Sub categories

Showing Results for Video & Storage

Compare

Out of stock
Axis

SKU: 02766-004

Axis S3008 Mk II 8TB Network Video Recorder - 02766-004

8TB compact NVR with integrated 8-port PoE switch for small facilities
Special Order · Usually Ships in 2-3 Weeks

$1,329.00 $1,288.99 Save $40.01

Add to Cart
The item has been added
Compare

Out of stock
Axis

SKU: 02765-004

Axis S3008 Mk II Compact PoE Recorder 4TB - 02765-004

8-camera PoE recorder with integrated switch and 4TB storage in compact form
Special Order · Usually Ships in 2-3 Weeks

$979.00 $949.99 Save $29.01

Add to Cart
The item has been added
Compare

Out of stock
Axis

SKU: 03426-012

Axis S9301 Mk II 4K Workstation - 03426-012

Dual 4K micro workstation with FIPS 140-2 security for surveillance ops
Special Order · Usually Ships in 2-3 Weeks

$1,689.00 $1,638.99 Save $50.01

Add to Cart
The item has been added
Compare

Out of stock
Axis

SKU: 03426-004

Axis S9301 Mk II Dual 4K Workstation NVR - 03426-004

Micro 4K workstation NVR for dual-monitor surveillance command centers
- Dual 4K DisplayPort outputs run synchronized live and playback feeds
- Intel Core processor with 16GB RAM and Windows 11 IoT Enterprise LTSC
- 182×36×178mm compact form factor fits desks, walls, and tight spaces
Special Order · Usually Ships in 2-3 Weeks

$1,689.00 $1,637.99 Save $51.01

Add to Cart
The item has been added
Compare

Out of stock
Axis

SKU: 03427-004

Axis S9302 4K Quad Monitor Workstation - 03427-004

Four 4K monitors, Intel Core + dual graphics, Windows 11 IoT Enterprise
- Quad 4K display support via DisplayPort 1.4a + 3x Mini DisplayPort outputs
- Intel Core processor with 16GB RAM, Intel UHD + Nvidia RTX A400 graphics
- FIPS 140-2 Level 2 TPM 2.0 and Secure Boot for regulated environments
Special Order · Usually Ships in 2-3 Weeks

$2,859.00 $2,772.99 Save $86.01

Add to Cart
The item has been added
Compare

Out of stock
Axis

SKU: 03427-012

Axis S9302 Mk II 4K Professional Workstation - 03427-012

Quad 4K workstation for multi-camera security operations
Special Order · Usually Ships in 2-3 Weeks

$2,859.00 $2,773.99 Save $85.01

Add to Cart
The item has been added
Compare

Out of stock
Axis

SKU: 02035-001

Axis TS2901 Appliance Stand for S2208/S2212 - 02035-001

Vertical stand for AXIS S2208/S2212 appliances in tight spaces
- Mounts S2208 and S2212 upright to reclaim desk footprint in control rooms
- Includes 4 mounting screws and rubber feet; optional surface-mount capability
- Compact 15.55 x 6.3 x 1.57 in form factor weighs 3.75 lb
Special Order · Usually Ships in 2-3 Weeks

$43.00 $42.99 Save $0.01

Add to Cart
The item has been added
Compare

Add to Cart The item has been added
Axis

SKU: 01964-004

Axis W800 Network Video System Controller - 01964-004

Centralized network video controller with 470GB storage and 12VDC power
- Single management interface for Axis cameras and compatible third-party devices
- Low 16W power draw supports continuous 24/7 operation in equipment racks
- 0.47TB internal storage for local recording buffering and configuration backups
Special Order · Usually Ships in 2-3 Weeks

$1,639.00 $1,589.99 Save $49.01

Add to Cart
The item has been added
Compare

Out of stock
Bosch

SKU: CCSD-CURD

Bosch CCSD-CURD Network Video Recorder
Special Order · Usually Ships in 2-3 Weeks

$2,595.00 $1,688.99 Save $906.01

Add to Cart
The item has been added
Compare

Out of stock
Bosch

SKU: PLE-WP3S2Z-US

Bosch PLE-WP3S2Z-US Wall Panel
Special Order · Usually Ships in 2-3 Weeks

$110.00 $75.99 Save $34.01

Add to Cart
The item has been added
Compare

Out of stock
Bosch

SKU: VZX-8-US

Bosch V-series Wall Panel Controller With 1.77IN - VZX-8-US
$1,106.50 $203.99 Save $902.51

Add To Quote
Compare

Out of stock
Eaton

SKU: 116750224-001

Eaton Environmental Monitoring Probe - Temp & - 116750224-001
Special Order · Usually Ships in 2-3 Weeks

