Hanwha SLA-F2480VA 5MP Fixed Lens Module
The Hanwha SLA-F2480VA is a compact 5MP fixed lens module engineered for seamless integration with the PNM-C20000QB remote head camera system. Featuring a right-angle body design and 8-meter integrated lens cable, this accessory delivers wide-angle coverage ideal for indoor surveillance and controlled deployment environments.
Key Features
- 5MP resolution on 1/2.8" CMOS sensor
- 2.45mm fixed focal length with f/2.0 maximum aperture
- 122° horizontal field of view for expansive coverage
- 0.08 lux minimum illumination (color and B&W mode)
- Right-angle body style for flexible mounting
- 8-meter pre-installed lens cable with RJ12 connection
- Operating temperature range: -10°C to +55°C
Technical Highlights
This lens module delivers comprehensive optical performance with 122° horizontal, 90° vertical, and 158° diagonal field of view—ideal for wide-area indoor monitoring. The f/2.0 aperture and 0.08 lux sensitivity enable reliable low-light performance in both color and black & white modes at 1/30 second shutter speed. Fixed focus design ensures consistent image quality across deployment without focusing adjustments.
Typical Applications
- Indoor facility surveillance and monitoring
- Retail and commercial environments
- Wide-angle corridor and entrance coverage
- Integrated modular camera system deployments
The SLA-F2480VA is supplied complete with the 8-meter integrated lens cable, requiring no additional accessories for immediate deployment on compatible Hanwha remote head systems.
