Viking E-1600-45A-CE ADA Emergency Phone IP66 Surface Mount CE

Viking Electronics E-1600-45A-CE ADA Emergency Phone with Voice Announcer

Overview

The Viking Electronics E-1600-45A-CE is a surface-mount ADA-compliant emergency phone designed for demanding environments where reliable one-touch emergency communication is non-negotiable. Finished in safety yellow with a 16-gauge steel housing, this unit is built for parking structures, elevator lobbies, stairwells, and industrial facilities where visibility and weather resilience matter equally. The CE Mark makes it suitable for deployments requiring European conformity. If you're speccing an emergency call station that needs to survive temperature swings, driving rain, and daily rough handling — the E-1600-45A-CE delivers a defensible, code-conscious solution.

Key Features

• IP66 Weather Protection: Rated IP66 against powerful water jets and total dust ingress — suitable for covered outdoor locations, loading docks, and parking garages without an additional enclosure. This is not a splash-rated unit; IP66 means directed hose-down survivability.
• 5 Programmable Emergency Numbers + 2 Central Station Lines: Seven total programmable destinations give you flexibility to sequence through on-call staff, a central monitoring station, or a backup PSAP — all without user training. Callers press one button; the dialer handles the rest.
• -15°F to 130°F Operating Range: Handles sub-zero northern winters and sun-baked equipment rooms alike. Cold-climate installs in unheated stairwells or covered parking decks won't trip a low-temperature failure; hot rooftop mechanical rooms stay within spec.
• 16-Gauge Steel Construction with Yellow Powder Coat: Heavier-gauge than typical ABS-shell call stations — resists vandalism, impact, and UV degradation. The textured yellow powder paint ensures high-contrast visibility for ADA compliance and emergency wayfinding without fading under UV exposure.
• Compact Footprint at 5.25″ × 4.0″ × 2.0″: At under half a foot tall, the unit fits on a standard single-gang surface backbox or custom surface mount without requiring a large wall cutout — useful in tight elevator cab corners or narrow corridor columns.
• Gel-Filled Butt Connector Terminations: Field wiring uses gel-filled butt connectors rather than bare screw terminals, providing moisture-sealed connections that resist corrosion in humid or washdown areas — a meaningful longevity advantage over standard terminal blocks.
• Voice Announcer Functionality: Audible status announcements confirm call progress to the user — a critical ADA-aligned feature that serves callers with visual impairments and reduces false-alarm callbacks when callers can hear system status without visual indicators.
• CE Mark Compliance: Certifies conformity with applicable European directives, making this model the correct choice when the project requires CE documentation for European installations or multinational facilities.

Integration and Compatibility

The E-1600-45A-CE connects to standard POTS (plain old telephone service) analog lines and is compatible with on-premise PBX systems supporting analog station ports. The unit is surface-mount only — flush or recessed mounting is not supported, so verify wall construction and backbox availability at each location during the design phase. For emergency phone deployments across a campus or parking structure, pair with a Viking Electronics line of central answering equipment or integrate with an existing attendant console via standard analog loop-start signaling. Coordinate with your access control design to ensure emergency phone locations align with egress path planning. For multi-building campuses, review Viking's 1600A Series family to identify IP-based variants if VoIP infrastructure is already in place.

Frequently Asked Questions

Q: Is the E-1600-45A-CE suitable for outdoor installation?

A: Yes, with caveats. The IP66 rating means it withstands powerful water jets and dust, making it appropriate for covered outdoor areas like parking structures and loading docks. It is not rated for full submersion. Verify that the installation location provides protection from direct prolonged rainfall if possible.

Q: What is the operating temperature range for the E-1600-45A-CE?

A: The unit operates from -15°F to 130°F (-26°C to 54°C). This covers most North American climate extremes in covered or semi-sheltered locations.

Q: How many emergency numbers can be programmed?

A: The E-1600-45A-CE supports five programmable emergency numbers plus two central station numbers, for a total of seven dialing destinations. The dialer sequences through these automatically on activation.

Q: Is the E-1600-45A-CE ADA compliant?

A: Yes. The unit is designed to meet ADA requirements for emergency communication, including voice announcer functionality that provides audible call-progress feedback for users with visual impairments.

Q: What mounting options does the E-1600-45A-CE support?

A: Surface mount only. Flush or recessed mounting is not supported. Plan backbox placement and wall construction accordingly during the design phase.

Q: What does the CE Mark on this model mean?

A: The CE Mark indicates conformity with applicable European Union directives, making this variant appropriate for projects requiring European compliance documentation. The base E-1600-45A without CE Mark is the standard North American variant.

Jerry Tildsen

The E-1600-45A-CE is one of those units where the spec sheet tells you exactly what you need to know before the first site walk. The IP66 rating combined with a -15°F to 130°F operating window means you can drop this into a northern parking deck or a sun-exposed loading dock corridor without engineering a custom enclosure around it — the housing does the work. The CE Mark variant is specifically worth calling out: if you're working on a multinational campus or a European facility expansion, pulling E-1600-45A-CE instead of the base model saves a compliance headache later.

Technical Highlights:

• 7 Programmable Destinations: Five emergency numbers plus two central station lines give dispatching flexibility without user-facing complexity — one button press, the dialer handles sequencing.
• 16-Gauge Steel Housing: Noticeably heavier construction than plastic-shell competitors. In high-vandalism environments like transit stations or public parking structures, gauge matters for longevity.
• Gel-Filled Butt Connectors: Factory-specified termination method seals the field splice against moisture intrusion — important in any install where condensation or washdown is a factor. Don't substitute open-barrel connectors on these.

Deployment Considerations:

• Surface-mount only — confirm backbox availability and wall substrate at every location before finalizing the design. There is no flush-mount option in this chassis.
• The 5% to 95% non-condensing humidity spec applies to this model; if your install location sees condensation cycles (cold storage anteroom, covered marine dock), evaluate the EWP variant instead, which is rated to 100% humidity.

Best fit for covered parking structures, industrial facility egress paths, and campus emergency call station networks where ADA compliance, CE documentation, and weather resilience need to be checked off simultaneously — without a custom enclosure budget.
