Panduit UTP28SP8INOR Cat 6 Patch Cord
The Panduit TX6-28 UTP28SP8INOR solves high-density patching problems that standard 24 AWG patch cords create. At 8 inches long with a 3.8mm (0.150-inch) diameter—roughly 40% thinner than conventional Category 6 cords—this 28 AWG cable reduces bundle congestion, improves airflow in densely populated racks, and simplifies moves, adds, and changes in network closets and data centers. Factory-installed RapidID barcodes enable fast port mapping and documentation without aftermarket labeling. Built on stranded copper conductors with high-performance modular plugs, it delivers full Category 6 performance to 250 MHz while fitting more circuits into less space.
Key Features
- 28 AWG stranded copper construction—3.8mm diameter for 40% better density vs. 24 AWG cords
- RapidID pre-installed barcodes for automated port mapping and documentation
- Patented tangle-free latch prevents snags during installation and service
- 100% factory tested for wire map, NEXT, and return loss
- Supports Gigabit Ethernet (1000BASE-T), Fast Ethernet, ATM, VoIP, and analog/digital video
- PoE++ (802.3bt Type 4) rated for 24-cable bundles; 802.3at/af rated for 48-cable bundles
- Centered de-embedded plug design and integral pair manager for consistent electrical performance
The 28 AWG gauge addresses a practical problem in modern network infrastructure: ToR switch density has outpaced traditional cabling. When you're patching 48-port switches with standard 24 AWG cords, cable bulk blocks airflow and makes troubleshooting difficult. The UTP28SP8INOR's compact diameter lets you route more cables through the same cable management without overfilling—critical when you're working within the 40% fill ratio guidelines for cable trays and ladder rack. Stranded copper conductors provide flexibility for tight bend radii around vertical managers and horizontal rings. The centered de-embedded plug and integral pair manager maintain pair geometry through the termination, keeping crosstalk and return loss well within TIA-568.2-D Category 6 limits across the full 1–250 MHz spectrum. Factory testing on every cord verifies wire map continuity, near-end crosstalk (NEXT), and return loss before it ships.
Eight-inch length is purpose-built for short-hop patching: switch-to-switch stacking, patch panel to adjacent switch, and server NIC to ToR port scenarios where a one-foot cord leaves excess slack and a six-inch cord barely reaches. The orange jacket provides instant visual identification for voice VLANs, out-of-band management networks, or whatever color-coding scheme your documentation standard requires. RapidID barcodes are printed directly on the cable during manufacturing—scan both ends during installation and the RapidID software auto-populates your port map, eliminating manual spreadsheet entry and the labeling errors that cause after-hours troubleshooting. The tangle-free latch design uses a snag-resistant boot geometry that releases cleanly even in tightly bundled environments, so moves and changes don't turn into a cable-pulling wrestling match.
Exceeds ANSI/TIA-568.2-D Category 6 and ISO 11801 Class E requirements. Meets TIA-1096-A modular plug performance standards and IEC 60603-7 mechanical specifications. cULus Listed under UL 1863 and CAN/CSA-C22.2 No. 214 (File E129886). CM/LSZH flame rating supports both North American plenum-equivalent and international low-smoke installations. PoE++ (802.3bt Type 3 and Type 4) qualification at 24 cables per bundle means you can power high-wattage devices—PTZ cameras, 802.11ax access points, IP phones with video—without derating or oversizing bundles. RoHS compliant for EU and California installations. For integrators managing long-term network operations, Panduit's TX6-28 line delivers the termination consistency and documented performance that keep networks running between refresh cycles.
