CyberPower CR6U61003 6U Wall Mount Rack Enclosure

Overview

The CyberPower CR6U61003 is a fully assembled 6U wall mount rack enclosure designed for secure deployment of standard 19-inch rack-mount equipment in environments where floor space is limited. Its compact form factor and 20.3-inch maximum mounting depth make it suitable for network closets, retail back offices, or small server rooms. The enclosure provides basic security with keyed alike door and side panels, protecting sensitive network hardware from unauthorized access and tampering.

Compatibility

This enclosure adheres to the EIA-310 Standard for 19-inch racks, ensuring compatibility with a wide range of standard rack-mount equipment, including network switches, patch panels, NVRs, and small servers. It supports a maximum mounting depth of 20.3 inches and a minimum of 1.9 inches, accommodating various equipment sizes. The mounting hole type supports both square and threaded inserts, offering flexibility for different rack-mount accessories.

Installation Notes

The CR6U61003 features a reversible front door, allowing installation flexibility based on site constraints. Both the door and side panels are secured with keyed locks for enhanced security. Cable management is facilitated through top and bottom openings, enabling clean routing of network and power cables. The enclosure has a stationary load capacity of 132.3 lbs (60 kg), sufficient for most 6U configurations. Its IP20 rating indicates protection against solid objects larger than 12.5mm but offers no protection against water ingress.