$322.00 $252.99 Save $69.01

Add to Cart
The item has been added
Compare

Out of stock
Eaton

SKU: 103005912

Eaton Environmental Rack Monitor C13/C14 100-250V - 103005912
Special Order · Usually Ships in 2-3 Weeks

$556.51 $410.99 Save $145.52

Add to Cart
The item has been added
Compare

Out of stock
ELO Touch

SKU: E210789

ELO Touch 1.8m Cable Kit - M Series Monitors - E210789
Special Order · Usually Ships in 2-3 Weeks

$50.00 $49.99 Save $0.01

Add to Cart
The item has been added
Compare

Out of stock
ELO Touch

SKU: E408193

ELO Touch 1.8M Cable KIT FOR 03LM Series Monitors - - E408193
Special Order · Usually Ships in 2-3 Weeks

$35.00 $34.99 Save $0.01

Add to Cart
The item has been added
Compare

Out of stock
ELO Touch

SKU: E408388

ELO Touch 1.8M Cable KIT FOR Usbc Series Monitors - - E408388
Special Order · Usually Ships in 2-3 Weeks

$59.00 $58.99 Save $0.01

Add to Cart
The item has been added

What to Look For When Buying

The six decisions that matter most before you spec.

Channel Count vs Bitrate Ceiling

A "32-channel" NVR doesn't mean 32 4K cameras. Aggregate bitrate — typically 320 Mbps or 512 Mbps on commercial NVRs — is the real constraint. 32 cameras × 8 Mbps each = 256 Mbps, which leaves almost no headroom for peak motion scenes. Size by aggregate bitrate first, channel count second. See retention math.

RAID vs JBOD vs Single-Drive

Single-drive NVRs fail catastrophically on disk loss. RAID 5 survives one drive loss, RAID 6 survives two, RAID 10 combines mirror + stripe. For critical deployments, specify RAID 5 minimum — and size the array for rebuild-time bitrate, which can be 4x normal write load for 24+ hours. Use surveillance-grade drives only (Seagate SkyHawk, WD Purple) — consumer and NAS drives will fail under 24/7 write workload.

VMS vs Appliance NVR

Appliance NVRs (Axis Camera Station, Hanwha Wisenet NVR, Hikvision DS-96xxx) are purpose-built, tested-together hardware with bundled licensing. Server-based VMS (Milestone XProtect, Genetec Security Center, Avigilon ACC) scale to unlimited channels, mix any ONVIF camera, and integrate with enterprise systems. Choose appliance for <64-channel single-site; choose VMS for multi-site or enterprise integration.

NDAA Compliance for Recorders

NDAA restrictions apply to NVRs as well as cameras — Hikvision and Dahua NVRs are excluded from federal procurement. NDAA-compliant NVR options include Axis Camera Station, Hanwha Wisenet, i-PRO, Digital Watchdog, Bosch, and server-based VMS on standard x86 hardware.

Retention & Compression

30-day retention across 32 4K cameras can be ~100 TB at H.264 — or ~50 TB at H.265 — or ~30 TB with smart-compression variants. Cameras, codec, bitrate, and motion activity all compound. Our retention math guide covers the formulas; use conservative bitrate assumptions unless you've benchmarked your scenes.

Failover & High Availability

Mission-critical deployments use dual-recorder failover (Milestone XProtect Corporate, Genetec Archiver redundancy, Axis Camera Station Pro HA). Standalone appliance NVRs typically don't support true HA — their failover is limited to edge SD-card recording on the cameras themselves. If uptime matters, architect HA from day one, not as a retrofit.

Technology Stack

The specs and acronyms that actually affect outdoor performance.

ONVIF Profile G + T

Profile G standardizes recording and playback; Profile T adds advanced streaming including H.265 and analytics metadata. Certified conformance — not "ONVIF compatible" language — is what ensures playback, export, and metadata interoperability across NVRs and VMS. Check spec sheets.

H.265 / HEVC vs H.264 / AVC

H.265 cuts bitrate 40-50% at equivalent perceived quality. Storage savings compound over multi-month retention. Trade-off: H.265 decoding requires ~2x the CPU for live monitoring on mid-range VMS servers. Most new NVRs support H.265 recording and H.264 or H.265 decoding per-channel.

RAID Levels for Surveillance

RAID 5 (stripe + parity, single-drive tolerance) is the surveillance standard for 4-8 drive arrays. RAID 6 (stripe + double parity, two-drive tolerance) for 8+ drive arrays where rebuild time extends risk window. RAID 10 (mirror + stripe) for write-intensive video-analytics servers. Never RAID 0 for production.

