Viking E-1600-40A-CE ADA Emergency Phone IP66 Red Surface Mount

Viking Electronics E-1600-40A-CE ADA Emergency Phone with Digital Voice Announcer

Overview

The Viking Electronics E-1600-40A-CE is a handsfree, ADA-compliant emergency phone built for surface-mount deployment on standard analog telephone lines — no separate power supply required, no network infrastructure, no PoE switch to budget. Engineered for stairwells, parking structures, loading docks, and any location where a fast, reliable distress call can mean the difference between a close call and a serious incident, the E-1600-40A-CE draws everything it needs from the phone line itself and survives environments that would defeat lesser hardware. The CE marking confirms conformity with applicable European directives, making this unit the correct choice for installations subject to EU regulatory requirements.

If you are sourcing Viking Electronics emergency phones for a multi-site deployment or evaluating this unit against other models in the emergency phone category, the sections below translate every spec into a real-world deployment implication.

Key Features

• Phone Line Powered (24VDC / 20mA minimum): The E-1600-40A-CE requires no local AC power or PoE infrastructure — the line itself supplies 24VDC at a minimum of 20mA. That eliminates a dedicated electrical circuit, simplifies permits, and keeps the phone operational during a building power failure as long as the PSTN or PBX line stays up. For stairwells and remote elevator lobbies where running conduit is expensive, this is a meaningful installation cost reduction.
• IP66 Enhanced Weather Protection: IP66 means the enclosure is fully dust-tight and withstands high-pressure water jets from any direction — sufficient for covered outdoor locations, wash-down areas, and industrial environments. It is not rated for submersion; if your application involves standing water or underground vault flooding risk, step up to an IP67 or IP68-rated unit.
• Operating Temperature Range -30°F to 170°F: This is a genuinely wide thermal envelope. Most commercial electronics tap out around -4°F to 140°F; the E-1600-40A-CE extends well below that on both ends, making it viable for unheated parking garages in northern climates and hot rooftop or mechanical-room installations without additional thermal management.
• Up to 100% Humidity (EWP rating): Unlike standard products rated to 95% non-condensing, the Enhanced Weather Protection version handles condensing moisture up to 100% relative humidity. Deploy this in car washes, pool mechanical rooms, or coastal installations where standard units fail prematurely from condensation inside the enclosure.
• 5 Emergency Numbers + 2 Central Station Numbers: The digital dialer stores 5 distinct emergency destination numbers and 2 central monitoring station numbers — enough to cover primary dispatch, secondary backup, facility security desk, and overflow paths without burning all slots on redundancy. The 3 additional information numbers support non-emergency announcements or facility-specific informational playback without consuming emergency capacity.
• Non-Volatile Memory: Programmed numbers survive a complete power loss — including extended phone-line outages — without requiring reprogram on restoration. In a campus or multi-building deployment, this eliminates a maintenance burden after utility events and means the unit is immediately operational when power is restored.
• Steel Enclosure with Red Powder Paint Finish: The all-steel housing at 5.25″ × 4.0″ × 2.0″ (133mm × 102mm × 51mm) is resistant to vandalism in a way that ABS plastic housings are not. Red powder paint provides high visibility for code compliance and wayfinding — occupants locate the unit faster under stress. The compact footprint fits standard single-gang or double-gang surface-mount conduit boxes.
• Gel-Filled Butt Connectors: Terminations use gel-filled butt connectors rather than bare wire splices or standard IDC blocks. The gel seals against moisture ingress at the connection point — critical in any outdoor or humid application where moisture wicking into the terminal is the most common field failure mode for analog phone hardware.
• ADA Compliant: The handsfree design and unit layout meet ADA accessibility requirements, which matters for building code compliance in public-access areas, parking structures, and any federally funded facility. Documenting ADA compliance at specification time avoids costly retrofits during inspection.

