Signamax 065-1176BLFSMM 10/100 to 100BaseFX WDM Fiber Converter

Overview

The Signamax 065-1176BLFSMM is a critical component for extending network reach in environments where standard copper Ethernet cabling is insufficient. This Wide Wavelength Division Multiplexing (WDM) media converter bridges the gap between 10/100Base-TX copper Ethernet and 100Base-FX multimode fiber optic networks. It's designed for point-to-point fiber links, enabling you to deploy network devices like IP cameras or access control panels up to 2 kilometers away from your network switch. The unit utilizes different wavelengths for transmitting and receiving, allowing two separate fiber links to operate over a single strand of multimode fiber, which is particularly useful for maximizing existing fiber infrastructure.

Compatibility

This converter is designed to interface with standard 10/100Base-TX Ethernet ports found on most network switches, IP cameras, and other edge devices. For fiber connectivity, it requires a paired WDM converter on the other end of the fiber link. Specifically, this unit transmits at 1550 nm (Tx) and receives at 1310 nm (Rx). Therefore, it must be paired with a WDM converter that receives at 1550 nm and transmits at 1310 nm to establish a functional link. It is compatible with 100Base-FX fiber optic standards over multimode fiber (MMF).

Installation Notes

The 065-1176BLFSMM uses an SC connector for its multimode fiber connection, a common standard in enterprise and industrial networking. It requires a standard 5V DC power supply (sold separately) and draws minimal power. Ensure the fiber optic cable is clean and free from damage before connecting. Proper pairing with a complementary WDM converter is essential for link establishment. The operating temperature range is -10°C to 55°C (14°F to 131°F), making it suitable for controlled indoor environments.
