Vertiv APS EBC with 5 Lithium-ion Battery Strings - AL7EBC5HHUBXLKB

Vertiv AL7EBC5HHUBXLKB Extended Battery Cabinet

Overview

The Vertiv AL7EBC5HHUBXLKB is a 14-bay Extended Battery Cabinet (EBC) designed to augment the runtime of compatible Vertiv Liebert APS UPS systems. It specifically houses five Lithium-ion battery strings, providing extended power backup for critical IT infrastructure during utility outages. This unit is intended for deployments where extended uptime is paramount, such as data centers or enterprise server rooms.

Compatibility

This EBC model is designed for use with the Vertiv Liebert APS UPS line. It is specifically configured with five Lithium-ion battery strings. Ensure your Liebert APS UPS system supports extended battery cabinets and is configured for Lithium-ion chemistry for optimal performance and safety. This cabinet is not compatible with VRLA battery string configurations.

Installation Notes

The Vertiv AL7EBC5HHUBXLKB requires specific EBC cables for connection to the UPS. Available cable lengths include 1-meter (APSEBCCBL1M), 3-meter (APSEBCCBL3M), and 5-meter (APSEBCCBL5M) options, sold separately. A 10 Amp Charger Module (APSCHRGRMOD) may be required if using third-party battery cabinets, though this unit is designed for direct integration. Consult the Liebert APS UPS installation manual for detailed wiring and connection procedures, including any specific torque requirements for battery terminals or cabinet connections.
