Altronix AL600RLBV 6A 12/24VDC Power Supply Charger

The Altronix AL600RLBV is a dual-voltage power supply and charger rated for 6A continuous output at selectable 12VDC or 24VDC. Designed for security systems requiring reliable backup power, the AL600RLBV accepts 220VAC input (198–256VAC operating range) and integrates sealed lead-acid or gel-type battery charging with instantaneous AC loss failover.

Key Features

• Selectable 12VDC or 24VDC output voltage
• 6A continuous supply current capacity
• Sealed lead-acid and gel battery charging support
• Instantaneous failover to battery backup upon AC loss
• AC fail, battery presence, and low battery supervision with Form C relay contacts
• AC failure Form C relay contacts for external signaling
• Compact form factor: 7.1" × 4.5" × 2"
• CE European Conformity certification

Applications

• Access control systems requiring backup power
• CCTV and alarm infrastructure in facilities without dedicated UPS
• Remote security equipment installations
• Perimeter intrusion detection systems

Specifications

• Input: 220VAC, 50/60Hz (198–256VAC working range)
• Output: 12VDC or 24VDC selectable, 6A continuous
• Operating Temperature: 0°C to 49°C (32°F to 120°F)
• Dimensions: 7.1" × 4.5" × 2" (180.3mm × 114.3mm × 50.8mm)
• Supervision: AC fail, battery presence, low battery with Form C contacts
• Battery Support: Sealed lead-acid and gel types
• Warranty: Lifetime Limited
• Certification: CE European Conformity
