APC by Schneider Electric SMX750CNC Concise Descriptor

Overview

The APC by Schneider Electric SMX750CNC is a 750VA Uninterruptible Power Supply (UPS) designed to provide clean, reliable backup power and surge protection for sensitive electronic equipment. Its convertible rack/tower design offers deployment flexibility, making it suitable for server rooms, network closets, or workstations where continuous operation is critical. The integrated LCD interface provides at-a-glance status updates and simplifies configuration. This unit is engineered to protect against power fluctuations and outages, ensuring your connected devices remain operational during short-term power interruptions and providing time to safely shut down during longer events.

Compatibility

This UPS is designed to support a wide range of standard IT equipment. It is compatible with most 120V rack-mount servers, network switches, workstations, and other critical devices that draw up to 750VA or 500W. Specific compatibility extends to standard 19-inch rack installations and standalone tower deployments. It is suitable for use with network surveillance equipment, including cameras and NVRs, provided their combined power draw does not exceed the unit's capacity.

Installation Notes

The SMX750CNC requires a standard NEMA 5-15P input plug for connection to a 120V AC power source. Output receptacles are NEMA 5-15R. Ensure the total continuous load does not exceed 500W (750VA) to maintain optimal performance and battery life. For rack mounting, standard rack rails (not included) are required. For tower deployment, ensure adequate ventilation around the unit, maintaining at least 2 inches of clearance on all sides.
