Axis 02350-001 2MP Full HD Low-Light Indoor Box Camera
Overview
The Axis 02350-001 is a compact, fixed-lens box camera designed for indoor surveillance where low-light performance and straightforward deployment matter. It captures 1920x1080 resolution at up to 30 fps, leveraging a 1/2.9" progressive scan CMOS sensor paired with a 3.16mm F2.0 lens to deliver a 103° horizontal field of view — wide enough for retail corridors, small office lobbies, and reception areas without the need for repositioning. The model runs on standard IP cameras wiring: 100BASE-TX Ethernet over PoE (IEEE 802.3af/at), drawing just 5.4W typical and 12.95W maximum, so it fits comfortably on any managed PoE switch without strain.
Key Features
- Full HD 1080p at 30 fps: Two resolution options (1280x960 or 1920x1080) ensure you can balance frame rate against bandwidth on slower links. At 30 fps full HD, motion blur stays minimal in typical indoor lighting, important for recognizing faces or reading signage in security footage.
- Dual codec compression (H.264 and H.265): H.265 cuts bitrate roughly 40–50% compared to H.264 for the same quality, which directly reduces storage costs and network congestion on bandwidth-constrained sites. H.264 remains the fallback for older VMS platforms or edge recording devices.
- Day/night IR illumination: Integrated IR LEDs let the camera see in complete darkness without external lighting. Night vision range is adequate for indoor spaces up to 10–15 meters; outdoor perimeter use would require a model rated for weatherproofing and higher IR output.
- Built-in microphone and speaker: Two-way audio support enables basic voice communication — useful for remote greeting in unmanned lobbies or quick verbal warnings. Audio detection capabilities flag abnormal sound (glass breaking, shouting) for edge-based alerting.
- Motorized iris and automatic gain control: Adapts to rapid lighting changes (windows, doors opening) without manual lens adjustment. Prevents blown-out highlights and crushed shadows when sunlight shifts.
- Motion JPEG fallback: In addition to H.264/H.265, Motion JPEG support ensures compatibility with legacy systems or specialized playback devices that don't support modern codecs.
- Axis Edge Vault and Privacy Shield: Edge Vault cryptographically binds the camera identity to its hardware, blocking cloning or firmware spoofing. Privacy Shield remotely masks sensitive areas (faces, screens, doorways) in real time without reprocessing recorded video.
- Object Analytics (ACAP): On-camera motion detection and object classification reduce false alerts from shadows or reflections. Axis Application Platform (ACAP) support lets you install third-party analytics apps for specialized tasks (people counting, loitering detection) without external servers.
Integration & Compatibility
The 02350-001 complies with ONVIF Profile S and T, integrating with Milestone XProtect, Genetec Security Center, Axis Camera Station, and any standards-based VMS that supports H.264 or H.265. Network setup is straightforward: DHCP or static IP assignment, optional 802.1X for enterprise authentication, and IPv6 support for modernized deployments. Power is 100BASE-TX PoE only — no 12VDC or 24VAC barrel connectors, so you cannot use legacy power supplies.
Mounting & Physical Design
The compact box form factor fits ceiling or wall mounts designed for small-footprint cameras. No included bracket means you'll source a third-party mount matching the standard M20 lens thread and base geometry. The industrial plastic housing resists dust and minor impact but is not rated for outdoor weather (IP66) — reserve weatherproof models for exposed facades or high-moisture environments.
When to Choose a Different Model
If you need outdoor durability, higher resolution (4MP+), or advanced zoom capability, step up to a weatherproof turret or bullet in the outdoor IP cameras line. The 02350-001 excels indoors and under-roof; moving it to exposed eaves or parking lots invites moisture ingress and shortened lifespan. For large open areas (warehouses, auditoriums), a higher megapixel model minimizes pixel-per-foot trade-offs in forensic review.
Frequently Asked Questions
Q: What is the maximum IR range on the Axis 02350-001?
