TSC SP-PEX-2000-0026 Peel-Off Assembly Right Hand
Overview
The TSC SP-PEX-2000-0026 is a right-hand peel-off assembly designed for integration with TSC thermal label printing systems. This component enables automatic label peeling functionality, allowing operators to separate printed labels from the backing material without manual intervention. The assembly is supplied as a complete set per box and connects to compatible TSC printer platforms via wired connectivity.
Key Features
- Right-Hand Configuration: Optimized for RH mounting to accommodate diverse production line layouts and facility workflows
- 14 ips Print Speed: Delivers 14 inches per second throughput when integrated with compatible host printers, supporting high-volume label operations
- 4.1-Inch Maximum Print Width: Accommodates label sizes up to 4.1 inches wide for standard and mid-range label applications
- Multiple Resolution Support: Compatible with 203 dpi, 300 dpi, and 600 dpi print resolutions for varied quality and detail requirements
- Wired Connectivity: Reliable hardwired connection to host printer eliminates wireless latency and ensures consistent peeling operation
- Label Media Support: Engineered for roll-feed label stock with standard backing material compatibility
- Touchscreen Integration: Works with TSC printers equipped with touchscreen displays for intuitive operational control and diagnostics
- One Set Per Box: Complete assembly delivered in single package ready for installation
Integration & Compatibility
The SP-PEX-2000-0026 peel-off assembly integrates with TSC SG-Series and related thermal label printer platforms. The right-hand orientation suits production environments where label output must feed toward the operator's right side or where existing machinery constraints require RH peeler configuration. Wired connection provides synchronization between printer controller and peeling mechanism, ensuring labels separate cleanly at the correct timing relative to print head advancement. Installation requires mechanical mounting to the printer frame and electrical harness connection to the printer's accessory port.
Operational Specifications
Print speed capability reaches 14 inches per second under standard conditions when the host printer operates at rated throughput. Maximum print width of 4.1 inches accommodates label rolls up to that dimension, making this assembly suitable for shipping labels, barcode labels, and product identification applications. Resolution options span 203 dpi (standard), 300 dpi (mid-range), and 600 dpi (high-detail) to match print quality requirements. The peeling mechanism operates on label stock with standard paper or synthetic backing material; confirm compatibility with your specific label substrate before deployment.
Ted PerryPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
I've evaluated the TSC SP-PEX-2000-0026 during integration planning for a mid-size logistics operation transitioning to automated label finishing. This right-hand peel-off assembly addresses a real operational gap: manual label separation becomes a bottleneck in high-volume environments. The SP-PEX-2000-0026 handles that cleanly when properly matched to your printer platform.
Technical Highlights:
- Throughput Alignment: 14 ips print speed means the peeler must coordinate precisely with printer advancement; wired connectivity ensures no timing drift between print cycles and peel actuation
- Resolution Flexibility: Support for 203, 300, and 600 dpi lets you right-size label quality to application—203 dpi covers most barcode and shipping scenarios; 600 dpi handles fine graphics and small fonts
Deployment Considerations:
- Verify your label roll width does not exceed 4.1 inches; oversized roll stock will jam the peel mechanism and cause downtime
- Confirm backing material compatibility before full production—some synthetic substrates may not separate cleanly; test a sample batch first
- Right-hand orientation is permanent; confirm your space layout matches RH mounting before ordering—swapping to LH requires a separate part
For operations printing 500+ labels per shift, the SP-PEX-2000-0026 delivers measurable labor savings and consistent label presentation. Pair it with a compatible TSC printer and you'll eliminate manual peeling tasks and reduce operator fatigue. Implementation is straightforward if your host printer has the accessory port and firmware support.
