CyberPower CR9U61003 9U Wall Mount Rack Enclosure

Overview

The CyberPower CR9U61003 is a fully assembled 9U wall mount rack enclosure designed to house standard 19-inch rack-mount equipment, such as network switches, patch panels, and NVRs, in environments where floor-standing racks are not feasible. Its compact design allows for secure installation in closets, offices, or behind reception areas, providing essential protection and organization for critical IT and surveillance infrastructure. The enclosure features a hex perforated metal door and side panels, all secured with keyed-alike locks for controlled access. This unit supports a stationary load capacity of 132.3 lbs and offers a maximum mounting depth of 20.3 inches.

Compatibility

This rack enclosure is compatible with all standard EIA-310 19-inch rack-mount equipment. It is suitable for housing network switches, patch panels, NVRs, DVRs, and other 19-inch wide IT and AV devices up to 9U in height. The maximum mounting depth of 20.3 inches accommodates a wide range of devices, but verify specific equipment dimensions before installation.

Installation Notes

The CR9U61003 is designed for wall mounting and includes necessary mounting hardware. Ensure the wall structure can support the weight of the enclosure plus its fully loaded equipment (up to 132.3 lbs stationary load). Cable access is provided through top and bottom openings for clean wire management. The door and side panels are removable for easier equipment installation and maintenance. The enclosure is rated IP20, meaning it protects against solid objects larger than 12.5mm but offers no protection against water ingress.
