Axis 02851-001 Wall-and-Pole Mount
The Axis 02851-001 is a heavy-duty aluminum mounting solution built for outdoor camera installations in industrial and commercial environments where exposure to weather, temperature extremes, and impact damage are operational realities. If you're deploying Axis IP cameras in tough conditions—transportation hubs, warehouses, processing plants—this mount handles the structural and environmental demands so your camera placement isn't compromised by weather or vandalism concerns.
Key Features
- IP66 / NEMA 4X Rating: Direct rainfall and dust ingress won't penetrate the aluminum casing—meaning you can mount this in salt-spray zones, high-humidity industrial areas, or regions with seasonal dust storms without worrying about corrosion or moisture seeping into connectors. Skip this if you need full submersion protection (that requires IP67 or higher).
- IK10 Impact Rating: Withstands 20 joules of impact force—equivalent to a 5 kg weight dropped from 40 cm. In vandalism-prone areas or where equipment gets bumped by forklifts or loading equipment, this rating means the mount won't fail under direct strikes. Standard outdoor mounts (IK07 or lower) can crack or deform under similar conditions.
- 40 kg Load Capacity: Supports heavier camera models, PTZ units, or multi-sensor housings without bracket flex or sag over time. If you're mounting a large PTZ or a camera plus secondary optics, this capacity keeps you clear of the equipment's weight spec rather than right at the edge.
- 1.5" NPS Thread Compatibility: Standard across most outdoor camera mounts and pole-top adapters, so integration with existing pole infrastructure or swing-arm rigs is straightforward. No proprietary threading means you're not locked into a single bracket ecosystem.
- Dual M25 Conduit Entries + Back Cable Hole: Flexibility to run power and network cables from top, sides, or rear without forcing awkward cable bends that degrade connectivity or damage insulation. A real advantage in retrofit installations where cable routing isn't always ideal.
- RJ45 Ethernet Output & IDC/RJ45 Input Connectors: Allows inline wiring—run cable through the mount rather than around it—reducing external cable length and clutter. For long cable runs to rooftop cameras, this minimizes cable sag and simplifies maintenance access.
- Operating Range: -50°C to +65°C (-58°F to +149°F): Aluminum thermal expansion doesn't crack seals or loosen fasteners across this span, so arctic warehouses, desert industrial zones, or heated equipment enclosures won't cause premature failure. Most standard mounts degrade or lose waterproofing below -20°C or above +50°C.
- Weight: 2,164 g (4.77 lbs): Heavy enough to dampen vibration from wind or building sway, light enough to install without requiring additional reinforcement on standard poles or wall anchors.
- EMC Compliance (CISPR 35, CISPR 32 Class A): Meets strict conducted and radiated immunity standards, so the mount won't inject noise into your network or sensitive analog systems if deployed near industrial machinery or radio transmitters.
- PVC-Free Materials & Conflict Mineral Screening: Supports procurement policies in regulated industries (pharma, food, electronics manufacturing) where material sourcing and chemical content are audited.
Typical Deployments
Ideal for fixed-position outdoor surveillance cameras in warehouses, loading yards, perimeter fencing, traffic intersections, and industrial plant exteriors. The combination of weatherproofing, impact rating, and long temperature range makes it a natural fit for unattended remote sites where service intervals are measured in months rather than weeks. Includes 5-year warranty.
Integration & Compatibility
The 02851-001 is camera-agnostic—it's a mechanical and electrical connector platform, not a device driver. Works with any Axis camera featuring a 1.5" NPS threaded mount. Cable pass-through supports standard RJ45 Cat5e/Cat6 Ethernet runs, so integration with managed PoE switches and NVR infrastructure is straightforward. If you're planning a distributed outdoor camera grid on a network infrastructure guide, factoring in mount durability early simplifies long-term TCO.
