Hanwha SLA-T2480WA 2.4mm Outdoor Fixed Lens
The Hanwha SLA-T2480WA is a premium fixed focal length lens module engineered for outdoor surveillance applications requiring robust performance in demanding environmental conditions. This straight-body lens delivers exceptional image quality with ultra-low light sensitivity, making it ideal for 24/7 monitoring in challenging weather and low-illumination scenarios. The module integrates seamlessly with compatible Hanwha camera platforms via RJ12 connection, providing flexible deployment options for enterprise security infrastructure.
Key Features
- Ultra-wide 138° horizontal field of view for extensive area coverage
- Exceptional 0.045 Lux low-light performance (F2.0, 1/30sec, 30IRE)
- Fixed 2.4mm focal length optimized for panoramic monitoring
- F2.0 maximum aperture for superior light gathering capability
- IP66 and NEMA 4X weatherproof ratings for extreme environments
- 8-meter cable with RJ12 connector for flexible installation
- Compact ø24 x 49.8mm form factor for discrete outdoor mounting
Technical Specifications
Optical Performance: The 2.4mm fixed lens delivers a comprehensive 138° horizontal, 73° vertical, and 165° diagonal field of view, ideal for perimeter monitoring and wide-area surveillance applications. The F2.0 aperture ensures superior performance in low-light conditions, while the fixed focus design eliminates maintenance requirements and provides consistent image sharpness across the monitoring area.
Environmental Durability: Operating across -30°C to +55°C (-22°F to +131°F) with storage capability to -50°C, this lens module handles extreme temperature fluctuations encountered in diverse geographic deployments. IP66 and NEMA 4X certifications provide complete protection against dust ingress, water jets, and environmental contaminants, ensuring reliable operation in harsh outdoor settings including coastal, industrial, and arctic environments.
Regulatory Compliance: The lens module meets international EMC standards including FCC 47 CFR 15 Class A, CE/UKCA, VCCI CISPR 32, RCM AS/NZS, and KS C classifications. Safety certification to UL 62368-1 and CAN/CSA C22.2 ensures compatibility with enterprise infrastructure requirements.
Compatible Systems
The SLA-T2480WA is engineered for use with Hanwha PNM-9000QB and XNB-6002 camera platforms, with the 0.045 Lux minimum illumination specification achieved through integration with these compatible units.
Applications
- Perimeter security and access control monitoring
- Wide-area facility surveillance in industrial settings
- Outdoor campus and parking lot coverage
- Transportation and critical infrastructure monitoring
- Coastal and high-temperature environment deployments
James EverettPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The SLA-T2480WA delivers exceptional value for enterprises requiring ultra-wide field of view coverage in outdoor environments. The 138° horizontal perspective minimizes camera count requirements for large area monitoring, directly reducing deployment costs and system complexity. The 0.045 Lux performance specification positions this lens above standard outdoor modules, enabling effective color surveillance in conditions typically requiring infrared augmentation.
The fixed focus architecture eliminates manual calibration errors and lens drift common in motorized alternatives, while the compact 101g weight enables installation on lightweight mounting infrastructure. The 8-meter cable provides installation flexibility in distributed surveillance architectures without requiring powered intermediate connections. For integrators, the RJ12 connection standard simplifies inventory management and reduces training requirements across mixed-vendor environments.