A: Integrated IR illumination is designed for typical indoor spaces (conference rooms, hallways, small retail) at ranges up to 10–15 meters in complete darkness. Exact range depends on reflectivity of the target surface and ambient light; bright paint surfaces reflect IR better, extending effective range.
Q: Does the 02350-001 work with Milestone XProtect and Genetec Security Center?
A: Yes. The camera supports ONVIF Profile S and T, which both VMS platforms recognize natively. Add the camera by IP address in your VMS and configure H.264 or H.265 streams as needed.
Q: Can I use a standard 802.3af PoE switch, or do I need PoE+?
A: Standard 802.3af is sufficient. The 02350-001 draws 5.4W typical and peaks at 12.95W, well within the 15W 802.3af budget. No special switch upgrade is required.
Q: Is the Axis 02350-001 outdoor-rated?
A: No. This is an indoor-only model. It lacks weatherproofing (no IP66/IP67 rating). For rooftop, soffit, or high-moisture applications, choose a weatherproof turret or bullet camera from the Axis product line.
Q: What mounting options are available for the 02350-001?
A: The camera supports standard wall and ceiling mounts via the M20 lens thread and base geometry. Brackets are not included in the package; verify your mount matches the box form factor and VESA spacing before purchase.
Q: Does the 02350-001 support two-way audio, and is it suitable for intercom applications?
A: Yes, it has a built-in microphone and speaker for bidirectional audio. The built-in speaker is modest in volume and suited for small spaces (lobbies, reception desks); large halls or outdoor intercoms require external amplified audio systems.
Marty AllisonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The Axis 02350-001 is a pragmatic choice for small-to-medium indoor deployments where simplicity and low power draw outweigh raw megapixels. Its 2MP 1080p sensor paired with H.265 codec support makes it a storage-efficient entry point for organizations rolling out standardized PoE surveillance without breaking network or power budgets.
Technical Highlights:
- H.265 codec at 1920x1080, 30 fps: Achieves roughly 45% bitrate savings versus H.264 on typical indoor scenes. On a network video recorder storing 30 cameras at 24/7 retention, that's meaningful — 6TB becomes 3.3TB for equivalent archival span.
- Dual compression fallback (H.264 + Motion JPEG): Hedges against VMS or edge device codec incompatibility. Legacy systems that don't parse H.265 can still pull H.264 streams; Motion JPEG serves as a lowest-common-denominator failsafe.
- 5.4W typical power consumption under 802.3af: Leaves 9W budget headroom on a standard 15W PoE port, allowing for future splitter/extender modules or local power reservoirs without requiring PoE+ or a dedicated power injector.
- Built-in IR and motorized iris: No external illuminator or manual focus adjustment needed. In retail or office settings where ambient light changes throughout the day (windows, door swings, overhead lights), the iris adapts automatically, reducing blown highlights and clipping in playback.
Deployment Considerations:
- Indoor-only design: The unrated plastic housing will fog and corrode in humid or wet environments — eaves, loading docks, and canopy areas are off-limits. Verify installation remains under roof or in climate-controlled spaces before provisioning.
- Fixed 3.16mm lens (103° FOV): This is wide-angle and suited for compact hallways or reception areas, but it sacrifices zoom-in detail. If forensic facial recognition or license plate readability is a requirement, pair this with a higher-megapixel varifocal model, or accept that pixel density on distant subjects will be modest.
- No built-in storage: Unlike some compact domes, the 02350-001 has no microSD slot — all recording routes through your network video recorder or edge storage appliance. In poor-network conditions, plan for local failover (edge NVR at the site) to avoid footage loss.
- PoE-only power: No 12VDC or 24VAC connector. If your site predates PoE infrastructure, budget for a managed PoE switch or injector; off-the-shelf dumb switches won't power the camera.
Reserve the 02350-001 for controlled indoor environments — small retail operations, office lobbies, break rooms, warehouse receiving areas — where you prioritize low operational overhead (single power and network wire) over advanced features. It is a solid workhorse for departments that need reliable, standards-compliant surveillance without the complexity of thermal, multi-sensor, or motorized systems.
