Vertiv APS EBC with 1 Lithium-ion Battery String - AL7EBC1HHUBXLKB

Vertiv AL7EBC1HHUBXLKB Extended Battery Cabinet

Overview

The Vertiv AL7EBC1HHUBXLKB is a 14-bay Extended Battery Cabinet (EBC) specifically configured with one Lithium-ion battery string. This unit is designed to augment the runtime of compatible Vertiv Liebert APS UPS systems, providing critical power continuity for sensitive equipment in data centers, enterprise IT environments, and other mission-critical applications. It ensures extended operational uptime during power disturbances or outages, directly integrating with the UPS to manage battery charging and discharge cycles.

Compatibility

This EBC is engineered for direct integration with the Vertiv Liebert APS UPS platform. It is designed to house and manage one string of Lithium-ion batteries. For extended runtime requirements, Vertiv offers variants with up to seven battery strings (AL7EBC7HHUBXLKB for Lithium-ion, AS7EBC7CCUBXLKB for VRLA). Optional accessories include 1, 3, or 5-meter EBC cables (APSEBCCBL1M, APSEBCCBL3M, APSEBCCBL5M) for flexible placement and a 10 Amp Charger Module (APSCHRGRMOD) for use with third-party battery cabinets, though this specific model is designed for proprietary Vertiv battery integration.

Installation Notes

Proper installation requires connecting the EBC to the host Liebert APS UPS using the appropriate EBC cable. The internal battery string must be correctly seated and connected according to the manufacturer's guidelines. Ensure the UPS system is properly configured to recognize and manage the extended battery capacity. The unit is intended for deployment within controlled environments, typically server rooms or data center floors, where ambient temperature and humidity are within operational specifications for UPS and battery systems. Consult the Liebert APS UPS documentation for detailed wiring, configuration, and environmental requirements.