What's in the Box
- 1x Axis TP1001-E wall-and-pole mount assembly
- Wall bracket
- Cable ties
- Installation accessories (fastening hardware)
Frequently Asked Questions
Q: Can I use the 02851-001 on a horizontal pole or does it only work wall-mounted?
A: The 1.5" NPS thread is design-agnostic—it works on vertical wall mounts, horizontal poles, swing arms, or any standard pole adapter. The M25 conduit entries and cable routing are oriented for both wall and pole orientations.
Q: What's the maximum cable gauge I can run through the M25 conduit entries?
A: M25 is an industrial standard that accommodates up to 20 mm diameter cables. Standard Cat5e/Cat6 (5-8 mm bundled) passes easily. If running multiple thick armor-jacketed cables, test fit before final installation.
Q: Is the 02851-001 suitable for coastal or salt-spray environments?
A: Aluminum construction with IP66 sealing handles salt spray far better than steel, but true salt-spray (IEC 60068-2-52) testing data is not published in the available specs. If you're in a direct ocean-facing installation, consult Axis support or consider additional marine coatings as a precaution.
Q: Does the IK10 rating mean it's bulletproof?
A: No. IK10 covers impact damage from dropped tools, accidental strikes, or vandal impact—not ballistic protection. The 20-joule impact threshold is industrial-grade protection, not security-grade.
Q: Will the 02851-001 accommodate a motorized varifocal lens adjustment?
A: The mount itself is passive—it's a structural and electrical connector. If your camera has motorized focus/iris, the camera's built-in motor handles adjustment. The mount doesn't interfere with that.
Q: How do I know which camera models fit the 1.5" NPS thread?
A: Check your camera's mechanical drawing or datasheet for "mounting thread" or "pole mount adapter." Most Axis fixed and PTZ models support 1.5" NPS. If your camera spec sheet doesn't list it, contact Axis pre-sales or your integrator to confirm compatibility before ordering.
Ted PerryPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The Axis 02851-001 is a no-nonsense accessory for permanent outdoor camera installations where you're accepting that the mount itself becomes part of the warranty chain. If the 02851-001 fails due to corrosion or impact, your camera comes down too—so the IK10 and IP66 ratings aren't luxury specs, they're protective layers for your capital equipment.
Technical Highlights:
- IP66 / NEMA 4X Enclosure: Keeps moisture and dust away from the RJ45 mating surfaces across temperature swings from -50°C to +65°C. Over a 5-year deployment cycle on a rooftop or in a salty industrial zone, this envelope prevents connector corrosion that would force a costly mount replacement. Standard IP54 mounts don't hold up in these conditions.
- IK10 Impact Resistance (20J): Absorbs accidental forklifts, vandal kicks, or wind-driven tool strikes without structural failure. Means you're not replacing the mount every 18 months due to bracket cracks or bent pole adapters—a real TCO factor in high-traffic or rough-handling environments.
- 40 kg Capacity with Dual M25 Conduit: The weight budget accommodates mid-to-large PTZ cameras or fixed models with auxiliary housings, and the separate cable entries (not funneled through a single port) reduce stress on connectors and allow independent cable routing for redundancy or future upgrades.
Deployment Considerations:
- The 02851-001 is passive infrastructure—it doesn't amplify network signals or add PoE power. Verify your switch delivers sufficient wattage to the camera after accounting for cable resistance, especially on long runs beyond 300 feet.
- Aluminum conducts heat, so in direct sunlight, the mount can reach +70°C to +80°C even if the ambient is +50°C. Ensure your camera's operating temp spec covers this thermal margin, or shade the mount with a sunshield.
Position this mount for fixed-position surveillance where you're prioritizing 5-year durability over adjustability. If your site demands pan-tilt repositioning, the 40 kg load and long temperature range still make it suitable, but layer on regular inspection schedules for fastener corrosion and connector oxidation every 24 months. Good choice for warehouse perimeters, utility substations, and remote plant monitoring where setup-and-forget is the operational norm.