Integration and Compatibility

The E-1600-40A-CE connects to any standard analog telephone line — PSTN, PBX analog port, or VoIP ATA — provided the line delivers at least 24VDC at 20mA under load. No special programming interface or proprietary controller is required. For facilities integrating emergency phones into a monitored access control or security management system, the two central station number slots allow direct-dial integration with a monitoring station receiver. Pair with a PoE-capable network switch only if you are mixing with IP-based Viking models in the same installation; this unit is strictly analog and draws no network connectivity. Review your emergency communication planning guide to confirm line-seizure behavior with your PBX vendor before deployment across a multi-tenant facility.

Frequently Asked Questions

Q: Does the E-1600-40A-CE require external power or a dedicated electrical circuit?

A: No. The E-1600-40A-CE is fully telephone line powered, drawing 24VDC at a minimum of 20mA from the analog line. No AC outlet, conduit for power wiring, or PoE switch is needed.

Q: What does the CE mark on the E-1600-40A-CE mean, and is it required for my installation?

A: The CE mark indicates conformity with applicable European Union directives. If your project is in the EU or a jurisdiction that requires CE-marked equipment, the E-1600-40A-CE satisfies that requirement. For domestic US-only installations, the base E-1600-40A (without CE suffix) is the standard variant.

Q: How many numbers can be programmed, and will they be lost during a power outage?

A: The unit stores 5 emergency numbers, 2 central monitoring station numbers, and 3 informational numbers — 10 total. All numbers are stored in non-volatile memory and are retained through complete power loss with no reprogram required on restoration.

Q: What is the IP rating, and can this phone be installed outdoors or in a wash-down environment?

A: The E-1600-40A-CE carries an IP66 rating, meaning it is fully dust-tight and rated against high-pressure water jets from any direction. It is suitable for covered outdoor locations, industrial wash-down areas, and similar harsh environments. It is not rated for submersion.

Q: What is the operating temperature range, and is this phone suitable for unheated parking garages or hot mechanical rooms?

A: The operating temperature range is -30°F to 170°F. This exceeds the range of most commercial emergency phones and is suitable for unheated parking structures in cold climates as well as hot rooftop or mechanical-room locations.

Q: Is the E-1600-40A-CE ADA compliant?

A: Yes. The E-1600-40A-CE is ADA compliant by design, with a handsfree operation mode meeting accessibility requirements for public-access locations, parking structures, and federally regulated facilities.

Ted Perry

The detail that consistently matters in emergency phone deployments is power architecture, and the E-1600-40A-CE gets it right: 24VDC at 20mA minimum drawn directly from the analog line means this unit stays operational through a building power event as long as the PBX or PSTN line is live. That is a material advantage over AC-powered units in life-safety applications where a power failure is often the trigger for the emergency itself.

Technical Highlights:

• Non-Volatile Memory: All 10 programmed numbers — 5 emergency, 2 central station, 3 informational — survive complete power loss. In a campus with 30+ phones, not having to reprogram after a utility event is a real maintenance reduction.
• IP66 + Up to 100% Humidity: IP66 blocks dust and high-pressure water jets; the Enhanced Weather Protection rating pushes humidity tolerance to 100%, including condensing environments. Standard commercial enclosures rated to 95% non-condensing fail in car washes and pool areas precisely where emergency phones are most needed.
• -30°F to 170°F Operating Range: This is 26 degrees colder on the low end than the EWP variant's -15°F floor, making the E-1600-40A-CE (often searched as E 1600 40A CE) the correct selection for unheated northern-climate garages and rooftop mechanical equipment rooms where most competitors' hardware is not rated to operate.

Deployment Considerations:

• Surface mount only — the 5.25″ × 4.0″ × 2.0″ steel enclosure requires a flat surface or conduit box backing; there is no flush or recessed mounting option for this model. Confirm wall or column depth before rough-in.
• Line voltage minimum is 24VDC at 20mA: verify your analog port or ATA delivers this under load, especially on older PBX hardware where line voltage sags under simultaneous call load across many extensions.

The E-1600-40A-CE is the correct specification for covered outdoor parking structures, industrial facilities with wash-down zones, and EU-regulated installations where the CE mark is a procurement requirement — particularly where AC power is unavailable and the budget does not support conduit runs to each phone location.
