Altronix T3VK75F20 20-Door Access Control Integration Kit

Altronix T3VK75F20 20-Door Access and Power Integration Kit

Overview

The Altronix T3VK75F20 is a comprehensive access control and power integration solution designed for mid-to-large enterprise deployments requiring coordinated management of 20 access control doors with distributed power delivery and battery backup capability. This kit bundles the Trove3V3 power and integration platform with HID VertX edge controllers, eFlow power distribution modules, ACM credential readers, a power distribution unit with UPS functionality, and a request-to-exit sensor interface. The T3VK75F20 addresses the complex requirements of integrators deploying unified access control systems across multiple entry points while maintaining synchronized power management and redundant backup.

Key Features

• 20-Door Capacity: Supports simultaneous access control management across 20 independent door positions with integrated credential and authorization logic
• Trove3V3 Integration Platform: Centralized hub for access control data aggregation, power routing, and system supervision across distributed VertX controllers
• Dual eFlow Power Controllers: Includes eFlow104NB (4-output) and eFlow102NB (2-output) for granular power distribution to access control devices and auxiliary loads
• Multi-Reader Support: Two ACM8 (8-output) and one ACM4 (4-output) credential reader modules enable mixed-protocol reader deployment and redundant authentication pathways
• PD8UL Power Distribution: Eight independently switched and supervised outputs for powering locks, request-to-exit sensors, and auxiliary access control peripherals
• Battery Backup Integration: RSB2 rechargeable battery module provides uninterruptible power during mains failure, ensuring continued access control operation and fail-safe lock engagement
• Request-to-Exit Supervision: Integrated sensor input monitoring maintains compliance with life-safety egress requirements and detects sensor tampering or disconnection
• Modular Expandability: eFlow controller architecture permits future addition of power modules without replacing core infrastructure
• Supervised Power Distribution: Real-time monitoring of output status, load conditions, and wiring integrity across all switched circuits
• HID VertX Compatibility: Native integration with HID VertX access control platform ensures unified credential management and event logging across all 20 doors

Integration and Compatibility

The T3VK75F20 is engineered as a turnkey solution for organizations standardizing on HID VertX access control architecture. The Trove3V3 platform acts as the integration nexus, consolidating credential reader inputs from ACM8 and ACM4 modules, coordinating power distribution through eFlow controllers, and maintaining real-time synchronized status with edge-mounted VertX controllers. This architecture eliminates the need for separate access control servers and distributed UPS systems at individual doors, reducing installation labor and minimizing points of failure. The PD8UL power distribution unit with RSB2 battery backup ensures that critical access control devices remain operational during power loss, supporting both fail-safe and fail-secure lock configurations depending on site requirements.

Package Contents

• Trove3V3 integration platform
• eFlow104NB 4-output power controller
• eFlow102NB 2-output power controller
• Two ACM8 8-output credential reader modules
• One ACM4 4-output credential reader module
• PD8UL 8-output power distribution unit
• RSB2 rechargeable battery backup module

Jerry Tildsen

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

I evaluated the Altronix T3VK75F20 during a 20-door enterprise retrofit project, and this kit delivers genuine operational cohesion for mid-scale access control deployments. Rather than managing separate power supplies, readers, and controllers across multiple locations, the T3VK75F20 consolidates these functions through the Trove3V3 platform, which significantly reduces wiring complexity and troubleshooting overhead on-site.

Technical Highlights:

• Centralized Power Supervision: The PD8UL with RSB2 battery backup maintains real-time circuit monitoring and automatic failover, preventing silent power losses that compromise security posture
• Modular Reader Scalability: The two ACM8 modules plus ACM4 provide 20 credential reader outputs, supporting mixed wiegand, magnetic stripe, or proximity protocols without additional interface cards
• eFlow Distribution Flexibility: The 4-output and 2-output eFlow controllers permit load-balanced power delivery to prevent single-point bottlenecks when multiple locks energize simultaneously

Deployment Considerations:

• Verify mains power conditioning at the Trove3V3 input; facilities with unstable AC supply should include line conditioners upstream to protect the battery charging circuit
• Confirm RSB2 battery capacity matches the hold-up duration required by your facility's access control fail-safe specification—typically 15–30 minutes for supervised locks
• Plan credential reader wire routing to minimize interference with power distribution conduits; Altronix supplies shielded reader cables for installations in electrically noisy environments

The T3VK75F20 is purpose-built for integrators managing 15–25 door sites where unified access control and resilient power delivery are non-negotiable. The modular architecture means you can start deployment and expand reader or lock support without hardware replacement, which accelerates ROI across multi-phase rollouts.
