Hanwha FC37-001051A PNM-9320VP Quad Camera Window
The Hanwha FC37-001051A is the factory-spec window assembly for the PNM-9320VP multi-directional quad camera. The PNM-9320VP uses four independently-aimed sensors behind a single contoured front window, and the optical clarity, anti-reflective coating, and precise channel cut-outs of this window are essential to keep all four channels delivering full-published image quality.
Key Features
- OEM Hanwha window assembly for the PNM-9320VP quad sensor camera
- Precision contour preserves correct angle of incidence for each of the four sensor channels
- Anti-reflective interior treatment reduces flare and IR ghosting
- UV-stabilized exterior coating slows haze formation under sustained sun exposure
- Maintains the camera's published IP and IK ratings with the OEM gasket
- Direct mechanical replacement without camera-body removal
- Cost-effective alternative to RMAing the entire camera after surface damage
The PNM-9320VP is a flagship multi-sensor camera typically mounted in parking decks, intersections, and large indoor lobbies where one camera replaces three or four traditional fixed cameras. Window damage is a common service issue — projectile impact, ladder strike, and gradual cleaning-induced abrasion all reduce image quality on the affected channel. Because each channel uses an independent optical path, a damaged window can degrade one channel while leaving others usable, but the only correct repair is a window replacement.
Plan the service window to include a fresh gasket, new desiccant, and the Hanwha-published torque value for the cover screws. After re-assembly, verify all four channels in WAVE or the Hanwha Device Manager and confirm image focus has not shifted. Stocking this part on the service vehicle is recommended for any team responsible for multi-sensor camera fleets — turnaround on a flagship camera RMA can take days, but a window swap is a single same-day visit.
