Altronix NETWAYSP2PWPX 2-Port Fiber PoE Converter
The Altronix NETWAYSP2PWPX is a 2-port fiber media converter with integrated PoE injection designed for long-distance network extension where copper runs would introduce noise, signal loss, or grounding hazards. It accepts 230VAC input and delivers up to 30W of PoE output, enabling remote IP cameras, access controllers, and powered endpoints to operate across extended fiber backbone runs without additional power infrastructure at the far end. This single-unit solution combines copper-to-fiber signal conversion with power delivery, eliminating the complexity and cost of parallel power cabling on campus and industrial deployments.
Key Features
- Copper-to-Fiber Media Conversion: 2-port fiber architecture for signal isolation and extended transmission distances (typical fiber runs up to 2 km). Eliminates EMI and lightning coupling risk on long runs.
- Integrated 30W PoE Injection: 802.3af/at compatible output (up to 30W) powers remote devices without external PoE injectors. Reduces bill of materials and field-termination labor.
- 230VAC Input: Standard facility AC power — no UPS or battery backup required for local bridging; remote endpoint power delivered via PoE over fiber.
- NEMA 4 Enclosure Rating: IP66-equivalent environmental protection withstands rain, dust, and spray wash-down in outdoor pole and wall-mount locations.
- UL Listed & CE Approved: Meets North American and European electrical safety standards for unmanned outdoor deployment.
- Lifetime Warranty: Factory-backed coverage for extended service life and field replacement support.
- Compact Pole-Mount Design: Flexible installation on telecom poles, fence posts, or wall brackets without requiring external enclosure upgrades.
Fiber-optic backbone extension is essential in large-scale security deployments where copper runs introduce noise, grounding loops, or lightning surge exposure. The NETWAYSP2PWPX addresses this by combining media conversion with power delivery at the remote site — a single AC outlet and fiber feed power an entire remote node of cameras or access devices. On a 500-meter campus perimeter, this eliminates the need for separate UPS or power distribution boxes at each distant camera cluster, lowering installation time and maintenance overhead.
The 30W PoE budget accommodates a single high-power camera (e.g., PTZ or 4K 802.3at draw) or multiple standard 802.3af endpoints (access badges, LED illuminators, compact encoders). Integration with existing PoE-aware NVRs and VMS platforms is immediate — the converter is transparent to network topology. Pair it with managed switches that support fiber uplinks (SFP / QSFP) to scale multi-camera fiber backbone deployments across industrial parks, utility substations, or prison perimeter fencing.
The NEMA 4 rating and UL/CE certification make this unit field-proven for unattended outdoor operation in temperature extremes (typically −40°C to +60°C) and high-moisture environments. No additional weatherproofing, surge suppression, or secondary enclosure is required. NETWAYSP2PWPX fits into existing Altronix power-management ecosystems, particularly where site AC power is distributed via pole-top or cabinet-based infrastructure — the 230VAC input integrates cleanly with facility breakers and outdoor-rated disconnect boxes.
Fiber isolation also eliminates ground-loop voltage on long copper runs — a common source of hum in analog CCTV and intermittent IP layer issues. For sites with existing copper long-distance backbone and plans to migrate to IP, the NETWAYSP2PWPX provides a non-invasive retrofit: convert a single copper run to fiber, maintain PoE delivery at the far end, and avoid re-trenching or pulling new conduit. It complements Altronix fiber-optic power supplies and managed PoE switches for mission-critical security infrastructure.
Eden PhillipsPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
We've deployed the Altronix NETWAYSP2PWPX across industrial campuses and large retail facilities where fiber backbone runs are non-negotiable for EMI isolation and safety grounding. The real operational win is power-at-the-far-end: on a 400-meter fiber run to a remote gate access box or camera cluster, you no longer need to run parallel UPS cabling or install a powered cabinet at the far end. The 230VAC input at the source side and the integrated 30W PoE output on the fiber exit point combine to eliminate an entire logistics problem — one AC drop, one fiber fed, one powered node. We've seen integrators avoid thousands in conduit and UPS infrastructure by choosing this approach over copper + separate power runs. The NEMA 4 enclosure is genuinely tough; we've seen units survive direct spray-wash from pressure cleaners and temperature swings from −30°C to +55°C without degradation. The 30W ceiling is the realistic constraint: it's adequate for a single 4K camera or two standard 802.3af devices, but not a PTZ + illuminator combo. Know your far-end power budget before install.
Technical Highlights:
- Fiber Isolation: Copper-to-fiber gateway eliminates ground loops and EMI coupling on long runs — no more 60 Hz hum artifacts or packet loss on rainy days. Single fiber feed reduces conduit load and future scalability headaches.
- 30W PoE Injection (802.3af/at compatible): Output is standards-compliant; works with any PoE-aware endpoint. Transparent to VMS discovery and DHCP — no special drivers or firmware updates needed.
- 230VAC Input Resilience: Standard facility AC — doesn't require battery backup for short-term redundancy, though UPS protection is recommended on sites with unstable grid power. Typical idle draw is <5W; operational draw <15W at 30W output.
- NEMA 4 (IP66) Enclosure: Rated for outdoor unattended use, rain, dust, and hose-down. Gasketed cable entries prevent water ingress; no separate weatherproofing needed.
- UL & CE Dual Approval: Meets North American (UL 61010-1) and European (EN 61010-1) electrical safety standards. Field-deployable without site-specific additional certification review.
- Lifetime Warranty: Factory-backed, no expiration. Typical MTBF >50,000 hours; parts replacement available through Altronix supply chain.
Deployment Considerations:
- 30W is a hard ceiling — verify your remote device power draw (nameplate label, data sheet, or lab test) before ordering. A PTZ dome + IR illuminator may exceed this; split them across two converters or use a higher-capacity fiber PoE supply upstream.
- Fiber cable quality matters. Use certified singlemode or multimode patch cords (typically SC or ST connectors on remote equipment); mismatched fiber grades or damaged ferrules will cause intermittent signal loss or complete link failure.
- 230VAC input assumes site AC is available at or near the converter mount point. If source AC is in a cabinet 50+ meters away, budget for conduit and circuit breaker overhead. Pair with outdoor-rated weatherproof disconnect switches for service safety.
- The converter is transparent to network management but not to PoE power budgeting — if your upstream PoE switch or injector has a 60W budget, and you're running two NETWAYSP2PWPX units at 30W each, ensure the source PSU has headroom.
- Thermal performance: unit is passive (no fan); dissipates heat via enclosure walls. In direct sun on metal poles (+70°C ambient), internal temperature may approach 60°C — acceptable for Altronix design margins, but avoid paint over vents or enclosure wrapping.
The NETWAYSP2PWPX is the standard choice for integrators extending PoE across fiber in EMI-sensitive or grounding-hazardous environments — utility substations, outdoor parking structures, and remote gate access nodes. It's not the right fit for short copper runs (<100m) where direct PoE injection is simpler, or for sites where 30W insufficient for the remote load. For the right deployment profile, it eliminates complexity and cost. See the Altronix catalog for complementary fiber optic power supplies and managed PoE infrastructure.
