Frame Rate:
30fps
Sensor Type:
1/2.8" progressive scan CMOS
Max. Resolution:
1920 × 1080
Min. Illumination:
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR
Shutter Speed:
1/1 s to 1/30,000 s
Day & Night:
IR cut filter
Zoom:
20x optical, 16x digital
Focal Length:
4.7 mm to 94 mm
Field of View:
Horizontal FOV 54.9° to 2.7°, vertical FOV 31.5° to 1.5°, diagonal FOV 62.3° to 3.1°
Focus:
Auto, semi-auto, manual
Aperture:
Max. F1.6
Zoom Speed:
Approx. 3.2 s (Optical Lens, Wide-Tele)
Supplement Light Type:
IR
Supplement Light Range:
IR Distance: up to 50 m
Smart Supplement Light:
Yes
Movement Range (Pan:
360° endless
Movement Range (Tilt:
From -40° to 30°
Pan Speed:
Configurable, from 0.5°/s to 60°/s. Preset speed: 60°/s
Tilt Speed:
Configurable, from 0.5°/s to 50°/s. Preset speed: 50°/s
Proportional Pan:
Yes
Presets:
300
Preset Freezing:
Yes
Patrol Scan:
8 patrols, up to 32 presets for each patrol
Pattern Scan:
4 pattern scans, record time over 10 minutes for each scan
Park Action:
Preset/Pattern Scan/Patrol Scan
PTZ Status Display:
Yes
Scheduled Task:
Preset/Pattern Scan/Patrol Scan/Dome Reboot/Dome Adjust/Aux Output
Power-Off Memory:
Yes
Main Stream:
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720); 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720);
Sub-Stream:
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288);60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)
Video Compression:
Main Stream: H.265+/H.265/H.264+/H.264;Sub-Stream: H.265/H.264/MJPEG
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Baseline Profile/Main Profile/High Profile
H.265 Type:
Main profile
Scalable Video Coding (SVC:
H.264 and H.265 encoding
Region Of Interest (ROI:
8 fixed regions for each stream
Audio Compression:
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate:
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps to 160 Kbps(MP2L2)
Protocols:
IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour
Simultaneous Live View:
Up to 20 channels
API:
Open Network Video Interface (Version 18.12, Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
User/Host:
Up to 32 users; 3 levels: Administrator, Operator and User
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security aud
Network Storage:
NAS (NFS, SMB/CIFS), ANR
Client:
iVMS-4200, HikCentral Pro, Hik-Connect
Web Browser:
IE10-11, Chrome 57.0+, Firefox 52.0+, Safari 12+
Image Settings:
Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
Wide Dynamic Range (WDR:
120 dB
Defog:
Digital defog
Image Enhancement:
BLC, HLC, 3D DNR
Privacy Mask:
24 programmable polygon privacy masks, mask color configurable
Regional Focus:
Yes
Regional Exposure:
Yes
Ethernet Interface:
1 RJ45 10 M/100 M Ethernet Interface; PoE (802.3at, class4)
On-Board Storage:
Built-in memory card slot, support MicroSD/SDHC/SDXC, up to 256 GB
Audio Support:
1 input, 1 output
Alarm:
1 input, 1 output
Basic Event:
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), alarm input and output
Smart Event:
Face detection, line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection
Linkage:
Alarm actions, such as Preset, Patrol Scan, Pattern Scan, Memory Card Video Record, Trigger Recording,audible warning, Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send Email, etc.
Power Type:
PoE+
Dimension:
255 mm × 129 mm × 195 mm (10.04" × 5.08" × 7.68")
Weight:
Approx. 3 kg (6.61 lb)
Operating Condition:
-30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing)
Language:
33 languages.;English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Tradition
Protection:
IP66 Standard; 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
Housing Color:
White
