Geovision 84-MFD4700-0F10 4MP Mini Dome IP Camera

Geovision 84-MFD4700-0F10 4MP Mini Dome IP Camera

Overview

The Geovision 84-MFD4700-0F10 is a 4MP indoor mini dome delivering evidence-grade detail in a discrete footprint. Built around a compact dome housing, this camera solves the dual problem of unobtrusive placement and usable forensic imagery—typical for retail floors, office corridors, and reception areas where visible camera domes attract attention but you still need sharp face and document capture at 8–12 feet. The 4MP sensor (2560×1920) pushes enough resolution into standard focal lengths to preserve license-plate-grade legibility without zooming. WDR (Wide Dynamic Range) balances mixed lighting—sun-blasted entry doors against shadowed checkout counters—without the halo artifacts that corrupt edge analytics. H.265 compression cuts bandwidth and storage by roughly half compared to H.264, a measurable win on 24/7 recording across dozens of mini domes. IR night vision extends 24/7 operation into complete darkness without supplemental lighting, eliminating the false-economy trap of daytime-only cameras. The IP-native architecture means one Ethernet run per camera—no proprietary cabling, plug into your managed switch, and provision via standard VMS platforms.

Compatibility

The 84-MFD4700-0F10 integrates into any IP-based video management system supporting ONVIF Profile S or equivalent. It connects directly to PoE-capable network switches (802.3af or PoE+, depending on your IR duty cycle) and pairs with Geovision's own GeoVision products, as well as third-party VMS platforms. Deploy in standard indoor network surveillance ecosystems—no special firmware, no proprietary middleware required. Multi-camera deployments benefit from H.265 efficiency: ten 4MP mini domes at 4 Mbps each consume roughly 40 Mbps sustained, keeping per-camera load light on switches and recorders.

Installation Notes

Mount on ceiling or wall using standard dome brackets (verify ceiling load rating and backing type—hollow drywall requires anchors). Route Ethernet and optional audio over the same cable run where VMS supports it. IR performance degrades beyond 8–10 feet in completely dark scenes due to IR range limits inherent to mini dome optics; supplement with additional units or lower lux scenes rather than relying on single placement for wide dark areas. Operating temperature range is standard commercial indoor (0–50°C typical); avoid humidity extremes or direct water spray despite the enclosed dome.
