Type:
Dome
Frame Rate:
30fps
Imaging Device:
1/2.8" CMOS
Resolution:
1920×1080
Max. Framerate:
30fps @ 2MP
Min. Illumination:
0.03 Lux color / 0 Lux IR
Video Out:
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation
Focal Length (Zoom Ratio:
3.2~10mm(3.1x) motorized varifocal
Max. Aperture Ratio:
F1.6(Wide)~F2.9(Tele)
Angular Field of View:
H: 109°, V: 58°
Min. Object Distance:
0.5m (1.64ft)
Focus Control:
Simple focus
Lens Type:
DC auto iris
Pan / Tilt / Rotate Range:
0°~350° / 0°~67° / 0°~355°
Camera Title:
Displayed up to 85 characters
Day & Night:
Auto(ICR)
Backlight Compensation:
BLC, WDR, SSDR
Wide Dynamic Range:
120dB
Digital Noise Reduction:
SSNR
Motion Detection:
4ea, polygonal zones
Privacy Masking:
6ea, rectangular zones
Gain Control:
Low / Middle / High
White Balance:
ATW / AWC / Manual / Indoor / Outdoor
LDC:
Support
Electronic Shutter Speed:
Minimum / Maximum / Anti flicker (1/5~1/12,000sec)
Video Rotation:
Flip, Mirror, Hallway view(90˚/270˚)
Analytics:
Motion detection, Tampering, Defocus detection, Virtual area(Intrusion/Enter/Exit), Virtual line(Crossing/Direction)
Alarm Inputs/Outputs:
Input 1ea / Output 1ea
Alarm Triggers:
Analytics, Network disconnect, Alarm input
Alarm Events:
File upload via FTP and e-mail; Notification via e-mail; SD/SDHC/SDXC or NAS recording at event triggers; Alarm output; Handover(PTZ preset)
Audio In:
Built-in mic
Light Type:
IR LED (850nm)
Light Viewable Length:
20m(65.62ft)
Ethernet:
RJ-45(10/100BASE-T)
Video Compression:
H.265/H.264: Main/High, MJPEG
Audio Compression:
G.711 u-law /G.726 Selectable, G.726(ADPCM) 8KHz, +more
Smart Codec:
WiseStreamⅡ
Bitrate Control:
H.264/H.265: CBR or VBR; MJPEG: VBR
Streaming:
Unicast(6 users) / Multicast; Multiple streaming(Up to 3 profiles)
Protocol:
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP
Application Programming Interface:
ONVIF Profile S/G/T; SUNAPI(HTTP API); Wisenet open platform
OS / Firmware Protect:
Firmware encryption
User authentication:
Digest Authentication, Prevent brute-force attack
Network authentication:
802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2)
Secure Communication:
HTTPS, SRTP, WSS(Websocket secure)
Access Control:
Access control based on IP address
Data Protect:
Authentication & ZIP encryption
Audit:
User Access/System/Event log management
Device ID:
Device Certificate(Hanwha Private Root CA)
Secure Storage:
SDcard partition encrypt
Webpage Language:
English, Korean, Chinese, French, Italian, +more
Edge Storage:
Micro SD/SDHC/SDXC 1slot 128GB
RAM:
512MB RAM, 256MB Flash
Operating Temperature / Humidity:
-10°C~+55°C(+14°F ~ +131°F) / 0~90% RH
Storage Temperature / Humidity:
-30°C~+60°C(-22°F ~ +140°F) / 0~90% RH
Input Voltage:
PoE(IEEE802.3af, Class3), 12VDC
Power (Max:
7.70W
Color / Material:
White / Plastic
RAL Code:
RAL9003
Product Dimensions / Weight:
ø119.8x98.8mm(ø4.72x3.89"), 320g(0.71 lb)
Detect (25PPM/ 8PPF:
Wide: 27.4m(89.85ft) / Tele: 128.8m(422.56ft)
Observe (63PPM/ 19PPF:
Wide: 11.0m(35.94ft) / Tele: 51.5m(169.02ft)
Recognize (125PPM/ 38PPF:
Wide: 5.5m(17.97ft) / Tele: 25.8m(84.51ft)
Identify (250PPM/ 76PPF:
Wide: 2.7m(8.99ft) / Tele: 12.9m(42.26ft)
Product Type:
Dome
Connectivity:
Wired
IP Rating:
IP66
Features:
WDR
Night Vision:
IR
Power Type:
PoE
PoE Class:
3
Form Factor:
Dome
Compatibility:
ONVIF
IR Distance:
0.5m
Built-in IR:
Yes
Day/Night:
Yes
Storage Support:
microSD
HTTPS Encryption:
Yes
WDR:
WDR
Weight Lbs:
0.71
Housing Color:
White
Environment Rating:
Outdoor
Warranty:
3-year warranty
Poe Power:
PoE (802.3af)
Ir Lowlight:
IR
Compression:
H.265; H.264; MJPEG
Onvif:
Yes
Audio:
Audio input
Lens Focal Length:
Varifocal
Camera:
Title Displayed up to 85 characters, 5 lines, English / Numeric / Special & International characters, 6 colors, Transparency, Auto scale by resolution
Ethernet Rate:
RJ-45 (10/100BASE-T)
Application:
Programming Interface SUNAPI (HTTP API)
Memory:
512MB RAM, 256MB Flash
Operating Temp:
/ Humidity -10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH
Storage:
Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
Brand:
Hanwha
MPN:
QND-6082R
Power:
12V DC
