Lenovo Thinksystem ST650 V2 4314 32GB - 7Z74A02LNA

Lenovo 7Z74A02LNA Server Chassis

Overview

The Lenovo ThinkSystem ST650 V2 (model 7Z74A02LNA) is a 4U rack-convertible tower server designed for enterprise workloads requiring significant processing power and memory capacity. It supports dual third-generation Intel Xeon Scalable processors, up to 4TB of system memory, and provides high-speed 10GbE networking for demanding applications like VMS or data analytics.

Compatibility

This server chassis (7Z74 machine type) is compatible with one or two third-generation Intel Xeon Scalable processors (codenamed "Ice Lake"). It supports up to 32x 128GB 3DS RDIMMs for a maximum of 4TB of system memory, or up to 5TB when combined with Intel Optane Persistent Memory 200 Series modules. The 7Z74 machine type includes a 3-year warranty.

Installation Notes

The server chassis measures 175 mm (6.9 in.) wide, 462 mm (18.2 in.) high, and 734 mm (28.9 in.) deep. It supports up to 4x double-wide or 8x single-wide GPU adapters, enabling significant graphical processing capabilities. Cooling is managed by up to 4x N+1 redundant 92 mm hot-swap fans.
