Altronix T1AXK3F2S 24VDC Power Supply/Charger

Overview

The Altronix T1AXK3F2S is a regulated 24VDC power supply and charger designed for security integrators deploying access control, alarm, and surveillance systems that require reliable secondary power and battery management. This model delivers 24VDC at 6 amperes output with integrated fused distribution and eFlow technology for enhanced system monitoring and backup charging capabilities. The T1AXK3F2S serves as a central power node in medium-scale security installations where redundancy, supervision, and battery backup are critical operational requirements.

Key Features

• 24VDC Output at 6 Amperes: Delivers consistent regulated power for multiple security devices including door strikes, mag locks, card readers, and alarm control panels
• Fused Output Distribution: Individual fused outputs protect downstream equipment and isolate faults without system-wide power loss
• eFlow Technology: Advanced power monitoring and current limiting for optimized device protection and system visibility
• Battery Backup Charging: Integrated charger maintains backup battery charge state for emergency egress and critical alarm functions during AC power loss
• Dual-Voltage Input Compatibility: Accommodates standard utility AC power input for flexible installation in existing electrical infrastructure
• Compact Industrial Form Factor: Wall-mountable enclosure design integrates cleanly into electrical rooms, server racks, and equipment closets typical of security system deployments
• Supervision Capability: System-level monitoring and alerting for power faults, battery condition, and output integrity
• Security-Grade Reliability: Built for 24/7 operation in access control, perimeter security, and integrated security management environments

Integration & Compatibility

The T1AXK3F2S integrates seamlessly into Altronix and AXIS ecosystem deployments. As a dedicated power platform, it supports legacy and modern access control systems, PoE injectors, alarm panels, and surveillance infrastructure requiring stable 24VDC rails. The fused architecture ensures compatibility with fault-tolerant distributed security networks where device isolation prevents cascading failures. Integrators deploying multi-building campuses or large single-site installations benefit from the redundant battery backup topology and native supervision reporting.

Deployment Scenarios

The T1AXK3F2S excels in enterprise access control deployments, healthcare facilities requiring emergency egress backup, retail security networks with door and gate control, and multi-tenant properties where centralized power management reduces installation complexity. The 6-ampere capacity supports 8–12 standard electromagnetic locks, multiple card reader nodes, or a hybrid mixture of control and monitoring equipment. Battery backup ensures that critical exit doors remain accessible and alarm systems remain operational for the duration specified in local fire codes.

Ted Perry

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

I've integrated the Altronix T1AXK3F2S into a dozen campus security networks over the past three years, and it remains one of the most reliable mid-tier power platforms available for access control and emergency backup applications. The combination of regulated 24VDC output, fused distribution, and integrated battery charging creates a foundation that contractors and end customers trust.

Technical Highlights:

• 6-Ampere Capacity: Sufficient for small-to-medium access control nodes without requiring load-splitting or redundant supplies; eFlow monitoring prevents overcurrent conditions gracefully
• Fused Output Design: Each rail is independently protected, meaning a short circuit on one device doesn't cascade to the entire installation — critical for minimizing mean-time-to-restore
• Battery Backup Integration: Built-in charger maintains battery state without external management, simplifying compliance with ADA emergency egress and fire code requirements

Deployment Considerations:

• Calculate total connected device current before installation; 6A supports approximately 8–12 standard electromagnetic locks depending on duty cycle and solenoid type
• Mount the T1AXK3F2S in a controlled environment (electrical closet or MDF) to protect the power plane from environmental stress and unauthorized tampering
• Verify battery backup capacity meets local code hold-up time; this unit charges but does not specify discharge duration — pair with appropriately sized sealed lead-acid or lithium backup
• Use supervision features to monitor power rail health; early detection of failing supplies or battery degradation prevents downtime during critical events

The T1AXK3F2S represents disciplined power architecture for integrators who prioritize fault isolation, system visibility, and regulatory compliance. Specify it where reliability outweighs cost-cutting, and you'll minimize callback service and customer satisfaction issues.
