Axis 02451-001 Wall and Pole Mount Bracket
Overview
The Axis 02451-001 is a dual-purpose wall and pole mount bracket engineered for Axis dome cameras in indoor and outdoor surveillance deployments. The IK10 impact-resistant design and IP66-rated built-in RJ45 connector handle moisture, dust, and mechanical stress without requiring separate weatherproof conduit adapters. Flipping the bracket converts it from wall mount to pole mount, eliminating the need to stock different hardware. Supports camera loads up to 40kg (88.2 lb), covering most fixed and motorized Axis dome models.
Compatibility
The 02451-001 mounts Axis Q-series and P-series dome cameras, including compact indoor domes and full-size outdoor models. Confirm your specific camera model's weight and mounting footprint against the 40kg load capacity before installation. For corner-mount configurations, order the optional AXIS T91A64 Corner Bracket separately.
Installation Notes
Operating temperature range: −50°C to 65°C (−58°F to 149°F); humidity 10–100% RH non-condensing. The bracket features a built-in IP66-rated RJ45 connector and accepts either an IDC (insulation-displacement contact) connector for field termination. Cable ties are included. For pole mounting, AXIS Steel Straps TX30 (570mm or 1450mm) are required as optional accessories. Maximum load is 40kg; exceeding this voids the mount's structural integrity. Storage conditions: −40°C to 65°C, 10–100% RH non-condensing.
What's in the Box
- 1x Wall bracket mount
- 1x Installation guide
- Cable ties
- 1x RJ45 mounting tool
