Vertiv LV5500R-400 High-Performance KVM Extender Receiver

Overview

The Vertiv Avocent LV5500R-400 is a high-performance KVM extender receiver designed to extend 4K video and USB signals over long distances. This unit is crucial for scenarios where you need to access and control a server or workstation remotely, such as in data centers, control rooms, or broadcast environments, without compromising video quality or responsiveness. It supports resolutions up to 4096x2160 at 60Hz, ensuring crisp visuals for detailed work. The LV5500R-400 model is specifically the receiver unit, pairing with a transmitter (sold separately) to complete the KVM extension link.

Compatibility

This receiver is part of the Vertiv Avocent LV5500 series. It is designed to work with the corresponding LV5500 transmitter unit. The system supports DisplayPort video connections and USB 2.0 Type B for keyboard and mouse connectivity. Analog audio line in/out and an RJ12 serial port are also available for peripheral integration. It requires an RJ45 or SFP+ connection for the primary extension link, allowing for flexible network integration.

Installation Notes

The operating temperature range for the LV5500R-400 is 0°C to 40°C (32°F to 104°F), with a storage temperature range of -10°C to 50°C (14°F to 122°F). Humidity should be kept between 0% and 80% non-condensing. The unit requires a 12 VDC power supply, drawing up to 18W, and accepts 100–240 VAC input via its power supply unit.
