Form Factor:
Dome
Resolution:
1080p (2MP)
IR Low Light:
Lightfinder; Day/Night
Features:
Forensic WDR
Video Compression:
H.265
IP Rating:
IP66/IP67
IK Rating:
IK10
Type:
Dome
Product Type:
Dome
Warranty:
5 Year(s)
Compatibility:
ONVIF
Operating System:
Windows
wdr:
Forensic WDR
Night Vision:
IR
Power Type:
PoE+
PoE Class:
5
Day Night:
Yes
Storage Support:
microSD
Outdoor Ready:
Yes
HTTPS Encryption:
Yes
Wide Dynamic Range:
Forensic WDR
Housing Color:
White
Environment Rating:
Vandal Resistant
Lightfinder:
Lightfinder
Min Illumination/ Light Sensitivity (color:
0.06 lux
Min Illumination/ Light Sensitivity (b/w:
0.01 lux
Max Frames Per Second:
25/30
Electronic Image Stabilization:
Yes
Focal Length:
2.8 mm
Aperture:
1.6
Lens Mount:
M12
Replaceable Lens:
Yes
Digital Pan/Tilt:
Yes
Digital Zoom:
Yes
Zipstream:
Yes
H.264:
Baseline, High, Main
H.265:
Yes
Active Tampering:
Yes
AXIS Camera Application Platform:
Yes
IEEE 802.1X:
Yes
Signed OS:
Yes
Local Storage (memory Card Slot:
Yes
Operating Temperature:
-40 to 55 °C
Vandal Rating:
IK10
Variants:
AXIS P3925-R RJ45 AXIS P3925-R M12
Image Sensor:
1/2.9” Progressive scan RGB CMOS
Minimum Illumination Color:
0.06 lux at 30 IRE F1.6; 0.12 lux at 50 IRE F1.6
Minimum Illumination B/W:
0.01 lux at 30 IRE F1.6; 0.02 lux at 50 IRE F1.6
Shutter Speed:
1/33500 s to 2 s
Camera Adjustment Pan:
±30°
Camera Adjustment Tilt:
15-90°
Camera Adjustment Rotation:
±175°
Model:
ARTPEC-7
Frame Rate:
Up to 25/30 fps (50/60 Hz) in all resolutions 45 fps in 720p Capture mode 2MP 1920x1080 (16:9) @25/30 fps Capture mode 1MP 1280x720 (16:9) @45 fps
Video Streaming:
Multiple, individually configurable streams in H.264, H.265 and Motion JPEG Axis Zipstream technology in H.264 and H.265 Controllable frame rate and bandwidth VBR/ABR/MBR H.264 and H.265 Video streaming indicator Low latency mode
Multi-view Streaming:
Up to 8 individually cropped out view areas
Image Settings Scene Profiles:
forensic, vivid, traffic overview
Pan/Tilt/Zoom:
Digital PTZ, preset positions, guard tour, control queue
Network Protocols:
IPv4, IPv6 USGv6, HTTP, HTTPS , HTTP/2, TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, PTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP,
Application Programming Interface:
Open API for software integration, including VAPIX® and AXIS Camera Application Platform; specifications at axis.com AXIS Video Hosting System (AVHS) with One-Click Connection One-click cloud connection ONVIF® Profile G, ONVIF® Profile M, ONVIF® Prof
Video Management Systems:
Compatible with AXIS Camera Station Edge, AXIS Camera Station Pro, AXIS Camera Station 5, and video management software from Axis’ partners available at axis.com/vms .
Event Conditions Device Status:
above operating temperature, above or below operating temperature, below operating temperature, IP address removed, network lost, new IP address, shock detected, storage failure, system ready, within operating temperature
Event Conditions Edge Storage:
recording ongoing, storage disruption
Event Conditions I/O:
manual trigger, virtual input MQTT subscribe
Scheduled And Recurring:
scheduled event
Event Conditions Video:
average bitrate degradation, day-night mode, live stream open, tampering
Upload Images Or Video Clips:
FTP, HTTP, HTTPS, SFTP, email and network share
Event Actions Notification:
HTTP, HTTPS, TCP and email Overlay text Preset positions
Event Actions Record Video:
SD card and network share SNMP trap messages WDR mode MQTT publish
Data Streaming:
Event data
Built-in Installation Aids:
Pixel counter
Included:
AXIS Motion Guard, AXIS Fence Guard, AXIS Loitering Guard AXIS Video Motion Detection, active tampering alarm , blocked view detection , shock detection Support for AXIS Camera Application Platform enabling installation of third-party applications, s
Edge Security Software:
Signed OS, brute force delay protection, digest authentication and OAuth 2.0 RFC6749 Client Credential Flow/OpenID Authorization Code Flow for centralized ADFS account management, password protection, AES-XTS-Plain64 256bit SD card encryption
Edge Security Hardware:
Secure boot
Network Security:
IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2) , IEEE 802.1AE (MACsec PSK/EAP-TLS), HTTPS/HSTS , TLS v1.2/v1.3 , Network Time Security (NTS), X.509 Certificate PKI, host-based firewall
Documentation:
AXIS OS Hardening Guide Axis Vulnerability Management Policy Axis Security Development Model AXIS OS Software Bill of Material (SBOM) To download documents, go to axis.com/support/ cybersecurity/resources To read more about Axis cybersecurity suppor
Casing:
IP66/67-, NEMA 250 4X- and IK10-rated aluminum casing, polycarbonate clear dome
Sustainability:
PVC free
Mounting:
Inside vehicles and rolling stock
Connectors RJ45:
male, 10BASE-T/100BASE-TX
Connectors M12:
female, rugged, D-coded with rotatable coupling nut All connectors support PoE
Operating Conditions Normal:
-40 °C to 55°C (-40 °F to 131°F)
Maximum (intermittent:
70 °C (158 °F)
Arctic Temperature Control:
start-up at -40 °C (-40 °F)
Operating Conditions Humidity:
10-100% RH (condensing)
EMC:
EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, RCM AS/NZS CISPR 32 Class A, KCC KN32 Class A, KN35, EN 50121-4, EN 50121-3-2, IEC 62236-4, ECE R10 rev.06 (E approval), EN 50498
Safety:
IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, EN 45545-2, UN ECE R118, NFPA 130, IS 13252
Dimensions Height:
49.4 mm (1.94 in), ø 110 mm (4.33 in)
Weight RJ45:
400 g (0.88 lb)
Weight M12:
410 g (0.90 lb)
Lenses:
Lens M12 2.1 mm F1.8 IR: horizontal field of view 145° Lens M12 3.6 mm F1.8 IR: horizontal field of view 87° Lens M12 6 mm, F1.9 IR: horizontal field of view 56° Lens M12 8 mm F1.8 IR: horizontal field of view 40°
Other:
AXIS T94D01S Mount Bracket, AXIS T94D02S Curved Mount Bracket, Network coupler IP66, network cable coupler indoor For more accessories, see axis.com
Languages:
English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Traditional Chinese, Dutch, Czech, Swedish, Finnish, Turkish, Thai, Vietnamese
Lens:
2.8mm, F1.6
Ingress Protection:
IP66/IP67
Impact Protection:
IK10
Video Codec:
H.264, H.265, Motion JPEG
Memory Card Slot:
microSD/microSDHC/microSDXC
Shipping Weight:
0.880 lb
Country Of Origin:
JP
UNSPSC:
46171610
