Frame Rate:
20fps
Sensor Type:
1/2.5" Progressive Scan CMOS
Min. Illumination:
0.01 Lux (F1.2, AGC ON)
Shutter Speed:
1/3 s to 1/100,000 s
Slow Shutter:
Yes
Wide Dynamic Range:
120dB
Day & Night:
IR Cut Filter
Angle Adjustment:
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Focus:
Fixed
Lens Type:
2.8/4/6/8 mm
Field of View:
102° horizontal (2.8mm), 79° (4mm), 50° (6mm), 40° (8mm)
Aperture:
F2.0
Lens Mount:
M12
Aperture Type:
Fixed
IR Distance:
Up to 30 m
Wavelength:
850nm
Max. Resolution:
3840 × 2160
Main Stream:
50Hz: 12.5 fps (3840 × 2160), 20fps (3072 × 1728), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720),60Hz: 15 fps (3840 × 2160), 20fps (3072 × 1728), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Sub Stream:
25-30fps, up to 640×480
Third Stream:
25fps 1280×720 (50Hz) / 30fps 1280×720 (60Hz)
Video Compression:
H.265/H.264, MJPEG (3 streams)
Video Bit Rate:
32 Kbps to 16 Mbps
H.264 Type:
Main Profile/High Profile
H.265 Type:
Main Profile
H.264:
Main stream supports
H.265:
Main stream supports
Scalable Video Coding (SVC:
H.264 and H.265 encoding support
Simultaneous Live View:
Up to 6 channels
API:
ONVIF (PROFILE S, PROFILE G), ISAPI
Protocols:
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
User/Host:
Up to 32 users,3 levels: Administrator, Operator and User
Security:
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
Network Storage:
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Client:
iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
Chrome 57+, Firefox 52+, Safari 11+, IE8+
Alarm Trigger:
Motion detection, tampering, network, login alert
Day/Night Switch:
Day/Night/Auto/Schedule
Target Cropping:
No
DNR:
3D DNR
Image Enhancement:
BLC/3D DNR/HLC
Image Settings:
Saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Video Outputs:
No
On-Board Storage:
Built-in microSD/SDHC/SDXC slot, up to 128 GB
Hardware Reset:
Yes
Communication Interface:
1 RJ45 10M/100M self-adaptive Ethernet port
Basic Event:
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Smart Event:
Line crossing detection, intrusion detection, face detection
Face Detection:
Yes
Linkage Method:
Memory card, network storage, FTP, HTTP, NAS, Email
Firmware Version:
5.6.3
Web Client Language:
32 languages
General Function:
One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Startup And Operating Conditions:
-30°C to +60°C, 95% humidity non-condensing
Power Type:
12 VDC ± 25%, Φ 5.5 mm ,PoE(802.3af, class 3)
Power Consumption And Current:
12V 0.5A (6W) / PoE+ (7.5W)
Camera Dimension:
Φ 70 mm × 155 mm
Camera Weight:
Camera: approx. 410 g (0.9 lb.)
Protection:
IP67
Housing Color:
White
