Hanwha ACV-8080R 5MP IR Vandal Dome Camera
The Hanwha ACV-8080R (often searched as ACV 8080R) is a 5MP analog HD infrared vandal dome engineered for high-impact surveillance in secured perimeters, parking facilities, transportation hubs, and areas prone to tampering or extreme weather. Built on the Wisenet A Series platform, this camera bridges legacy analog and modern hybrid infrastructure by supporting multiple HD-over-coax protocols without requiring equipment replacement—a significant practical advantage when upgrading existing analog systems incrementally.
Key Features
- 5MP Native Resolution (2592×1944): Captures video at up to 30 fps in AHD/TVI/CVBS modes, delivering 2.5× more pixel density than 1080p analog cameras. This translates to better forensic playback and facial/license-plate detail at distance. You can identify specifics across wider coverage areas without repositioning equipment.
- Motorized Varifocal Lens (4.3–10.5mm, 2.44x Zoom): Adjustable field-of-view from 88° (wide, parking lot overview) to 34° (tight, entry point focus) eliminates the need for multiple fixed-lens cameras or physical repositioning. Deploy a single camera and adjust zoom during commissioning or as site requirements shift—reduces initial hardware count and long-term deployment costs.
- Infrared Night Vision (20m Range): Built-in IR LEDs deliver effective illumination to 20 meters, supporting 0 Lux monochrome operation and 0.4 Lux color performance. Operates 24/7 without supplemental lighting in darkened parking structures, alleys, or exterior perimeters. Adjustable LED intensity prevents washout in confined spaces and reduces power draw when full range is unnecessary.
- Day/Night Auto-Switching (ICR): Internal Color Conversion automatically transitions between color and monochrome as ambient light changes, ensuring optimal contrast and forensic detail without manual intervention or scene-specific tuning.
- Vandal-Resistant Construction (IP66/IK10): IP66 rating prevents direct rain, dust, and moisture ingress—critical in outdoor parking lots, building perimeters, and transit stations. IK10 impact rating withstands physical tampering and vandal attacks without optical or housing degradation. Together, these ratings eliminate the need for separate protective cages in most deployments, lowering material and installation costs. Note: IP66 blocks spray and heavy rain but does not support full submersion; if you require submerged operation, specify an IP67+ model instead.
- Multi-Protocol Output (AHD/TVI/CVI/CVBS): Selectable protocols via DIP switch allow deployment in legacy analog systems, hybrid DVR/NVR environments, or mixed infrastructure without codec conversion appliances. The camera adapts to your existing coaxial backbone—no rip-and-replace required.
- 1/2.8" Progressive Scan CMOS Sensor: Delivers clean image quality with minimal rolling shutter artifacts. Supports low-light color capture at 1/30 second shutter speed (F1.6), which is faster than typical fixed-iris domes and reduces motion blur during night operation.
- Motorized Zoom Control via PTZ Interface: If your DVR supports PTZ output, zoom is controlled remotely from the control room. Otherwise, zoom is set manually during installation and remains static—verify your DVR's PTZ capabilities before commissioning.
Integration & Compatibility
The ACV-8080R connects via standard BNC coaxial cable, making it a direct replacement for older analog domes in existing installations. Protocol selection is configured through DIP switches on the camera body—no software or re-provisioning required. Compatible with legacy DVR systems and modern hybrid platforms that accept AHD, TVI, CVI, or CVBS input. Motorized zoom requires the DVR to support PTZ signaling; verify this capability before purchase if remote zoom is required.
When to Choose a Different Model
If your infrastructure is pure IP-based (ONVIF NVRs, cloud integration, advanced codec efficiency), consider a higher-megapixel IP dome in the Hanwha surveillance line instead. The ACV-8080R outputs analog HD over coaxial cable only—it does not support Ethernet transmission, which limits bandwidth efficiency on long cable runs and prevents integration with modern network video management platforms. For environments requiring ONVIF compliance, video analytics, or integration with third-party VMS software, an IP-native camera is the appropriate choice.
Frequently Asked Questions
Q: Can the ACV-8080R work with my existing analog DVR system?
