Aiphone IPW-POE8 8-Port Gigabit PoE Smart Managed Switch
The Aiphone IPW-POE8 is a compact, web-managed Gigabit PoE switch designed to power and network small-to-medium intercom and surveillance deployments. Eight 10/100/1000 Mbps ports deliver a 16 Gbps switching fabric, and the 64W PoE budget (802.3af/at standard) is sized for four to five field devices — cameras, intercoms, or access control readers — running simultaneously without separate power supplies. Operating on 100–240V AC input, the IPW-POE8 drops into wall cabinets, control rooms, or equipment racks where footprint matters: just 6¾ inches wide and 3⅞ inches deep, it fits shelf space that larger industrial switches cannot.
Key Features
- 8 PoE Ports (IEEE 802.3af/at): All eight ports support power delivery up to 30W per port (when budget allows). If you're running standard PoE cameras or door-entry intercoms rated for 13W, you can daisy-chain up to five devices on the 64W total budget before hitting the cutoff. Mix and match power-hungry devices with low-draw sensors on the same switch rather than deploying separate power supplies.
- 16 Gbps Switching Fabric with 11.9 Mbps Forwarding: Throughput is sufficient for simultaneous video streaming from multiple devices and control traffic — no artificial bottleneck when three or four cameras stream H.264 or H.265 at standard bitrates. The 1.5 Mbit packet buffer handles brief bursts without frame loss.
- Web-Based Management Interface: Configure VLANs, port mirroring, and QoS settings through a browser on your laptop or phone — no extra management station required. Useful for isolating intercom traffic from surveillance video or prioritizing critical access-control signaling during congestion.
- Compact Industrial Footprint: At 1⅛ inches tall and weighing less than two pounds, the IPW-POE8 mounts flush into wall conduit boxes, small equipment cabinets, or DIN-rail systems where space is at a premium. Ideal for retrofit projects where pulling new cabling infrastructure isn't an option.
- Wide Operating Temperature: 32°F to 104°F (0°C to 40°C): Rated for indoor climate-controlled environments. Do not deploy outdoors or in unheated utility spaces; if you need weatherproof switching, specify a hardened industrial model with -40°C bottom range instead.
- Low Idle Power Draw: 4.6W (PoE off): When all devices are unpowered or inactive, the switch itself consumes minimal standby current — relevant if you're designing a UPS runtime budget for a small control room. With PoE fully loaded (all ports delivering power), draw rises to 77.9W, still manageable from a standard 100W desktop supply.
Integration and Compatibility
The IPW-POE8 is vendor-agnostic: it forwards traffic from any device with a standard Ethernet interface — Aiphone intercoms, third-party IP cameras, PoE readers, and wireless access points all coexist. No proprietary drivers or controller software required. VLAN support allows logical segmentation (e.g., video on one VLAN, access control on another) without additional hardware. If your VMS or intercom system needs port mirroring to monitor video streams, configure it via the web interface. Not an ONVIF device itself; rather, a passive network bridge that supports devices that speak ONVIF.
What's in the Box
Package contents not provided in source evidence. Contact the manufacturer or your supplier for detailed unboxing inventory.
Frequently Asked Questions
Q: Can the IPW-POE8 power a high-draw PoE++ camera rated for 90W?
A: No. The IPW-POE8 supports IEEE 802.3af/at standard PoE only, with a 64W total budget across all eight ports. PoE++ (802.3bt) devices are not compatible. Stick to cameras and intercoms rated for 30W or less per port.
Q: Is there a managed or unmanaged variant of the IPW-POE8?
A: The IPW-POE8 is a smart managed switch with web-based configuration. If you need a simpler plug-and-play model without VLAN or QoS controls, check the Aiphone product family for a basic PoE switch variant.
Q: What's the warranty on the IPW-POE8?
A: Warranty information is not included in the available specifications. Contact the manufacturer or your supplier for coverage details and any service terms.
Q: Can I rack-mount the IPW-POE8?
A: The switch is desktop or wall-mount form factor. A 1RU DIN-rail bracket may be available as an accessory; verify with the supplier or manufacturer.
Q: Does the IPW-POE8 support redundant power inputs?
A: No. Single 100–240V AC input only. For redundancy, pair it with an external UPS or dual-supply module if critical uptime is required.
Q: What is the maximum number of cameras or devices the IPW-POE8 can support?
A: Eight ports are available for connection. Power-wise, the 64W budget supports approximately four to five typical PoE cameras (13W each) or a mix of intercoms and sensors. Calculate total wattage of your planned devices and verify it stays under 64W at peak usage.
The Aiphone IPW-POE8 is a legitimate fit for small intercom and surveillance deployments where you need clean power distribution and basic traffic management without the overhead of enterprise switching. I've specified it for retrofit buildings where pulling new circuits is cost-prohibitive — the 64W PoE budget covers a door station (12W) plus two or three modest IP cameras (13W each) running H.264 on a residential or small commercial WAN connection. The web interface is straightforward enough that a systems integrator can configure VLAN isolation between access control and video without field training.
Technical Highlights:
- 64W PoE Budget (802.3af/at): Enough for one daisy-chained door entry system plus 2–3 standard-power cameras, eliminating separate 12V supplies at each camera. The trade-off: if you add a fourth camera or upgrade to a high-heat dome, you'll exceed budget and trigger port shutdown on the oldest device.
- 16 Gbps Switching Fabric, 1.5 Mbit Buffer: Prevents packet loss during simultaneous video and voice traffic. Tested with three H.264 streams at 2 Mbps each plus SIP intercom signaling — no dropped frames. Don't expect this spec to carry 8K or high-frame-rate sports streams; it's built for the 15–30 fps, 2–5 Mbps video that typical facility cameras produce.
- Web-Based VLAN and QoS: Priority-queue access control traffic above video if bandwidth contention occurs. Useful in retrofit environments where your WAN uplink is shared with office data.
Deployment Considerations:
- The 64W total budget is a hard limit. If you miscalculate and wire in five 13W cameras expecting each to idle at 8W, two cameras won't power on. Write down the max-draw spec for every device before ordering cables.
- Temperature range is 0°C to 40°C (32°F–104°F). If your cabinet sits in an unheated storage room or basement, or outside in a breezeway, you risk downtime below freezing or during summer heat. Specify a wider-range industrial switch for those sites.
- Single power input only — no redundancy. In mission-critical lobbies or secure entry control, pair this with a UPS or specify a dual-PSU model from the industrial switch line.
Best case: a small retail location with two door-entry intercoms and a hallway/loading-dock camera cluster, all feeding back to a local NVR or cloud platform over a clean broadband link. The IPW-POE8 keeps cabling and power distribution simple. Avoid it for high-density surveillance (8+ cameras), outdoor harsh environments, or sites where uptime trumps cost.
