Hanwha PWR-P-POE30 30W PoE+ Injector
Overview
The Hanwha PWR-P-POE30 is a single-port 802.3at PoE+ injector rated at 30W — a practical solution when you need to power an IP camera or PoE-capable device at a location where your existing switch lacks PoE output. Rather than swapping out infrastructure, the PWR-P-POE30 slots in between your non-PoE switch port and the connected device, delivering compliant power over the same Cat cable carrying data. For Hanwha Vision IP cameras and other 802.3at-compatible endpoints, this injector keeps the install clean without additional power runs.
The white housing blends into drop-ceiling and above-tile installations commonly found in commercial offices, retail environments, and light industrial spaces — less conspicuous than a raw power adapter hanging from a conduit. If you're building out a surveillance camera system and need to extend PoE to a handful of cameras on a legacy switch, the PWR-P-POE30 addresses that gap one port at a time.
Key Features
- 30W 802.3at PoE+ output: Delivers up to 30 watts per port — enough headroom for most PTZ cameras, IR domes, multi-sensor cameras, and access control readers that draw more than the 15.4W ceiling of older 802.3af devices. If your camera spec sheet lists PoE+ as a power requirement, this injector covers it without negotiation.
- IEEE 802.3at standards compliance: Interoperates with any 802.3at-compatible powered device. The handshake is standards-based, so you're not locked into Hanwha-only endpoints — useful in mixed-vendor environments where a PoE switch upgrade isn't in the current budget.
- Single-port form factor: Each PWR-P-POE30 powers one device independently. That isolation is a feature in deployments where you need per-camera power control — cycling one injector resets one camera without touching the rest of the run.
- White housing: Low-profile white enclosure suits above-ceiling or wall-mounted installs in commercial interiors. In environments where aesthetics matter — lobbies, retail floors, healthcare corridors — the white finish is less visually disruptive than a black or gray device.
- Passive data pass-through: The data signal passes through the injector untouched. You're not adding a managed device to the network path — latency impact is negligible, and there's no configuration overhead. Plug in, power up, done.
Integration & Compatibility
The PWR-P-POE30 is compatible with any IP device that accepts 802.3at PoE+ power, including the full range of Hanwha Vision cameras that specify PoE+ input. It also works with 802.3af (PoE) devices at lower draw — the injector negotiates down to what the powered device requests. Pair it with a non-PoE network switch to extend PoE capability to individual ports without a full infrastructure replacement. No special software, drivers, or firmware is required on either end of the connection.
Frequently Asked Questions
Q: What is the maximum power output of the PWR-P-POE30?
A: The PWR-P-POE30 delivers up to 30W per port in compliance with the IEEE 802.3at (PoE+) standard.
Q: Will the PWR-P-POE30 work with 802.3af (standard PoE) devices that draw less than 15.4W?
A: Yes. 802.3at injectors are backward-compatible with 802.3af powered devices. The injector negotiates power delivery based on what the connected device requests, so lower-draw 802.3af cameras and readers will operate correctly.
Q: Does the PWR-P-POE30 work with non-Hanwha cameras and devices?
A: The PWR-P-POE30 is a standards-based 802.3at injector. It will power any compliant 802.3at or 802.3af device regardless of manufacturer, as long as the device accepts PoE input over a standard RJ-45 connection.
Q: Does the injector require any configuration or software?
A: No. The PWR-P-POE30 is plug-and-play. It has no management interface, requires no drivers, and no firmware configuration. Data passes through transparently while power is injected over the same cable.
Q: How many devices can the PWR-P-POE30 power simultaneously?
A: The PWR-P-POE30 is a single-port injector. It powers one device per unit. For multi-port PoE delivery, a PoE switch or multi-port injector would be the appropriate solution.
The PWR-P-POE30 fills a specific gap I see often in staged camera rollouts: a perfectly good non-PoE switch with unused copper ports, and a handful of cameras that need PoE+ power. Rather than pulling a new power home-run or swapping switch hardware mid-project, this 30W 802.3at injector lets you add powered ports one at a time as cameras go in — which matters when phased installs are being billed in stages and the full switch upgrade is coming later.
Technical Highlights:
- 30W 802.3at output: Covers the full PoE+ envelope — PTZ cameras, multi-sensor domes, and access readers that exceed the 15.4W 802.3af ceiling will run without underpower shutdowns or erratic behavior.
- Standards-based handshake: IEEE 802.3at compliance means the injector negotiates correctly with any compliant powered device, Hanwha or otherwise. No proprietary quirks to debug at 2am when a camera won't come online.
- Plug-and-play, no management overhead: No IP address, no VLAN config, no firmware to update. Data passes through without adding a hop that could introduce latency or a failure point in the network path.
Deployment Considerations:
- Each PWR-P-POE30 powers a single port — plan your unit count per camera head, not per switch. Budget one injector per camera that needs PoE on a legacy non-PoE port.
- Verify your wall outlet or power strip capacity before stacking multiple injectors in an IDF closet — each unit draws from AC mains, and a cramped closet with six injectors will need adequate circuit capacity and physical cable management.
The PWR-P-POE30 (often searched as PWR P POE30) is the right tool for phased commercial camera deployments where legacy switch infrastructure is staying in place and you need PoE+ at specific drops without a full infrastructure refresh.