A: Yes. The camera outputs AHD, TVI, CVI, or CVBS—all analog HD protocols supported by modern and legacy DVRs. Set the protocol via DIP switch to match your DVR's input specifications. No IP network or Ethernet connectivity is required.
Q: What is the maximum infrared range, and does it work in complete darkness?
A: IR range is 20 meters (65 feet). In complete darkness, the camera operates in 0 Lux monochrome mode using the built-in IR LEDs. With 0.4 Lux of ambient light (moonlight, distant streetlights), the camera switches to color mode and maintains color output. Adjustable LED intensity prevents overexposure in confined spaces.
Q: Is the zoom motorized or fixed?
A: The lens is motorized varifocal (4.3–10.5mm). If your DVR supports PTZ output, zoom can be controlled remotely. Otherwise, zoom is adjusted manually during installation. Verify your DVR's PTZ capabilities before purchase if remote zoom control is required.
Q: What is the difference between IP66 and IP67 ratings, and which do I need?
A: IP66 means the camera resists direct rain and spray; IP67 adds submersion protection up to 1 meter for 30 minutes. Choose IP66 for outdoor perimeters, parking lots, and transit stations exposed to weather. Choose IP67 only if the camera will be submerged or installed in a water-spray wash-down area.
Q: Can I integrate this camera with an IP-based NVR or Milestone VMS?
A: No. The ACV-8080R is analog coaxial output only and does not support Ethernet or ONVIF protocols. It requires a DVR with analog HD input ports (AHD, TVI, CVI, or CVBS). For IP or ONVIF integration, select an IP-native camera from the Hanwha product family.
Q: What is the impact rating, and does it protect against vandalism?
A: The IK10 rating means the camera withstands impacts up to 20 joules without optical or housing damage—equivalent to a vandal strike with a hand tool or rock. Combined with the dome form factor and metal housing, the ACV-8080R eliminates the need for a protective cage in most deployments, lowering installation cost and improving aesthetics.
Marty AllisonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The ACV-8080R occupies a specific niche: analog HD surveillance in facilities still operating DVR infrastructure. It's not a modern IP camera, but it's also not a legacy 1080p analog dome. The 5MP native resolution and 4.3–10.5mm motorized lens give you flexibility to adjust coverage post-installation without adding cameras, which matters in larger deployments where repositioning is disruptive.
Technical Highlights:
- 5MP at 30 fps (AHD/TVI/CVBS mode): This is your forensic ceiling on analog HD. CVI mode drops to 4MP at 20 fps—a limitation if your DVR defaults to CVI. Check your hardware's native protocol before buying to avoid disappointing framerate or resolution penalties.
- IP66/IK10 combination: Rain and dust ingress won't happen; neither will dome distortion from a thrown rock or hammer strike. This matters in transit stations and retail parking where casual vandalism is real. You eliminate the cost and aesthetic penalty of installing a protective cage.
- 20m IR with 0.4 Lux color: Many analog domes force monochrome at night. This one holds color in low light, which is useful if your investigation needs color detail (vehicle paint, clothing). Adjustable LED intensity is non-obvious but practical—full 20m range is overkill in a stairwell; dial it back and save power.
- DIP-switch protocol selection: No software, no reprogramming. Set the switch, mount, and cable. This is operationally clean if you're running mixed AHD/TVI infrastructure.
Deployment Considerations:
- Analog coaxial output means this camera is invisible to IP-based VMS platforms, cloud storage, and ONVIF integrations. If your roadmap includes network migration, a native IP camera is the more future-proof choice, even if you deploy it with an analog backbone today.
- Motorized zoom control requires PTZ signaling from the DVR—not all legacy DVRs support this. Verify before purchase. If your system doesn't, you set zoom at installation and it's static; the camera is still useful, but you lose the flexibility advantage.
- CVI protocol users see a resolution penalty (4MP vs. 5MP) and framerate drop (20 fps vs. 30 fps). If you're standardized on CVI, consider requesting an AHD or TVI equivalent instead.
Position the ACV-8080R in analog HD perimeter and parking lot deployments where you need impact resistance, flexible zoom, and 24/7 IR coverage, and where your DVR infrastructure is stable and not earmarked for IP migration. For facilities planning a network transition or already running pure IP, choose an IP dome instead.
