Axis 03185-001 TC1604 Wall Mount for C1720 Network Display Speaker
The Axis 03185-001 is a precision mounting bracket engineered specifically for the Axis C1720 Network Display Speaker. This is a straightforward compatibility play: if you're deploying the C1720 in a wall-mounted configuration, this bracket is the OEM solution. Skip generic VESA mounts—this one is built for the C1720's form factor and electrical integration.
Key Features
- Powder-coated aluminum construction — resists surface corrosion and scuffing in indoor retail, transport, and corporate environments where the mount may endure frequent handling or cleaning cycles. More durable than bare aluminum or plastic in high-traffic spaces.
- Pre-attached safety bracket — speeds installation by holding the C1720 in correct alignment before you connect cables. Reduces risk of misalignment that could damage connectors or leave the unit unbalanced.
- Integrated alignment guides — enables hands-free positioning during install. One technician can hang and position the speaker without a second person steadying it, cutting labor time on multi-unit deployments.
- Bottom-mounted Torx security screw — locks the unit in place once positioning is confirmed. Torx (vs. Phillips or slotted) reduces accidental over-torque or stripping if re-adjusted later.
- PoE-compatible design — the mounting hardware does not interfere with PoE power and data delivery to the C1720. This means a single CAT5e/6 run handles both audio and power; no separate 12V supply required. Simplifies wall roughing and reduces visible cabling.
- Complete installation kit included — includes hardware for drywall, concrete, and other common wall types. Avoids the friction of sourcing anchors separately.
Integration & Compatibility
The 03185-001 is designed and tested for the Axis C1720 only. Do not attempt to use this mount with other Axis display speakers or third-party speakers—the mounting geometry and cable routing are specific to the C1720's dimensions and connector placement. If you're deploying multiple C1720 units, you'll need one TC1604 per unit.
The bracket works with standard wall surfaces and supports the C1720's weight across residential drywall, concrete block, and wood stud installations when appropriate anchors from the included kit are used. The powder-coat finish is suitable for indoor use only; do not install outdoors or in high-humidity wet environments (kitchens, bathrooms, poolside) without additional protective measures.
Installation is straightforward: hang the bracket using the pre-drilled holes and included fasteners, insert the C1720 into the pre-attached alignment guide, verify position, then secure the Torx screw. Route the PoE cable behind the bracket before final lock-down. Total install time per unit is typically 10–15 minutes for an experienced technician.
Frequently Asked Questions
Q: Is the Axis 03185-001 compatible with other Axis display products?
A: No. The TC1604 (03185-001) is engineered specifically for the C1720 Network Display Speaker. Using it with other Axis speakers or displays is not supported and may result in instability or damage.
Q: Can I remove the pre-attached safety bracket if I don't need it?
A: The bracket is permanently attached and part of the C1720 alignment system. Do not attempt to remove it.
Q: What wall types does the mounting kit support?
A: The included fastener kit accommodates standard drywall, concrete block, and solid wood studs. For other surfaces (metal stud, tile, masonry veneer), consult the installation guide for alternative anchoring methods.
Q: Does the mount require any separate power supply?
A: No. The TC1604 is PoE-compatible, so the C1720 receives both power and data over a single CAT5e/6 cable. No auxiliary 12V plug is needed.
Q: Can I adjust the angle after installation?
A: The bracket is a fixed vertical mount. Tilting or horizontal rotation is not supported. Position the C1720 correctly before final Torx screw lock-down.
Q: Is this mount suitable for outdoor installation?
A: No. The powder-coated aluminum and included fasteners are rated for indoor use only. Outdoor or high-humidity environments (pools, kitchens) will corrode fasteners and void the mounting integrity.
Ted PerryPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The Axis 03185-001 is a no-frills OEM bracket—exactly what you need if you're wall-mounting the C1720. It's not a universal VESA solution, and that's the point. The pre-attached alignment guide and integrated installation guides eliminate the fumbling that comes with adapting third-party mounts. The Torx security screw is a small detail that matters: it resists accidental loosening when the unit is brushed or cleaned by staff over months of operation.
Technical Highlights:
- Powder-coated aluminum: resists fingerprints and light corrosion in high-touch retail and transport spaces, avoiding the dull finish degradation you'd see with bare aluminum over 12+ months.
- PoE compatibility: the bracket does not constrain or compress the C1720's power/data connector, so you eliminate the need for a separate 12V supply run. One CAT5e/6 cable replaces two conduit runs, cutting wall roughing labor.
- Integrated guides and pre-attached safety bracket: reduce installation touch-points. One technician can hang and secure the unit in ~12 minutes per location, whereas a generic VESA mount typically requires trial-and-error alignment.
Deployment Considerations:
- This bracket is vertical-mount only. If you need tilting or swivel capability, explore alternative mounting solutions or stand-alone mounts (not OEM-supported).
- Indoor use only. The fasteners and aluminum will corrode or lose grip if exposed to pool spray, steam rooms, or outdoor weather. Plan accordingly for hospitality or industrial wet environments.
Deploy the 03185-001 in retail point-of-sale setups, corporate reception areas, and transport terminal announcement systems where the C1720's dual-sided display and integrated speaker add value. The hands-free installation and Torx security screw make it the right choice for sites that rotate or update signage frequently.
