Panduit AFR4WTROS Pan-Way Wall Transition - Office Slate

Panduit AFR4WTROS Pan-Way Above Floor Raceway Wall Transition Fitting

The Panduit AFR4WTROS provides a professional wall transition point for Pan-Way Above Floor Raceway installations. This single-piece steel fitting routes cables from floor-mounted raceway up wall surfaces in conference rooms, executive offices, and AV equipment locations where concealed conduit isn't feasible. The Office Slate powder-coat finish matches Panduit's Pan-Way AFR accessory line for visual continuity across multi-room deployments. Measures 4.62" high by 7.16" wide. Ships in 10-piece project cartons.

Key Features

• Office Slate powder-coat finish integrates with corporate interior palettes and Pan-Way AFR raceway accessories
• Single-piece stamped steel construction eliminates field assembly and provides rigid cable protection at transition points
• 4.62" height accommodates standard AFR raceway profiles plus cable bend radius clearance per TIA-568 recommendations
• 7.16" width spans floor-to-wall joint gaps and provides screw mounting flanges for attachment to wood studs or masonry anchors
• UL/cUL listed as surface raceway component for commercial power and low-voltage cable routing applications
• 10-piece carton quantity supports multi-room rollouts and reduces per-piece logistics cost on large AV or access-control projects

The AFR4WTROS uses 20-gauge cold-rolled steel with an electrostatically applied and baked powder-coat finish that resists scratches during installation and provides long-term color retention in high-traffic areas. Internal cable guides molded into the transition's rear wall maintain separation between power and low-voltage conductors when routing mixed cabling per NEC 725.136(A). The fitting's 4.62" interior height leaves 1.5" of clearance above a fully populated two-channel AFR base, preventing Category 6A cables from exceeding the 1" minimum bend radius during the 90° turn from horizontal to vertical routing. Mount the unit with four #10 screws through pre-punched holes in the top and bottom flanges—wood screws into studs at 16" on-center spacing, or masonry anchors into concrete or CMU walls. The top flange's slotted holes provide ±0.25" vertical adjustment to align with raceway runs that drift slightly off-level across long distances. Pair with Panduit AFR series base, cover, inside elbow, outside elbow, and end-cap accessories; all share the same Office Slate finish lot for consistent appearance.

Install AFR4WTROS fittings at podium locations in conference rooms where floor-mounted raceway delivers microphone, HDMI, and power to the presenter position, then transitions up the wall to connect with ceiling-mounted displays or in-wall AV switching equipment. Use at reception desks to route access-control card readers, IP phones, and networked PCs from underfloor raceway through the desk's rear panel to wall-mounted patch panels. In open-plan offices, deploy at workstation clusters where modular furniture systems terminate and cabling must rise to wall-mounted wireless access points or security cameras. The Office Slate color coordinates with gray modular furniture, brushed aluminum finishes, and neutral commercial carpet tiles common in Class A office environments. For installations requiring plenum-rated cable routing above finished ceilings or through return-air spaces, verify local AHJ requirements—surface raceway fittings themselves don't require plenum rating, but cables inside the raceway must meet NEC 800.113 or 725.179 if the raceway penetrates a plenum space.

AFR4WTROS fittings carry cULus listing under UL Standard 5A (surface metal raceways) for use in dry indoor locations. The powder-coat finish provides corrosion resistance in humidity-controlled commercial interiors but isn't rated for outdoor or wet-location deployment. When installing in facilities subject to seismic design requirements (IBC Seismic Design Categories D, E, or F), mount fittings to structural framing per ASCE 7 Chapter 13 nonstructural component anchorage provisions—typically requiring anchors rated for 1.5× the fitting's installed weight under simultaneous vertical and horizontal accelerations. The Office Slate finish distinguishes these fittings from Panduit's Off-White (FPWH) and Electric Ivory (FPEI) alternatives, making it the first-choice option for modern office installations where gray-scale neutrality matters more than legacy color-matching to aged plastic faceplates.