Surveillance-Grade HDDs

Seagate SkyHawk and WD Purple are purpose-engineered for 24/7 write workloads at 180 TB/yr workload rating. Consumer desktop drives (Seagate Barracuda, WD Blue) and even NAS drives (WD Red) will fail prematurely under 16-camera continuous-record load. Budget SkyHawk/Purple pricing up-front — drive failures during warranty are operationally painful.

Edge + Cloud Hybrid Archive

Modern deployments often combine local edge recording (30-day primary retention) with cloud archive (90-day+ compliance retention). Axis Connected Services, Milestone XProtect Cloud, Genetec Stratocast, and Verkada Command implement edge-to-cloud tiering. Bandwidth, egress costs, and compliance scope all matter.

Failover Architecture

Milestone XProtect Corporate implements true recorder failover — a standby server takes over recording within seconds of primary failure. Genetec Archiver Redundancy works similarly. Appliance NVRs typically do not support true failover; SD-card failover on the camera itself fills the gap for brief outages but not for total recorder loss.

Typical Deployment Scenarios

32-Camera Retail Plaza

Single-site deployment: 32 IP cameras across six storefronts, mix of outdoor and indoor. 32-channel NVR with 16TB RAID-5 for 30-day retention at 2 Mbps H.265. Mobile app for store managers, export workflow for loss-prevention.

500-Camera Campus VMS

University campus with 500 IP cameras across 40 buildings, mix of brand/form-factor. Milestone XProtect Expert on dual redundant servers, 300TB NetApp storage, integrated with access control events and mass-notification. 60-day retention, 7-year forensic archive on tape.

Multi-Site Retail Chain

200 retail locations, 12 cameras per site, centralized VMS. Milestone XProtect Corporate or Genetec Federation model: per-site edge NVR with central management at HQ. Cloud archive for 90-day compliance retention. Analytics for people-counting, dwell-time, and shrinkage investigation.

Critical Infrastructure

Utility substation with 48 cameras including thermal, PTZ, and panoramic. Dual-redundant VMS servers with real-time replication, FIPS 140-2 encryption, CJIS-compliant audit logging. NDAA-compliant cameras and NVRs only — Axis, Hanwha, i-PRO. Integration with SCADA and perimeter intrusion.

Frequently Asked Questions

How do I size an NVR for my cameras?

Start with aggregate bitrate, not channel count. Estimate per-camera bitrate (2 Mbps for 2MP H.265, 4-6 Mbps for 4K H.265 on busy scenes) and sum across all cameras. Ensure the NVR's total-bitrate rating exceeds your sum by at least 20%. Then size storage: total bitrate × seconds × retention days ÷ 8 = bytes. Our retention math guide walks through the complete formula.

Are Hikvision NVRs NDAA compliant?

No. Hikvision and Dahua NVRs fall under the same NDAA Section 889 restrictions as their cameras — excluded from U.S. federal, state government, and critical-infrastructure procurement. NDAA-compliant NVR options include Axis Camera Station, Hanwha Wisenet, i-PRO, Digital Watchdog, and Bosch DIVAR.

Do I need surveillance-grade hard drives?

Yes — standard desktop or NAS drives will fail prematurely under 24/7 write workload. Seagate SkyHawk and Western Digital Purple are purpose-engineered for surveillance workloads (180 TB/yr rating, multi-drive vibration tolerance, optimized firmware for streaming writes). The cost difference vs. desktop drives is marginal; the failure rate difference is catastrophic.

What's the difference between an NVR and a VMS?

An NVR is a turnkey appliance — tested hardware + software combo, typically 8-64 channels, easy to deploy. A VMS (Video Management System) is server-based software that runs on standard x86 hardware and scales to thousands of channels, mixes any ONVIF cameras, and integrates with enterprise systems. Rule of thumb: NVR for single-site <64 channels; VMS for multi-site, >64 channels, or enterprise integration. See our VMS platform guide.

Can I mix camera brands on one NVR?

It depends. Appliance NVRs (Axis Camera Station, Hanwha Wisenet) typically support their own brand plus ONVIF cameras with limited analytics interop. Server-based VMS platforms (Milestone, Genetec, Exacq) routinely mix Axis, Hanwha, i-PRO, Hikvision, Bosch on one server — as long as all are ONVIF Profile S + G certified. Vendor-specific AI/analytics metadata may require the matching VMS.

What RAID level should I use for surveillance storage?

RAID 5 for 4-8 drive arrays (single-drive tolerance, ~80% storage efficiency). RAID 6 for 8+ drive arrays where rebuild time is long and second-drive failure during rebuild is a realistic risk. RAID 10 for analytics-heavy VMS servers that mix high write + read workloads. Never RAID 0 for production. Size all arrays for rebuild-time performance — 4x normal bitrate is typical during a rebuild.
