Geovision 84-TDR4702-0F10 4MP Bullet IP Camera

Geovision 84-TDR4702-0F10 4MP Bullet IP Camera

Overview

The Geovision 84-TDR4702-0F10 is a 4MP fixed bullet camera engineered for outdoor perimeter, entry, and general-purpose surveillance where you need consistent detail capture across varying light. The 2.8mm lens delivers a wide field of view suitable for wall or eave mounting on building facades, parking lot perimeters, and loading-dock coverage. WDR (Wide Dynamic Range) balances exposure when monitoring mixed-lighting scenes—doorways with sun-blasted glass behind them, or building entries where interior and exterior brightness differ sharply. Infrared night vision activates automatically when ambient light drops, maintaining visibility without requiring external lighting infrastructure. H.265 compression cuts bandwidth and storage consumption roughly in half compared to H.264, a meaningful factor when recording 24/7 across multi-camera installations on fixed NVR storage budgets.

Compatibility

The 84-TDR4702-0F10 integrates with any standards-compliant network video recorder or video management system supporting ONVIF IP camera protocols. This includes enterprise systems, mid-market appliances, and open-architecture platforms. Mounting brackets and weatherproof cable connectors for outdoor bullet installations are available as separate camera mount accessories. Power delivery via standard PoE (802.3af) from any managed or unmanaged switch eliminates the need for separate power supplies at the camera location.

Installation Notes

Confirm your network switch provides sufficient PoE budget—this model draws power within 802.3af limits, but when deploying multiple cameras, cumulative power demand must not exceed switch capacity. Outdoor mounting requires weathertight cable glands and strain relief to prevent water ingress at connectors. Test night-vision focus under actual darkness before finalizing mounting height and angle; IR reflectivity from nearby surfaces (metal, glass) can create hotspots that degrade contrast in target areas.
