Bosch 60W IEEE 802.3BT SINGLE PORT 20 60VDC INPUT INDOOR INDUSTRIAL - NPD-6001-I

Bosch NPD-6001-I 60W PoE Injector

Overview

The Bosch NPD-6001-I is a single-port, industrial-grade Power over Ethernet injector designed to deliver up to 60W of power to network devices. It accepts a wide DC input voltage range (20VDC to 60VDC), making it suitable for deployments where standard AC power is unavailable or unreliable, such as in mobile surveillance or remote industrial sites. This injector is essential for powering high-demand devices like PTZ cameras, advanced access control readers, or wireless access points that exceed the capabilities of standard PoE (802.3af/at).

Compatibility

This injector is compatible with any network device requiring IEEE 802.3bt Type 3 power, up to 60W. It supports standard RJ-45 connectors wired to EIA 568A or 568B standards. It is designed to work with devices that utilize the 1/2 (-), 3/6 (+), 4/5 (+), 7/8 (-) pin assignment for power delivery, common in high-power PoE applications. Ensure your connected device's power requirements do not exceed 60W.

Installation Notes

The NPD-6001-I operates across a broad temperature range of -40 °C to 75 °C (-40 °F to 167 °F), suitable for harsh environments. It requires a 20VDC to 60VDC power source, with a maximum input current of 4A. The unit supports 10/100/1000 Mbps data rates, ensuring no bottleneck for network traffic. Its compact dimensions (111 mm x 35 mm x 78 mm) facilitate installation in tight spaces. The device is rated for IEC 60068-2-27 shock, IEC 60068-2-31 freefall, and IEC 60068-2-6 vibration standards, indicating robust mechanical resilience.

What's in the Box

• 1x Bosch NPD-6001-I PoE Injector
• 1x Mounting Template
