A at this length with no voltage drop concern. The 10ft reach covers most IDF/MDF cabinet placements without extension cords.
- TAA + Buy American Act COTS Compliance: USA-manufactured and procurement-vehicle eligible — a non-trivial differentiator for federal, state, and education contracts where sourcing documentation is audited.
Deployment Considerations:
- The 27858 is a non-surge model — if the site lacks upstream surge suppression on the panel or UPS, choose a surge-rated variant. Running sensitive network gear on a non-surge PDU in a lightning-prone location is a known risk.
- All six outlets are on one 15A breaker with no per-outlet switching or metering. If you need visibility into per-outlet load or remote reboot capability, this is the wrong SKU — move to a metered or switched unit in the PowerIT family.
This unit is the right pick for government IDF closets and small-footprint edge racks where TAA compliance is mandatory, the circuit is a clean 15A, and monitoring hardware is handled upstream by the UPS or a separate metered PDU on the same rail.
