Hanwha SLA-T2415 2.4mm Fixed Lens Module

The Hanwha SLA-T2415 is a compact 2 megapixel fixed lens module engineered for seamless integration with Hanwha remote head camera systems, including the PNM-9000QB and XNB-6002 platforms. This modular lens solution delivers high-performance wide-angle surveillance imaging with a fixed 2.4mm focal length and exceptional field of view, making it ideal for broad-area coverage applications where flexible optical configurations are required.

Key Features

• 2MP resolution (1920 x 1080) at 30 fps
• 2.4mm fixed focal length with 138° horizontal field of view
• F/2.0 maximum aperture for enhanced light gathering
• Low-light performance at 0.45 Lux minimum illumination
• Fixed focus optical design
• RJ12 connector interface for direct integration with compatible camera heads
• Compact cylindrical form factor (Ø24 x L49.8mm)
• Durable black plastic construction

Technical Highlights

The SLA-T2415 delivers comprehensive wide-angle coverage with a 138° horizontal field of view (73° vertical, 165° diagonal), making it well-suited for lobby entrances, hallways, and expansive indoor spaces. The 1/2.8" image sensor combined with F/2.0 aperture ensures reliable color performance even in challenging low-light environments down to 0.45 Lux. Full 30 fps frame rate capability supports fluid motion capture and effective forensic review.

Applications

This lens module is ideal for facility-wide surveillance in retail environments, office buildings, educational institutions, and transportation hubs where modular camera systems provide installation flexibility and streamlined maintenance. Its wide field of view minimizes the number of camera units required for comprehensive coverage while maintaining 2MP clarity.
